SETUP GUIDE
1-800-KICKERS - parts.service@sternpinball.com
www.sternpinball.com - facebook.com/sternpinball
Stern Pinball machines are assembled in Elk Grove Village, Illinois,
USA; each pinball machine has unique characteristics that make it
a one-of-a-kind American-made product. Each machine will have
variations in appearance resulting from differences in the machine's
particular wood parts, digital art and mechanical assemblies. Stern
Pinball has inspected each game element to ensure it meets our quality
standards.
© & ™ Lucasfilm Ltd.
Advertisement
Table of Contents
Related Manuals for Stern Pinball STAR WARS Pin Series
Summary of Contents for Stern Pinball STAR WARS Pin Series
- Page 1 SETUP GUIDE 1-800-KICKERS - parts.service@sternpinball.com www.sternpinball.com - facebook.com/sternpinball Stern Pinball machines are assembled in Elk Grove Village, Illinois, USA; each pinball machine has unique characteristics that make it a one-of-a-kind American-made product. Each machine will have variations in appearance resulting from differences in the machine’s particular wood parts, digital art and mechanical assemblies.
- Page 2 IMPORTANT SAFETY INSTRUCTIONS - PLEASE READ FIRST 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not operate this apparatus near water. 6. Clean only with a dry cloth. 7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. 8.
- Page 3 PARTS LIST TOOLS REQUIRED: - 5/8” WRENCH OR SOCKET DRIVER BACKBOX FRONT MOLDING CABINET 1 GAME CABINET 4 LEGS AND LEVELERS 8 CABINET LEG BOLTS POWER CORD 2 BACKBOX BOLTS SETUP GUIDE 4 PINBALLS INDEX INITIAL SETUP • 4 VOLUME ADJUSTMENT • 9 SERVICE MENU •...
-
Page 4: Initial Setup
INITIAL SETUP (2 PEOPLE REQUIRED) OPEN CARTON UNBOX GAME TAKE HOLD OF THE CABINET CAREFULLY TILT CARTON AND CAREFULLY PULL GAME FORWARD ONTO THE FLOOR OUT FROM CARTON REMOVE 4 LEGS STAND GAME ON FROM CARTON INSTALL BOTH FRONT LEGS CHECK THAT BOTTOM LEG EACH USING 2 OF THE BOLTS LEVELERS ARE FULLY SEATED... - Page 5 WITH ASSISTANCE AGAIN, WITH ASSISTANCE, CAREFULLY LIFT THE BACK ROCK THE CABINET FORWARD OF THE CABINET AND PLACE ON A STURDY SUPPORT OBJECT UNTIL THE FRONT LEGS ARE INSTALL AND TIGHTEN BOTH ON THE FLOOR BACK LEGS USING 2 BOLTS EACH CUT THE STRAP LIFT BACKBOX...
- Page 6 SECURE BACKBOX USING THE TWO 5/8” BACKBOX BOLTS INCLUDED INSTALLING PINBALLS TO INSTALL PINBALLS SLIDE PLAYFIELD GLASS REACH INSIDE THE CABINET DOWN PARTIALLY AND PLACE AND LIFT THE TWO LATCHES THE PINBALLS INTO THE LOCATED ON EITHER SIDE OF PLAYFIELD AREA THE FRONT DOOR SLIDE PLAYFIELD GLASS SLIGHTLY TOWARDS THE...
- Page 7 TILT ADJUSTMENT LEVELING ADJUST THE FRONT LOCATE THE TILT SENSOR OR REAR LEVELERS AS INSIDE THE FRONT DOOR BY THE LEFT SIDE PANEL. NECESSARY TO POSITION THE PLAYFIELD BUBBLE LEVEL, LOCATED ON THE REMOVE ANY SHIPPING FRONT RIGHT OF THE MATERIAL COVERING THE PLAYFIELD NEXT TO THE TILT SENSOR.
- Page 8 PLAYFIELD ACCESS (FOR QUALIFIED SERVICE PERSONNEL ONLY) CAREFULLY LIFT THE PLAYFIELD BY THE UNSCREW THE BLACK MIDDLE OF THE PLASTIC ARCH PLAYFIELD KNOB AT THE BOTTOM CENTER OF THE PLAYFIELD PLASTIC ARCH LIFT THE PLAYFIELD UP AND THEN PULL SLIGHTLY TOWARDS YOU PLAYFIELD SHOULD STOP SLIDING AT A NOTCH ABOUT A...
-
Page 9: Volume Adjustment
VOLUME ADJUSTMENT Volume Menu Control: Green - Exit to Attract Mode Left Red - Decrease Volume Right Red - Increase Volume Black - Enter Service Menu Open the door on the front of the machine to gain access to the service control buttons. - Page 10 SERVICE MENU CONTINUED DIAGNOSTICS The Diagnostics Menu is used to access various tests to verify that your machine is working properly or to help diagnose potential problems. SWITCH Switch Test: Close each switch by hand and observe the display. If the switch is working properly it will display the name and corresponding number of the switch when it is actived.
- Page 11 SERVICE MENU CONTINUED GAME Bank: Tests the functionality of the 3-Bank Drop Target Assembly. Manually hit the drop targets and watch the display. The display should indicate any dropped targets. Useful for checking the functionality of switches in the drop target bank. If any of the targets are recessed, press the start button to reset them.
