SERVICE AND OPERATION MANUAL
WARNING
IMPORTANT HEALTH WARNING: PHOTOSENSITIVE SEIZURES - A very small percentage of people may experience a seizure when exposed to certain visual images, in-
cluding flashing lights or patterns. Even people with no history of seizures of epilepsy may have an undiagnosed condition that can cause "photosensitive epileptic seizures"
due to certain visual images, flashing lights or patterns. Symptoms can include light-headedness, altered vision, eye or face twitching, jerking or shaking of arms or legs,
disorientation, confusion, momentary loss of awareness, and loss of consciousness or convulsions that can lead to injury from falling down or striking nearby objects.
IMMEDIATELY STOP PLAYING AND CONSULT A DOCTOR IF YOU EXPERIENCE ANY OF THESE SYMPTOMS.
Stern Pinball machines are assembled in Elk Grove Village, Illinois, USA. Stern Pinball has inspected each game element to ensure it meets our quality standards.
Each pinball machine has unique characteristics that make it a one-of-a-kind American made product. Each will have variations in appearance resulting from differences
in the machine's particular wood parts, individual printed art and mechanical assemblies. No playfield is perfectly flat and varies depending on the season. Game play will
result in playfield dimpling as the harder steel ball contacts the wood and coating; over time multiple dimples will blend to make them less noticeable. Normal plastic insert
crazing (tiny stress cracks) and ghosting (small cloudy areas around insert edges) are often seen in pinball machines, due to a combination of plastic mold stress, pushing of
inserts into purposely undersized holes, and heating and breaking of inserts' plastic "skin" when the playfield field is sanded.
REBEL BLOCKADE RUNNER Composed by John T. Williams © 1977 WARNER-TAMERLANE PUBLISHING CORP. (BMI) AND BANTHA MUSIC (BMI) ALL RIGHTS
RESERVED. USED BY PERMISSION.
THRONE ROOM (AND END TITLE) Composed by John T. Williams © 1977 WARNER-TAMERLANE PUBLISHING CORP. (BMI) AND BANTHA MUSIC (BMI) ALL RIGHTS
RESERVED. USED BY PERMISSION.
THE IMPERIAL MARCH Composed by John T. Williams © 1977 WARNER-TAMERLANE PUBLISHING CORP. (BMI) AND BANTHA MUSIC (BMI) ALL RIGHTS RESERVED.
USED BY PERMISSION.
© & ™ Lucasfilm Ltd.
Games configured for North America operate on 60 cycle electricity only. These games will not operate in countries with 50 cycle electricity (Europe, UK, Australia).
STAR WARS LE #500-55J6-01
STAR WARS PREMIUM #500-55J7-01
1-800-KICKERS - parts.service@sternpinball.com
www.sternpinball.com - facebook.com/sternpinball
MANUAL #780-50J6-00
Advertisement
Table of Contents
Related Manuals for Stern Pinball STAR WARS Premium
Summary of Contents for Stern Pinball STAR WARS Premium
- Page 1 IMMEDIATELY STOP PLAYING AND CONSULT A DOCTOR IF YOU EXPERIENCE ANY OF THESE SYMPTOMS. Stern Pinball machines are assembled in Elk Grove Village, Illinois, USA. Stern Pinball has inspected each game element to ensure it meets our quality standards. Each pinball machine has unique characteristics that make it a one-of-a-kind American made product. Each will have variations in appearance resulting from differences in the machine’s particular wood parts, individual printed art and mechanical assemblies.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Setup and Moving ........3 5.11 Slingshot Assembly..........42 5.12 Flipper Assembly, Left ........43 First-Time Setup Instructions ....... 3 5.13 Flipper Assembly, Right ........43 Adjustments Menu ..........6 5.14 Pop Bumper Assembly ........44 Transporting the Game ........7 5.15 Pop Bumper Top Assembly ....... -
Page 3: Setup And Moving
MOVE AND MANEUVER THE SETUP INSTRUCTIONS TOOLS REQUIRED GAME. USE PROPER MOVING EQUIPMENT EXTREME Your brand new Stern Pinball Machine is • 5/8” Socket Wrench CARE WHILE HANDLING. STERN carefully packed for safety and security. • Utility Knife PINBALL MACHINES... - Page 4 SETUP AND MOVING FIRST-TIME SETUP CONTINUED 15. Cut nylon strapping and remove 18. Open the front coin door. 21. Store the backbox keys, if desired, protective strap corner guards. 19. Reach into the game and remove on the metal hook located in the 16.
