OPERATOR'S MANUAL
HOLMAN CONVEYOR TOASTERS
FOR SERVICE INFORMATION
U.S. AND CANADA CALL: 1-800-264-7827
24 HOURS/DAY 7 DAYS/WEEK
TABLE OF CONTENTS
DRAWINGS
PAGE 1
PAGE 1
PAGE 2
PAGE 2A
PAGE 3, 4
PAGE 4
PAGE 5, 6
PAGE 7, 8, 9
PAGE 10, 11, 12, 13
PAGE 1
PAGE 1
PAGE 3
PAGE 6
PAGE 7
PAGE 9
PAGE 15, 16
PAGE 16, 17
PAGE 18
PAGE 19
PAGE 20
REV. 1/31/2011
Advertisement
Related Manuals for Holman T710
Summary of Contents for Holman T710
- Page 1 OPERATOR'S MANUAL HOLMAN CONVEYOR TOASTERS MODELS T710(H, TW, TX) T714(H, TW, TX) S710(H) S714(H) B710H FOR SERVICE INFORMATION U.S. AND CANADA CALL: 1-800-264-7827 24 HOURS/DAY 7 DAYS/WEEK TABLE OF CONTENTS UNCRATING AND INSPECTION PAGE 1 ASSEMBLY AND INSTALLATION PAGE 1...
- Page 2 Page 1 OPERATOR'S MANUAL HOLMAN CONVEYOR TOASTERS MODELS T710(H, TW, TX) T714(H, TW, TX) S710(H) S714(H) B710H UNCRATING AND INSPECTION Unpack unit and components from container. Remove all visible packing material, inspect unit for damage. If damage is discovered, file a claim immediately with the carrier that handled the shipment.
- Page 3 Page 2 OPERATOR'S MANUAL HOLMAN CONVEYOR TOASTERS MODELS T710(H, TW, TX) T714(H, TW, TX) S710(H) S714(H) B710H OPERATION Your Holman toaster may be equipped with a Power Saver Switch, details are as follow; POWER SAVER SWITCH FULL POWER TOGGLE POWER SAVER...
- Page 4 HOLMAN CONVEYOR TOASTERS MODELS S710(H), S714(H) SECURITY COVER : Your Holman models S710 and S714 are quipped with a full front key locking cover (fig.1). This over fits over the front and sides of the unit. The security cover must be removed with a key in order to gain access to the controls, side panels, legs and toast chute to be removed.
- Page 5 HOLMAN CONVEYOR TOASTERS MODELS T710(H, TW, TX) T714(H, TW, TX) S710(H) S714(H) B710H COOKING PROCEDURES A. BREAD TOASTING NOTE: Models TX710(H) and TX714(H) have an extended conveyor belt in lue of a load up tray. Place (do not press) the product on the extended conveyor belt for toasting or heating.
- Page 6 HOLMAN CONVEYOR TOASTERS MODELS T710(H, TW, TX) T714(H, TW, TX) S710(H) S714(H) B710H COOKING PROCEDURES CONT. C. MODEL B710(H) The model B710(H) has higher wattage tubes on the top than on the bottom, therefore when placing the bun halves on the conveyor you should place them cut side up.
- Page 7 HOLMAN CONVEYOR TOASTERS MODELS T710(H, TW, TX) T714(H, TW, TX) S710(H) S714(H) B710H TROUBLESHOOTING GUIDE A. UNIT WILL NOT HEAT, CONVEYOR WILL NOT TURN. 1. Be sure the main circuit breaker is switched to the ON position. 2. Check to see if the toaster is plugged in and all controls are turned to the ON position.
- Page 8 HOLMAN CONVEYOR TOASTERS MODELS T710(H, TW, TX) T714(H, TW, TX) S710(H) S714(H) B710H TROUBLESHOOTING GUIDE CONT. 3. Check if crumb tray is in place. NEVER OPERATE UNIT WITHOUT CRUMB TRAY IN PLACE AS THIS CAUSES OVERHEATING IN THE CONTROL BOX.
- Page 9 HOLMAN CONVEYOR TOASTERS MODELS T710(H, TW, TX) T714(H, TW, TX) S710(H) S714(H) B710H MAINTENANCE PROCEDURES A. REPLACING HEATER TUBES (as below) 1. DISCONNECT UNIT FROM POWER SOURCE. 2. Remove right and left side panels. 3. Remove heater tube wire from terminal block connection, keeping top and bottom wires separate.
- Page 10 HOLMAN CONVEYOR TOASTERS MODELS T710(H, TW, TX) T714(H, TW, TX) S710(H) S714(H) B710H MAINTENANCE PROCEDURES (CONT.) B. REPLACING FAN MOTOR 1. DISCONNECT UNIT FROM POWER SOURCE. 2. Remove control box cover with fan motor. 3. Unplug power supply cord from fan motor.
