65E10/20 Reversing Hook-Up Diagram; 65E10/20E Hook-Up Diagram - DART Controls 65E Series Instruction Manual

Current
Min Speed
Limit Trip
Output
Max Speed
Accel
IR Comp.
Current Limit
Caution: When reversing a spinning motor, care must be taken that the resulting current through the armature
of the motor does not exceed the overload ratings of the control, or the demagnetize rating of the motor being
reversed when using a permanent magnet DC motor.
Fuse
Battery
-

65E10/20 REVERSING HOOK-UP DIAGRAM

Optional customer
supplied CL output relay
12V Relay Coil
IN4001 thru 4007
P2
Inhibit (P2-5) -5
Common (P2-4) -4
Pot Low (P2-3) -3
Pot Wiper (P2-2) -2
Pot High (P2-1) -1
-Arm (P1-4)
-4
+Arm (P1-3)
-3
+Battery (P1-2) -2
-Battery (P1-1)
-1
P1

65E10/20E HOOK-UP DIAGRAM

RED
RED
RED
RED
Motor
-
Gnd
Optional
Inhibit
(see hook-up
below)
5KΩ
Speedpot
Orange
Red
White
Fuse
Customer
supplied
SPST switch
or relay +
Battery
-
WHITE
ORANGE
Optional
Inhibit
(see hook-up
below)
5
Customer supplied
3PDT Center-off
Center-blocked switch
Motor
RED
