FOREWORD
This manual is an essential part of your
vehicle and should remain with the vehicle
when resold or otherwise transferred to a
new owner or operator. Please read this
manual carefully before operating your
new MARUTI SUZUKI and review the
manual from time to time. It contains
important information on safety, operation
and maintenance. You are invited to avail
the three Free Inspection Services as
described in the manual. Three free
inspection coupons are attached to this
manual. Please show this manual to your
dealer workshop while you take your
MARUTI SUZUKI for any Service.
To prolong the life of your vehicle and
reduce maintenance cost, the periodic
maintenance must be carried out accord-
ing
to
"PERIODIC
MAINTENANCE
SCHEDULE" described in "INSPECTION
AND MAINTENANCE" section of this man-
ual. It is essential for preventing trouble
and accidents to ensure your satisfaction
and safety.
Daily inspection and care as per "DAILY
INSPECTION CHECKLIST" described in
the "OPERATING YOUR VEHICLE" sec-
tion of this manual is essential for prolong-
ing the life of the vehicle and for safe
driving.
Vehicle and the available features/acces-
sories therein should be used and plied by
the owner/user in accordance with the
applicable legal requirements.
MARUTI SUZUKI INDIA LIMITED believes
in conservation and protection of Earth's
natural resources.
To that end, we encourage every vehicle
owner to recycle, trade-in or properly dis-
pose of, as appropriate, used Engine Oil,
coolant and other fluids, batteries and
tyres etc.
MARUTI SUZUKI INDIA LIMITED
All information in this manual is based
on the latest product information avail-
able at the time of publication. Due to
improvements or other changes, there
may be discrepancies between informa-
tion in this manual and your vehicle.
MARUTI
SUZUKI
INDIA
LIMITED
reserves the right to make production
changes at any time, without notice and
without incurring any obligation to
make the same or similar changes to
vehicles previously built or sold.
This vehicle may not comply with stan-
dards or regulations of other countries.
Before attempting to register this vehi-
cle in any other country, check all appli-
cable regulations and make any neces-
sary modifications.