- Page 5 SETUP AND MOVING FIRST-TIME SETUP CONTINUED SPIKE PINBALL SOFTWARE 30. If pinballs were already installed into the lower ball trough, remove them before lifting the playfield. UPDATE INSTRUCTIONS 31. Grasp the lower arch between the flippers, and firmly but gently pull directly up to raise the playfield 8 to 12 Obtain game software update file (filename ends inches.
-
Page 6: Adjustments Menu
SETUP AND MOVING 1.2 ADJUSTMENTS MENU STANDARD ADJUSTMENTS STANDARD ADJUSTMENT #1 appears with the adjustment name flashing. While the adjustment name is flashing press [<] [>] to move between adjustments. Perform the below steps to review the adjustments. To change the adjustment setting press SELECT. While the Enter the Service Menu, then enter the Standard Adjustments adjustment setting is flashing, press [<] [>] repeatedly until Menu. -
Page 7: Transporting The Game
SETUP AND MOVING 1.3 TRANSPORTING THE GAME CAUTION When transporting the game, such as in the back of a truck or with a hand truck, the game’s backbox must be secured to prevent damage to the side rails. NEVER TRANSPORT THE GAME IN A MOVING VEHICLE WITH THE BACKBOX RAISED! TWO PEOPLE 1. -
Page 8: Maintenance
Flipper rebuild kits, Left and Right (500-6307-10,-00) scuffed. Dirty pinballs accelerate game wear. Star Wars LE Playfield Plastics Kit 803-5000-J6 OVERHAUL MAINTENANCE - (5000 GAMES) Star Wars Premium Playfield Plastics Kit 803-5000-J7 Star Wars LE Playfield Decals Kit 802-5000-J6 • Verify latest game software is installed... -
Page 9: Spike System And Node Guide
48V system power. SPIKE standard I/O nodes are low-power nodes that read switch inputs and output to A Stern Pinball machine based on the SPIKE system will have at standard-brightness LEDs. Standard I/O nodes use the node bus... -
Page 10: Spike Node Programming
SPIKE SYSTEM AND NODE GUIDE SPIKE SYSTEM AND NODE GUIDE CONTINUED 2.5 SPIKE NODE PROGRAMMING INPUT/OUTPUT PROTECTIONS The SPIKE nodes are smart nodes that have on-board pro- SPIKE features built-in short-circuit, static electricity, and other cessors and run embedded code. The nodes are programmed protections to maximize reliability. -
Page 11: Light, Switch, And Driver Reference
LIGHT, SWITCH, AND DRIVER REFERENCE NODE BOARD ID INSTRUCTION SHEET 3. LIGHT, SWITCH, AND DRIVER REFERENCE PREMIUM/LIMITED EDITION PLAYFIELD FRONT NODE 8 NODE 8a PLAYFIELD LCD NODE 8b BACKBOX NODE 0 NODE 8d NODE 8e NODE 8c CN11 CN22 CPU NODE 0 NODE 8f NODE 9a CN13... -
Page 12: Driver Reference
SPIKE SYSTEM AND NODE GUIDE 3.2 DRIVER REFERENCE Name Node Connector Ret. Ret. Wire Voltage V+ Color Location Type Address Part Number Trough ORG GRY 48V GRY ORG Playfield Coil - 27-1500 8-DR-1 090-5004-ND Auto Plunger ORG WHT 48V GRY ORG Playfield Coil - 26-1200 8-DR-4 090-5044-ND... - Page 13 SPIKE SYSTEM AND NODE GUIDE DRIVER REFERENCE CONTINUED Figure 3.2.1. Playfield driver locations (top view). STAR WARS LE / PREMIUM MANUAL 500-55J6-01 © & ™ Lucasfilm Ltd.
