Master CLOUD SYNCRO 230V Instruction Manual

Chain operated actuator
Hide thumbs
Table of Contents

Advertisement

Quick Links

CLOUD SYNCRO
____
CHAIN OPERATED ACTUATOR
F
300 N -
400
ORCE
MAXIMUM STROKE
MM
E
230VAC 50 H
LECTRICAL FEEDING
Z
24V
OR
DC
INSTRUCTION MANUAL
ENGLISH
Third edition - 2014/01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CLOUD SYNCRO 230V and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Master CLOUD SYNCRO 230V

Summary of Contents for Master CLOUD SYNCRO 230V

  • Page 1 CLOUD SYNCRO ____ CHAIN OPERATED ACTUATOR 300 N - ORCE MAXIMUM STROKE 230VAC 50 H LECTRICAL FEEDING INSTRUCTION MANUAL ENGLISH Third edition - 2014/01...

  • Page 2: Table Of Contents

    “presumed in conformity with directives” issued by the EU. MASTER holds the technical file with all the documentation to show that our products have all been inspected to ensure compliance with directives conformity.

  • Page 3: Safety Indications

    1. Safety indications ATTENTION PLEASE READ THE FOLLOWING SAFETY INDICATIONS CAREFULLY BEFORE ATTEMPTING INSTALLATION OF THIS APPLIANCE THESE INDICATIONS WILL HELP TO AVOID CONTACT WITH ELECTRICAL CURRENT INJURY AND OTHER ACCIDENTS PLEASE KEEP THIS MANUAL FOR FUTURE CONSULTATION The CLOUD SYNCRO chain operated actuator has been designed exclusively for moving windows.

  • Page 4: Formulas And Recommendations For Installation

    Check that limit switch selection is less than at least one centimetre with respect to the mechanical stops, limit switches or any eventual obstacles preventing opening of the wing. In the event of damage or malfunction, switch off the device, disconnect any electrical connections and request the intervention of a qualified technician.

  • Page 5: Use Of Cloud Syncro

    Selection of actuator stroke Mode of installation Light domes, skylights or vertical top hung windows opening outwards with frontal assembly Top hung windows opening outwards with horizontal assembly Bottom hung windows (motor on frame) Bottom hung windows (motor on sash) Consult manufacturer 3.

  • Page 6: Technical Data

    • Instruction manual. Note: brackets for bottom hung (ref. C) and top hung (ref. D) windows have to be requested apart. 5. Technical data CLOUD CLOUD MODEL SYNCRO 230V SYNCRO 24V Pressure force 300 N Traction force 300 N Track runs (can be selected at any time) 100, 200, 400 mm Voltage 230VAC 50 Hz...

  • Page 7: Section Choice Of Supply Cables

    1. CLOUD S 230VAC: runs on grid tension of 110/230V~ (a.c.), 50/60Hz YNCRO (±10%), with a five wire cable (L , common neutral; B , phase IGHT LACK open; B , phase closed). The additional wiring (R and W ) is for ROWN HITE electronic synchronisation (NEKOS Patent).

  • Page 8: Assembly With Outward Opening Window

    Check that once the actuator has been installed the distance between the fixed part of the window frame (where the actuator is to be assembled) and the mobile part of the window frame (where the bracket is to be fixed) is greater than or equal to 0 mm (Fig. 1). If this is not the case the actuator will not function correctly as the window will not close correctly.

  • Page 9: Assembly On Transom Window

    J. Check that the exit on the chain is perfectly aligned with the bracket. If the chain is not aligned with the bracket, loosen the fixing screws and reposition the bracket correctly. K. Check all electrical connections with the diagram on the label attached to the lead.

  • Page 10: Electrical Connections

    J. Rotate the actuator 90°, bring the chain terminal up to the bracket and insert the pin into the opening on the bracket. Insert the rapid release hook into the bracket. K. Check that the exit on the chain is perfectly aligned with the bracket.

  • Page 11: Programming The Actuator

    10. Programming the actuator 10.1. Limit switches at opening The actuators leave the factory programmed and synchronized in pairs, thus the user only needs to select the desired stroke. It is recommended that you check to ensure that all the chains are in the same position and the actuators are connected properly as per paragraph 9.

  • Page 12: Setting For Synchronized Operation (Chain Alignment And Address Acquisition)

    • Isolate the actuators from the power source. • Remove the chains from the attachment of the window. • Position the dip-switches of the machine as shown in the table below. Dip-switch No. 1 No. 2 No. 3 No. 4 •...

  • Page 13: Light Signals Of The Led (For Cloud Syncro)

    • Power the machines again in any direction. • The machines now communicate with one another and acquire an address. The LED (near the Dip-switches) of each machine begins to flash in relation to its address; ensure that the LEDs flash with different numbers of flashes (machine No.1 flash –...

  • Page 14: Troubleshooting

    1. Release the rapid release hook locking the chain terminal to the bracket. 2. Hold the window with one hand and pull the pin out of the opening with the other hand. 3. Manually open the window frame. – the window could fall as the TTENTION DANGER sash is no longer held in position by the chain.

  • Page 15: Certificate Of Conformity

    The total or partial removing of the sticker label (with the identification code of the article) invalidates the warranty. Before the intervention of an authorized technician, the buyer has to prove the presence of the original power cable, that must be no shorter than 30 cm Page 15...
  • Page 16 MASTER S.r.l. s.p.37 Conversano-Castiglione km. 0,7 - z.i. 70014 Conversano (Bari) Italy – C.P. 81 - ITALY +39 080.4959823 +39 080.4959030 – Fax info@masteronline.biz http://www.masteronline.biz I461A – 06/07/2015 Page 16...