-
Page 12: Service Menu Adjustments
SERVICE MENU ADJUSTMENTS STANDARD ADJUSTMENTS ID Adjustment Name Default 30 Custom Message Setting 31 Knocker Volume 32 Game Restart Replay Type Auto 33 Ball Save Time 0:08 Replay Percentage 34 Timed Plunger Replay Award Extra Ball 35 Flipper Ball Launch Replay Levels 37 Player Competition Auto Replay Start... -
Page 13: Playfield & Cabinet Electrical
NODE BOARD ID INSTRUCTION SHEET PLAYFIELD & CABINET ELECTRICAL PLAYFIELD FRONT NODE 8c MODEL BACKBOX NODE 0 NODE 8a CN22 CPU NODE 0 NODE 8b NODE 8 Node Bus Cable (RJ45) 604-5004-08-XX Serial Data Cable 036-8054-XX When replacing node boards, ensure DIP address switches are set correctly! PLAYFIELD REAR... - Page 14 Driver Location Map...
-
Page 15: Switch Reference
SWITCH REFERENCE Name Node Node Conn. Input Input Ground Location Type Address Part Number Wire Wire Shooter Lane CN10 2 7/8/9 BLK Playfield Opto 8-SW-28 520-8115-00 tx Opto 520-8116-00 rx Left Outlane CN11 4 Playfield Rollover 8-SW-17 500-9935-03 Left Return CN11 5 Playfield Rollover 8-SW-18 500-9935-03 Lane... - Page 16 Switch Location Map...
- Page 17 SWITCH REFERENCE CONTINUED Name Node Node Conn. Input Input Ground Location Type Address Part Number Wire Wire Right Pop CN13 2 Playfield Leaf 8-SW-0 180-5232-00 Bumper Han Ramp CN11 2 11/12 BLK Playfield Rollover 8-SW-26 500-9935-03 Enter Han Ramp Exit CN11 3 11/12 BLK Playfield Opto...
-
Page 18: Light Reference
LIGHT REFERENCE Name Node Node Conn. Ret. Ret. Src. Src. Location Type Light Address Part Number Ext. Wire Wire Color Left Outlane 8 CN14 6 7/8 YEL Playfield Feature White 8-LP-3 520-5307-00 Left Return CN14 5 7/8 YEL Playfield Feature White 8-LP-4 520-5307-00 Lane Right Return... - Page 19 Light Location Map...
- Page 20 LIGHT REFERENCE CONTINUED Name Node Node Conn. Ret. Ret. Src. Src. Location Type Light Address Part Number Ext. Wire Wire Color 3-Bank Drop RED Playfield Feature White 8-LP-43 520-7011-00 Tgt Center 3-Bank Drop RED Playfield Feature White 8-LP-42 520-7011-00 Tgt Right R2-D2 RED Playfield Feature White 8-LP-41 520-5307-00...
- Page 21 LIGHT REFERENCE CONTINUED Name Node Node Conn. Ret. Ret. Src. Src. Location Type Light Address Part Number Ext. Wire Wire Color Playfield CN15 5 Playfield G.I. White 8-LP-0 112-5034-WW GI 1 Playfield CN15 6 Playfield G.I. White 8-LP-1 112-5034-WW GI 2 520-8059- 00(POPS) 520-...
-
Page 22: Playfield Top Assemblies
PLAYFIELD TOP ASSEMBLIES Part Number Description 500-2496-00 Shooter Assembly 515-5133-08-06 Flipper Bat 511-2778-00 Left Wireform Ramp 515-2077-00 Right Wireform Ramp 626-5057-01 Rubber Pad 510-1017-00 Left Ramp 510-1018-00 Right Ramp 511-2775-00 Spinner Assembly 535-9051-00 Shooter Lane Ramp 511-7989-00 Death Star (Left) 511-1050-01 Death Star (Right) 500-2487-00... -
Page 24: Playfield Bottom Assemblies
PLAYFIELD BOTTOM ASSEMBLIES Part Number Description 500-1177-00 Auto Launch Assembly 500-9820-L8 Trough Assembly 500-6543-13-ND Left Flipper Assembly 500-6543-03-ND Right Flipper Assembly 500-9920-01 Left Slingshot 500-9920-01 Right Slingshot 520-7011-00 3-LED Board 520-7008-00-L8 Center LED Board 500-7216-13 Drop Target Assembly 520-6831-01 Serial LED Board 515-6459-04-ND Pop Bumper - Bottom Assembly 511-2771-31... -
Page 26: Playfield Rubber Parts
PLAYFIELD RUBBER PARTS Qty Size (ID) Size (OD) Durometer Color Part Number 3/16" Black 545-5348-01 5/16" Black 545-5348-02 3/4" Black 545-5348-04 1" Black 545-5348-05 1-1/2" Black 545-5348-07 2-1/2" Black 545-5348-09 7/16" Black 545-5348-17 Qty Description Color Part Number Flipper Rubber Black 545-5277-00 Plunger Tip... - Page 28 1-800-KICKERS STAR WARS #500-55L8-01 MANUAL #780-50L8-00 PARTS.SERVICE@STERNPINBALL.COM WWW.STERNPINBALL.COM *780-50L8-00* FACEBOOK.COM/STERNPINBALL...