-
Page 14: Switch Reference
SPIKE SYSTEM AND NODE GUIDE 3.3 SWITCH REFERENCE ID Name Node Node Conn. Input Input Wire Ground Wire Location Type Address Part Number Left Outlane CN11 4 LGN RED 11-12 BLK ORG Playfield Rollover 8-SW-17 500-9935-04 Left Return Lane CN11 5 LGN ORG 11-12 BLK ORG Playfield... - Page 15 SPIKE SYSTEM AND NODE GUIDE SWITCH REFERENCE CONTINUED ID Name Node Node Conn. Input Input Wire Ground Wire Location Type Address Part Number Mini Target 4 CN12 4 PNK RED BLK VIO Playfield Leaf, 9-SW-10 515-9785-00-00 Target Mini Target 5 CN12 5 PNK ORG BLK VIO...
- Page 16 SPIKE SYSTEM AND NODE GUIDE SWITCH REFERENCE CONTINUED Figure 3.3.1. Playfield switch locations (top view). Continued on next page... STAR WARS LE / PREMIUM MANUAL 500-55J6-01 © & ™ Lucasfilm Ltd.
- Page 17 SPIKE SYSTEM AND NODE GUIDE SWITCH REFERENCE CONTINUED ID Name Node Node Conn. Input Input Wire Ground Wire Location Type Address Part Number Sixth Coin Cabinet 1-SW-21 Ticket Notch CN11 5 Cabinet 1-SW-8 Slam Tilt LGN RED Cabinet 1-SW-22 DIP 1 CPU Node 0-SW-0 C10 Service Plus...
-
Page 18: Light Reference
SPIKE SYSTEM AND NODE GUIDE 3.4 LIGHT REFERENCE Name Node Node Conn. Ret. Pin Ret. Wire Src. Pin Src. Wire Location Type Light Address Part Number Ext. Color Coin Enable BLK GRY GRY RED Coin Door Digital Out 1-LP-0 Start Button YEL BRN Cabinet Feature... - Page 19 SPIKE SYSTEM AND NODE GUIDE LIGHT REFERENCE CONTINUED Name Node Node Conn. Ret. Pin Ret. Wire Src. Pin Src. Wire Location Type Light Address Part Number Ext. Color FO(R)CE LED5 Playfield Feature White 8-LP-44 520-7043-00 FOR(C)E LED4 Playfield Feature White 8-LP-43 520-7043-00 FORC(E)
- Page 20 SPIKE SYSTEM AND NODE GUIDE LIGHT REFERENCE CONTINUED Figure 3.4.1. Playfield light locations (top view). Continued on next page... STAR WARS LE / PREMIUM MANUAL 500-55J6-01 © & ™ Lucasfilm Ltd.
- Page 21 SPIKE SYSTEM AND NODE GUIDE LIGHT REFERENCE CONTINUED Name Node Node Conn. Ret. Pin Ret. Wire Src. Pin Src. Wire Location Type Light Address Part Number Ext. Color RIGHT RAMP X-G LED8 Playfield Feature 9-LP-38 520-7054-00 RIGHT RAMP X-B LED8 Playfield Feature 9-LP-39...
- Page 22 SPIKE SYSTEM AND NODE GUIDE LIGHT REFERENCE CONTINUED Name Node Node Conn. Ret. Pin Ret. Wire Src. Pin Src. Wire Location Type Light Address Part Number Ext. Color 147 LEFT POP BUMPER BRN BLK 1/2/3 Playfield Feature White 10-LP-49 520-6971-01 148 RIGHT POP BUMPER 1/2/3 Playfield...
