Glencrest Ceiling Fan
User Guide
RATED FOR DAMP
CONDITIONS

Advertisement

loading

  Related Manuals for Honeywell Glencrest

  Summary of Contents for Honeywell Glencrest

  • Page 1 Glencrest Ceiling Fan User Guide RATED FOR DAMP CONDITIONS...
  • Page 2: Package Contents

    PACKAGE CONTENTS Canopy Canopy Cover Mounting Bracket Screw (x 4) Mounting Bracket Downrod Downrod Clip Downrod Pin Yoke Cover Closemount Set Screw (x 2) Screw (x 3) Motor Assembly Blade (x 5) Fitter Plate Screw (x 3) Blade Arm (x 5) Fitter Plate Motor Screw (x 10) Light Pan...
  • Page 3: Safety Information

    SAFETY INFORMATION Please read and understand this entire manual before attempting to assemble, operate or install the product. • Before you begin installing the fan, disconnect the power by removing fuses or turning off the circuit breakers. • Make sure all electrical connections comply with local codes, ordinances, the National Electrical Code Hire an electrician or consult a do-it-yourself handbook if you are unfamiliar with installing electrical wiring.
  • Page 4: Initial Installation

    PREPARATION Before beginning the assembly of this product, ensure all parts are present. Compare all parts with the package contents list and hardware contents list. If any part is missing or damaged, do not attempt to assemble the product. Estimated assembly time: 2 hours Tools required (not included): Electrical tape, Phillips Screwdriver, Safety Glasses, Step Ladder, and Wire Strippers.
  • Page 5 STANDARD OR ANGLE MOUNT INSTRUCTIONS 1. Remove the downrod clip and downrod pin from the downrod. Then partially loosen the set screws in the yoke at the top of the motor assembly (Figure 3.1). 2. Feed the fan wires through the yoke cover, canopy and downrod (Figure 3.2). 3.
  • Page 6: Final Installation

    CLOSEMOUNT INSTRUCTIONS (optional) 1. Remove the canopy cover from the bottom of the canopy (Figura 4.1). 2. Remove the three Phillips-head closemount screws from the top of the motor assembly. Then align the canopy with the holes in the top of the motor assembly. The larger holes in the canopy will encompass the remaining screws. Secure the canopy to the top of the motor assembly with the previously removed closemount screws (Figura 4.2).
  • Page 7 FINAL INSTALLATION 4. Partially insert the blade screws along with blade washer through blade and into the blade arm. Tighten each blade screw starting with the one in the middle. Repeat this step for the remaining blades and blade arms (Figure 5.4). 5.
  • Page 8 FINAL INSTALLATION Feed the pull chains through the off-center holes of the glass bowl. Lift the glass bowl onto the threaded rod of the light kit and secure it using the rubber washer and hex nut. Lift the finial cap over the threaded rod and secure it with the finial (Figure 5.10).
  • Page 9: Troubleshooting

    TROUBLESHOOTING Warning: Shut off the power supply before you begin any maintenance task. PROBLEM CORRECTIVE ACTION 1. Firmly push the reverse switch completely left or right. 2. Make sure the wall switch is turned on. The fan does not move. 3.
  • Page 10: Limited Lifetime Warranty

    LIMITED LIFETIME WARRANTY Set forth below, the manufacturer, warrants the fan motor for this ceiling fan to be free from defects in workmanship and material for the life of the product. Also, subject to the limitations below, warrants all ceiling fan parts (“ceiling fan parts” excludes the motor and parts made in whole or in part with glass) to be free from defects in workmanship and material for a period of one year after the date of purchase by the original purchaser at retail.
