T
ECHNICAL INFORMATION
Models No.
Description
C
ONCEPTION AND MAIN APPLICATIONS
This nibbling machine is developed to extend market in metal
industry especially for stainless steel cutting machines.
The main body is double insulated, small and light.
It's designed with lever switch for easy use.
S
pecifications
Voltage(V)
100
Maximum capacities
Cutting width(mm)
Prepared hole(mm)
Minimum cutting
radius(mm)
Strokes per minute
Overall length(mm)
Net weight(kg)
Power supply cord
S
tandard equipment
Hex spaner 3 -
Wrench holder 3-7 - 1 piece
The standard equipment for the tools shown may differ form country to country
JN1600
Makita 1.6mm Nibbler
Current(A)
3.2
Soft steel plate
Stainless steel
inside
Outside
1 piece
Cycle (Hz)
50/60
1.6mm
1.2mm
8mm
18mm or more
7mm
15mm
2200/min.
245mm
1.5kg
2m
New Tool
Continuous rating input
300 W
Advertisement
Table of Contents
Related Manuals for Makita JN1600
Summary of Contents for Makita JN1600
- Page 1 ECHNICAL INFORMATION New Tool Models No. JN1600 Description Makita 1.6mm Nibbler ONCEPTION AND MAIN APPLICATIONS This nibbling machine is developed to extend market in metal industry especially for stainless steel cutting machines. The main body is double insulated, small and light.
- Page 2 epair Disassembling and assembling 1) Changing punch and die To take off the die, loosen the fastening screw with attached hexagon socket screw key. Secondary, pull out the punch by turning the screw counterclockwise with a wrench (13mm). Fasten both the screw and the Locking screw locking screw tightly (see the right fig.).