-
Page 23: Motor Reference
SPIKE SYSTEM AND NODE GUIDE 3.5 MOTOR REFERENCE Name Node Node Ext. Conn. Ret. Ret. Wire Src. Src. Wire Location Type Light Address Part Number Color Motor A Enable Playfield Motor 9-LP-56 520-6996-00 Motor A Control 1A Playfield Motor 9-LP-57 520-6996-00 Motor A Control 2A Playfield... -
Page 24: Electronic Pinouts And Schematics
ELECTRONIC PINOUTS AND SCHEMATICS 4. ELECTRONIC PINOUTS AND SCHEMATICS 4.1 SPIKE-2 CPU NODE 0 509-1003-01 DIRECT SWITCH MAPPING (CN25) The coin-door diagnostic switches are connected directly to the CPU node via the Cabinet Node. Note that both the CPU and Cabinet nodes are required for diagnostic switch operation. - Page 25 ELECTRONIC PINOUTS AND SCHEMATICS SPIKE-2 CPU NODE 0 CONTINUED AUDIO PINOUTS Type Description Minimum Impedance Power (RMS) CN18 TRS 3.5mm Headphone Left 8 Ohms 200mW Headphone Ring Headphone Right 8 Ohms 200mW Jack Sleeve Audio Ground .156" 5-pin Speaker Right Ground (-) 4 Ohms Header Speaker Right (+) 4 Ohms...
-
Page 26: Cabinet Node 1
ELECTRONIC PINOUTS AND SCHEMATICS 4.2 CABINET NODE 1 520-6967-72 Type Description Wire Color .100" 8-Pin Header Universal Card Link Coin 1 Meter 1 Notch Coin Enable Ticket Enable Ground .100" 5-Pin Header low Ground ticket Ticket Low sw. Ticket Low .100"... -
Page 27: Lower Playfield 48V Driver Pinout Node 8
ELECTRONIC PINOUTS AND SCHEMATICS 4.3 LOWER PLAYFIELD 48V DRIVER PINOUT NODE 8 520-7017-72 CN11 .100" 12-Pin Header 8-SW-26 Switch LGN-BLK 8-SW-27 Switch LGN-BRN 8-SW-17 Switch LGN-RED 8-SW-18 Switch LGN-ORG 8-SW-19 Switch LGN-YEL 8-SW-20 Switch LGN-BLU 8-SW-21 Switch LGN-VIO 8-SW-22 Switch LGN-GRY 8-SW-23 Switch LGN-WHT... - Page 28 ELECTRONIC PINOUTS AND SCHEMATICS 4.4 MID UPPER PLAYFIELD 48V DRIVER PINOUT NODE 9 520-7017-72 CN11 .100" 12-Pin Header 9-SW-26 Switch 9-SW-27 Switch 9-SW-17 Switch TAN-BLK 9-SW-18 Switch TAN-RED 9-SW-19 Switch TAN-ORG 9-SW-20 Switch TAN-YEL 9-SW-21 Switch 9-SW-22 Switch TAN-BLU 9-SW-23 Switch TAN-VIO Ground BLK-BLU...
-
Page 29: Through Serial Opto Receiver Extension 8A
ELECTRONIC PINOUTS AND SCHEMATICS 4.5 THROUGH SERIAL OPTO 4.7 MODE SMALL LED BOARD 8C RECEIVER EXTENSION 8A 520-7042-00 520-7001-00 Type Description Wire Color .100" 7-Pin Header Ground MISO Output Data VIO-BLK MOSI Input Data Type Description Wire Color SCK Serial Clock VIO-RED CN1 .100"... -
Page 30: Mode Small Led Board 8D
ELECTRONIC PINOUTS AND SCHEMATICS 4.8 MODE SMALL LED BOARD 8D 4.9 MODE SMALL LED BOARD 8E 520-7042-00 520-7042-00 Type Description Wire Color Type Description Wire Color CN1 .100" 7-Pin Ground CN1 .100" 7-Pin Ground Header Header MISO Output Data VIO-BLK MISO Output Data VIO-BLK MOSI Input Data... -