- Page 11 PAGE 9 OPERATOR'S MANUAL HOLMAN CONVEYOR TOASTERS MODELS T710(H, TW, TX) T714(H, TW, TX) S710(H) S714(H) B710H MAINTENANCE PROCEDURES (CONT.) REPLACING BELT DRIVE MOTOR 1. DISCONNECT UNIT FROM POWER SOURCE. 2. Remove right side panel and control box covers. 3. Remove sprocket from motor shaft.
- Page 12 PAGE 10 OPERATOR'S MANUAL HOLMAN CONVEYOR TOASTERS MODELS T710(H, TW, TX) T714(H, TW, TX) S710(H) S714(H) B710H PARTS LIST /EXPLODED VIEW MODEL T710(H), 120, 208, 240 VOLT Model: T710 (H) 120, 208, 240V PART No. DESCRIPTION PART No. DESCRIPTION HO-400821...
- Page 13 PAGE 11 OPERATOR'S MANUAL HOLMAN CONVEYOR TOASTERS MODELS T710(H, TW, TX) T714(H, TW, TX) S710(H) S714(H) B710H PARTS LIST /EXPLODED VIEW MODEL TX710(H) 120, 208, 240 VOLT Model: TX710 (H) 120, 208, 240V PART No. QTY. DESCRIPTION PART No. QTY.
- Page 14 PAGE 12 OPERATOR'S MANUAL HOLMAN CONVEYOR TOASTERS MODELS T710(H, TW, TX) T714(H, TW, TX) S710(H) S714(H) B710H PARTS LIST /EXPLODED VIEW MODEL T714(H) Model: T714 (H) PART # DESCRIPTION PART # DESCRIPTION GC-400847 Top Cover 2U-200560 Fan Motor HT-197850 Heater Tube, 240 Volt...
- Page 15 PAGE 13 OPERATOR'S MANUAL HOLMAN CONVEYOR TOASTERS MODELS T710(H, TW, TX) T714(H, TW, TX) S710(H) S714(H) B710H PARTS LIST /EXPLODED VIEW MODEL TX714(H) Model: T714 (H) PART # DESCRIPTION PART # DESCRIPTION GC-400847 Top Cover 2U-200560 Fan Motor HT-197850 Heater Tube, 240 Volt...
- Page 16 PAGE 14 OPERATOR'S MANUAL HOLMAN CONVEYOR TOASTERS MODELS T710(H, TW, TX) T714(H, TW, TX) S710(H) S714(H) B710H PARTS LIST /EXPLODED VIEW MODEL TX710(H), 208, 240 VOLT Model: TX710 (H) 120, 208, 240V METAL ELEMENTS PART No. DESCRIPTION PART No. QTY.
- Page 17 PAGE 15 OPERATOR'S MANUAL HOLMAN CONVEYOR TOASTERS MODELS T710(H, TW, TX) T714(H, TW, TX) S710(H) S714(H) B710H WIRING DIAGRAM FOR MODEL T710(H & TW) 120 VOLT TX710(H) 120 VOLT WIRE DIAGRAM FOR MODEL T710(H), TX710(H) - 120 VOLT PLUG CONFIGURATION...
- Page 18 PAGE 16 OPERATOR'S MANUAL HOLMAN CONVEYOR TOASTERS MODELS T710(H, TW, TX) T714(H, TW, TX) S710(H) S714(H) B710H WIRING DIAGRAM FOR MODEL T710(H & TW) 208, 240 VOLT TX710(H) 208, 240 VOLT T714(H) 208, 240 VOLT (3.2 KW) BLUE 220/240 WHITE...
- Page 19 MODELS T710(H, TW, TX) T714(H, TW, TX) S710(H) S714(H) B710H WIRING DIAGRAM FOR MODEL T714(H & TW) TX714, 3.6 kW 208, 240 VOLTS, WIRED PARELLEL PLUG CONFIGURATION NEMA 6-30P REVISED 9/10/2008 PAGE 18 OPERATOR'S MANUAL HOLMAN CONVEYOR TOASTERS MODELS T710(H, TW, TX) T714(H, TW, TX) S710(H) S714(H) B710H...
- Page 20 High Limit Reset Reset Cooling Cooling Plug Configuration NEMA 5-20P 120V GROUND REVISED 9/10/2008 PAGE 19 OPERATOR'S MANUAL HOLMAN CONVEYOR TOASTERS MODELS T710(H, TW, TX) T714(H, TW, TX) S710(H) S714(H) B710H WIRING DIAGRAM FOR MODEL S710(H), 120, 208, 240 VOLT...
- Page 21 MODEL TX710 WITH OUT POWER SAVER 120, 208, 240 VOLT PLUG CONFIGURATION NEMA 5-15P NEMA 6-20P 120 VOLT 208/240 VOLT REVISED 9/10/2008 PAGE 20 OPERATOR'S MANUAL HOLMAN CONVEYOR TOASTERS MODELS T710(H, TW, TX) T714(H, TW, TX) S710(H) S714(H) B710H WIRING DIAGRAM FOR MODEL S714(H) 208, 240 VOLT...
- Page 22 PLUG CONFIGURATION NEMA 6-30P REVISED 9/10/2008...
