Add Points to a Saved Survey

1. Set up on the last instrument position occupied when the original survey was
mapped.
2. Power on all equipment.
3. Open QuickMap and tap [Saved Surveys].
4. Zero the TruAngle:
If there was only one instrument position in the survey (the Origin), aim the
laser at the original reference point for the survey and zero the TruAngle on
that point.
If there was more than one instrument position in the survey, aim the laser at
the previous instrument position (not the original reference) and zero the
TruAngle on that point. NOTE For help with zeroing a TruAngle, see Slide 21.
5. Begin adding new data points to the survey. To verify that you have correctly re-
entered the survey, shoot in a point that was mapped in the original survey. The
new point should be on top of or very close to the point shot in the original
survey.
TruPulse 200X or TruSpeed Sxb + TruAngle