Page 31: Five Bank Led Board 8F
ELECTRONIC PINOUTS AND SCHEMATICS 4.10 FIVE BANK LED BOARD 8F 4.12 RIGHT RAMP LED BOARD 9B 520-7043-00 520-7054-00 Type Description Wire Color .100" 7-Pin Header 1 Ground MISO Output Data VIO-BLK MOSI Input Data VIO-BRN SCK Serial Clock VIO-RED RCK Register Clock VIO-ORG Type Description... -
Page 32: Serial 16 Led Board 9C
ELECTRONIC PINOUTS AND SCHEMATICS 4.13 SERIAL 16 LED BOARD 9C 4.14 SERIAL MOTOR DRIVER BOARD 9D 520-6831-01 520-6996-00 Type Description Wire Color CN1 .100 in 12-Pin LED15 Housing LED14 LED13 LED12 LED11 LED10 Type Description Wire Color LED9 BLU-YEL CN1 .100" 7-Pin Ground Header LED8... -
Page 33: Spi Core Playfield Node 10
ELECTRONIC PINOUTS AND SCHEMATICS 4.15 SPI CORE PLAYFIELD NODE 10 4.17 MAIN LED BOARD 10A 520-6976-72 520-7052-00 Type Description Wire Color CN1 .100" 7-Pin Header Ground MISO Output Data VIO-BLK MOSI Input Data VIO-BRN Type Description Wire Color SCK Serial Clock VIO-RED SW1 Address DIP Node 10 - OFF-ON-OFF-OFF -... -
Page 34: Backpanel 48V Driver Pinout Node 11
ELECTRONIC PINOUTS AND SCHEMATICS 4.18 BACKPANEL 48V DRIVER PINOUT NODE 11 520-6998-72 GREEN ORANGE BLACK NEUTRAL CN15 .100" 14-Pin Header 11-SW-4 Switch Return WHT-BLU 520-6998-72 CN11 11-SW-5 Switch Return WHT-VIO 4 Coil NODE 11-SW-6 Switch Return WHT-GRY 11-SW-7 Switch Return CN14 CN13 CN16... -
Page 35: Power Distribution Board
ELECTRONIC PINOUTS AND SCHEMATICS 4.19 POWER DISTRIBUTION BOARD 4.20 POWER PLUG WIRING 520-5343-01 CAUTION TO MAINTAIN SAFETY, GROUND WIRE FROM LINE FILTER IS TO BE MOUNTED FIRST ON GROUNDING STUD AND SECURED WITH NUT. ALL OTHER GROUNDS MAY THEN BE ATTACHED TO GROUNDING STUD. -
Page 36: Parts Reference
PARTS REFERENCE 5. PARTS REFERENCE 5.1 PLAYFIELD RUBBER PARTS RUBBER O-RINGS Size (ID) Size (OD) Durometer Color Part Number 3/16" Black 545-5348-01 5/16" Black 545-5348-02 3/4" Black 545-5348-04 1-1/4" Black 545-5348-06 2" Black 545-5348-08 2-1/2" Black 545-5348-09 3-1/2" Black 545-5348-11 7/16"... -
Page 37: Playfield Assemblies, Top
PARTS REFERENCE 5.3 PLAYFIELD ASSEMBLIES, TOP Part Number Description 545-5995-02 Bottom Arch Assembly 755-51J5-12-Y Instruction Card 755-5400-02-Y Coin Card (USA) 545-5409-01 Light Reflector 535-1324-01 Bracket Support 545-5409-01 Reflector 077-5026-01 Socket 511-7888-05 1-Way Gate 511-7877-00 Spinner 500-1064-00 Accelerator Exit Diverter 511-5096-00 Electric Gate 511-5033-03 Electric Gate... -
Page 38: Playfield Assemblies, Bottom
PARTS REFERENCE 5.4 PLAYFIELD ASSEMBLIES, BOTTOM Part Number Description 520-7017-72 Core Node 520-7042-00 LED Board - Mode Small 520-7053-00 LED Board - Right Eject 520-7054-00 LED Board - Right Ramp 520-6976-72 SPF Node 520-7043-00 LED Board - Five Bank 520-7052-00 LED Board - Main 520-6831-01 Serial 16 LED Board... -
