5.38 RIGHT RAMP ASSEMBLY

500-2525-00
4
4
5
ID Part Number Description
1 510-1033-00 RIVETED RAMP ASM, AVENGERS, RIGHT
2 515-0215-00 LONG RANGE OPTO EMITTER ASSEMBLY
3 515-0215-01 LONG RANGE OPTO RECEIVER ASSEMBLY 1
4 237-5880-00 SCREW, #6 X 3/8 PPH T-25
5 535-2431-00 PROTECTOR, OPTO
ITEM
NO. PART NUMBER
1 510-1033-00
2 515-0215-00
3 515-0215-01
4 237-5880-00
5 535-2431-00
4
4
1
5
3
DESCRIPTION
RIVETED RAMP ASM, WATSON,
RIGHT
LONG RANGE OPTO EMITTER
ASSEMBLY
LONG RANGE OPTO RECEIVER
ASSEMBLY
SCREW, #6 X 3/8 PPH T-25
PROTECTOR, OPTO
AVENGERS INFINITY QUEST LE / PREMIUM MANUAL 500-55R2-01
© MARVEL

5.39 RIGHT WIRE RAMP ASSEMBLY

500-2547-00
2
2X
1
ID Part Number
1 515-2328-00
Qty
2 180-5010-04
1 3 535-6539-00
1 4 237-5937-02
4
2
QTY.
ITEM
1 PART NUMBER
NO.
1 515-2328-00
1
2 180-5010-04
3 535-6539-00
1
4 237-5937-02
4
2
PARTS REFERENCE
A
3
4
2
DETAIL A
Description
SCALE 1 : 2
WIRE RAMP, AVENGERS, RIGHT
MICRO-SWITCH
SWITCH BODY PROTECT PLATE
SCREW, 2-56 X 1/2" HWH MS
DESCRIPTION
WIRE RAMP, WATSON, RIGHT
MICRO-SWITCH
SWITCH BODY PROTECT PLATE
SCREW, 2-56 X 1/2" HWH MS
Qty
1
1
1
2
QTY.
1
1
1
2
57