Page 39: Backbox Parts
PARTS REFERENCE 5.5 BACKBOX PARTS LCD BACKBOX LCD BACKBOX 5009995-XX DOMESTIC VERSION 500-9995-XX Figure 5.5.1. Backbox external assemblies and components. Figure 5.5.2. Backbox internal assemblies and components. EXTERNAL INTERNAL Part Number Description Part Number Description 660-5052-00 Backglass 509-1003-01 CPU Node Board 830-52J6-00 Translite Art [LE] 520-5343-01... -
Page 40: Cabinet Parts
Side Armor Right [LE] 820-78J6-03 Decal, Cabinet Left, Star Wars LE 535-7297-02 Side Armor - Wrinkle Black [Premium] 820-78J7-03 Decal, Cabinet Left, Star Wars Premium 500-6146-00-04 Ball Shooter Assembly 820-78J6-04 Decal, Cabinet Right, Star Wars LE 535-5027-01 Plunger Support Plate, Notched... -
Page 41: Ball Shooter Assembly
PARTS REFERENCE 5.9 AUTO LAUNCH ASSEMBLY 5.8 BALL SHOOTER ASSEMBLY 500-9818-01 500-6146-00-04 Part Number Description 535-5067-02 Housing Assembly 266-5001-04 Compressed Spring (Long) - Green 242-5014-00 Washer 3/8 ID x 5/8 OD x 1/16 515-6557-00 Rod Assembly 266-5010-00 Compressed Spring (Short) 270-5012-00 Retaining Ring, 3/8"... -
Page 42: Ball Trough Assembly
PARTS REFERENCE 5.11 SLINGSHOT ASSEMBLY 5.10 BALL TROUGH ASSEMBLY 500-9920-01 500-9820-00 ID Part Number Description 515-7811-00 MAIN BRKT. BALL TROUGH 515-7812-00 COIL BRACKET, BALL TROUGH 237-5975-04 SCREW, 8-32 X 1/4" HWH SWAGE SERR Part Number Description 266-5020-00 COMPRESSION SPRING-CONICAL 515-5339-01 SLINGSHOT BRACKET ASSEMBLY 535-5203-03 COIL RETAINING BRACKET... -
Page 43: Flipper Assembly, Left
PARTS REFERENCE 5.12 FLIPPER ASSEMBLY, LEFT 5.13 FLIPPER ASSEMBLY, RIGHT 500-6543-12-ND 500-6543-02-ND ID Part Number Description ID Part Number Description 515-6617-01 FLIPPER BASE PLATE LEFT KIT W/ 515-6617-00 FLIPPER BASE PLATE RIGHT KIT W/ BRACKET MOUNT HARDWARE BRACKET MOUNTING HARDWARE 515-6308-01 COIL STOP BRACKET 515-6308-01... -
Page 44: Pop Bumper Assembly
PARTS REFERENCE 5.14 POP BUMPER ASSEMBLY 516-6784-XX Part Number Description 515-6459-01L BUMPER/RING TOP ASSY, W/ LED 1 515-6459-04-ND BUMPER BOTTOM ASSY, NO DIODE ID Part Number Description 500-9934-01 POP BUMPER SWITCH ASSY-2 - LUG-LEFT 240-5005-00 6-32 NYLON STOP NUT 090-5044-ND COIL - 26-1200 10 237-5976-01 #6-32 X 1/4"... -
Page 45: Pop Bumper Top Assembly
PARTS REFERENCE 5.15 POP BUMPER TOP ASSEMBLY 5.17 FIVE-BANK DROP TARGET ASSEMBLY 515-6459-00 500-7216-15 ITEM # QTY PART # DESCRIPTION 545-5195-00 BUMPER BASE 545-5197-00 BUMPER BODY 545-5607-04 BUMPER SKIRT - TRIMMED 266-5048-00 COMPRESSION SPRING, POP BUMPER BODY 511-7670-00 POP BUMPER LED PCB W/ WIRES POP BUMPER TOP ASSY W/ LED - Part Number Description... -
Page 46: Vertical Up-Kicker Assembly
PARTS REFERENCE 5.18 VERTICAL UP-KICKER 5.19 UP POST ASSEMBLY, LONG, NO ASSEMBLY DIODE 500-7078-01 500-6657-04-ND Part Number Description 535-9248-00 BRACKET 535-5203-03 COIL RETAINING BRACKET 232-5300-00 SCREW, 8-32 X 1/4" PPH SEMS 090-5044-ND COIL 26-1200 - NO DIODE 545-5847-00 COIL SLEEVE 280-5014-00 ADJUSTABLE BUMPER/STOP 515-7223-00... -
Page 47: Fork Ramp Opto Assembly
PARTS REFERENCE 5.20 FORK RAMP OPTO ASSEMBLY 5.22 FORK RAMP ASSEMBLY - MOTORIZED 511-7834-00 500-1045-01 ITEM PART NUMBER DESCRIPTION QTY. LONG RANGE OPTO 515-0215-01 RECEIVER ASSEMBLY LONG RANGE OPTO 515-0215-00 EMITTER ASSEMBLY 535-1512-00 CLEAVER OPTO BRACKET 237-5880-02 SCREW, #6 X 1/2 PPH T-25 Part Number Description 515-0215-01... -
Page 48: Tie Fighter Spring Assembly
PARTS REFERENCE 5.23 TIE FIGHTER SPRING 5.25 STAR WARS LE SPOT LAMP ASSEMBLY ASSEMBLY 500-1065-00 500-1091-00 Default/ ITEM NO. PART NUMBER DESCRIPTION QTY. TIE FIGHTER CHASSIS 515-1900-00 ASSEMBLY 880-6203-00 TIE FIGHTER WING 8-32 x 1/2 LG. SOC HD HEX, 237-6132-00 BLACK OXIDE 266-5107-02 ONE SIDED BUCKLING SPRING... -
Page 49: Lcd Display Assembly
PARTS REFERENCE 5.26 LCD DISPLAY ASSEMBLY 5.28 UP POST ASSEMBLY - LONG NO DIODE 500-2465-00 500-6657-04-ND ITEM NO. PART NUMBER DESCRIPTION QTY. 515-1819-00 LCD DISPLAY, 4.3", FRONT BRKT 545-9951-00 LCD DISPLAY, 4.3", SCREEN PROTECTOR 254-5090-01 PLASTIC SPACER #4 SCREW, 3/16" OD - 3/16" LENGTH 509-2002-00 4.3"... -
Page 50: Millennium Falcon Ship Subassembly
PARTS REFERENCE 5.30 MILLENNIUM FALCON SHIP 5.31 COMPACT DIVERTER SUBASSEMBLY ASSEMBLY 511-7887-00 500-1046-00 ITEM PART NUMBER DESCRIPTION QTY. APPLY LOCTITE FALCON LIGHT SUPPORT 535-1638-00 BRACKET TO SCREW 515-1871-00 FALCON TOY ASSEMBLY 545-1019-00 FALCON ENGINE PLASTIC 520-7000-00 SINGLE FLASH LED BOARD WASHER, .150 I.D. -
Page 51: Star Wars Le Left Ramp Assembly
PARTS REFERENCE 5.32 STAR WARS LE LEFT RAMP 5.33 STAR WARS LE RIGHT RAMP ASSEMBLY ASSEMBLY 500-1023-01 500-1024-01 ITEM PART 510-76 830-84 242-50 232-52 180-50 535-65 237-59 ITEM NO. PART NUMBER 510-7685-01 DOUNT LE LEFT RA 830-8400-22L PLAST 515-0215-01 LONG RANGE OPT 515-0215-00 LONG RANGE OP 242-5001-00... -
Page 52: Death Star Le Main Assembly
PARTS REFERENCE 5.34 DEATH STAR LE MAIN 5.35 DEATH STAR LE RIGHT ASSEMBLY ASSEMBLY 500-1062-00 511-7917-00 ITEM NO. PART NUMBER DESCRIPTION QTY. 511-7918-00 DEATH STAR LE FRAME SUB ASSEMBLY 520-7000-00 SINGLE FLASH LED BOARD 240-5005-00 6-32 NYLON STOP NUT 545-1017-00 FIRE BALL VACUUM FORMED 511-7897-00 DEATH STAR LIGHT SUBASSEMBLY... -
Page 53: Death Star Actuator Assembly
PARTS REFERENCE 5.37 DEATH STAR ACTUATOR 5.39 DEATH STAR LIGHT ASSEMBLY ASSEMBLY 511-7897-XX 511-7890-00 511-7897-00 "LEFT" ITEM NO. PART NUMBER DESCRIPTION QTY. 515-1821-00 DEATH STAR ACTUATOR MAIN PLATE 545-5070-08 FLIPPER BUSHING 090-5044-ND COIL 26-1200 - NO DIODE 545-5411-00 COIL SLEEVE 535-5203-05 COIL RETAINING BRACKET 237-5976-02... -
Page 54: Electric Gate Rail Mount Assembly
PARTS REFERENCE 5.40 ELECTRIC GATE RAIL MOUNT 5.42 ELECTRIC GATE BACK PANEL ASSEMBLY MOUNT 511-5033-XX 511-5096-XX 511-5033-00 511-5033-01 LEFT RIGHT ITEM NO. PART NUMBER DESCRIPTION QTY. BRACKET, ELEC GATE, RAIL 535-9847-00 511-5096 MOUNT 090-5060-01- MINI-COIL W/CORE, ND - 32- "LEFT" 1250, YELLOW 535-9577-00 COVER, ELECTRIC GATE... -
Page 55: Ball Guide 01 Assembly
PARTS REFERENCE 5.44 BALL GUIDE 01 ASSEMBLY 5.46 PLASTIC 12L ASSEMBLY 511-7797-01 511-7798-12L ITEM PART NUMBER DESCRIPTION QTY. 535-1456-01 DOUGHNUT BALL GUIDE -01 511-7877-00 SPINNER ASSY, BALL GUIDE MNT 237-6151-00 SCREW, 4-40 X 5/16" PFH U/C MS ITEM NO. PART NU 830-7378 550-5052 237-5809... -
Page 56: Accelerator Exit Diverter Actuator Assembly
PARTS REFERENCE 5.49 ACCELERATOR EXIT DIVERTER 5.48 ACCELERATOR EXIT DIVERTER ASSEMBLY ACTUATOR ASSEMBLY 500-1064-00 500-1063-00 ITEM NO. PART NUMBER 515-1826-00 ACCELERATOR EXIT 545-5352-00 NYLINER 530-7812-18 PIVOT 515-1827-00 ACCELERATOR E 270-5001-00 RETAINING E-R ITEM NO. PART NUMBER 535-1609-00 ACCELERAT ACCELERAT 515-9993-00 Part Number Description 545-5352-00... -
Page 57: Accelerator Coil Spacer Assembly
PARTS REFERENCE 5.51 ACCELERATOR COIL SPACER 5.53 STAR WARS LE BACK PANEL ASSEMBLY ASSEMBLY 511-7817-00 500-1022-01 ITEM ITEM NO. PART NUMBER DESCRIPTION QTY. 535-1499-00 ACCELERATOR COIL TIGHTENER 515-0215-01 LONG RANGE OPTO RECEIVER ASSEMBLY 515-0215-00 LONG RANGE OPTO EMITTER ASSEMBLY 237-5880-02 SCREW, #6 X 1/2 PPH T-25 523-0005-00 ACCELERATOR OPTO PROTECTOR... -
Page 58: Specifications
SPECIFICATIONS 6. SPECIFICATIONS 500-55J6-01 SPECIFICATIONS, MECHANICAL, GAME SETUP SPECIFICATIONS, ENVIRONMENT Specification Imperial Metric Minimum Maximum Weight 210 lbs 96 kg Temperature, Operating 32 ℉ / 0 ℃ 104℉ / 40 ℃ Max dimensions, leg lev- 78 x 27.75 x 57 in 198 x 70.5 x 145 cm Temperature, Storage 32 ℉... -
Page 59: Warranty
Stern Pinball Inc (‘SELLER’) warrants only to the initial purchaser of its that can lead to injury from falling down or striking nearby objects. - Page 60 1-800-KICKERS STAR WARS LE #500-55J6-01 STAR WARS PREMIUM #500-55J7-01 PARTS.SERVICE@STERNPINBALL.COM MANUAL #780-50J6-00 WWW.STERNPINBALL.COM *780-50J6-00* FACEBOOK.COM/STERNPINBALL...
