MARUTI SUZUKI Tour S Manual

MARUTI SUZUKI Tour S Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

FUEL RECOMMENDATION

FUEL RECOMMENDATION
1
Fuel Recommendation ........................................................ 1-1
65D394
56RH0-74E

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Tour S and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for MARUTI SUZUKI Tour S

Summary of Contents for MARUTI SUZUKI Tour S

  • Page 1: Fuel Recommendation

    FUEL RECOMMENDATION FUEL RECOMMENDATION Fuel Recommendation ............1-1 65D394 56RH0-74E...
  • Page 2 FUEL RECOMMENDATION Fuel Recommendation NOTICE Petrol engine The fuel tank has an air space to To avoid damaging catalytic converter you allow for fuel expansion in hot must use unleaded petrol with an octane weather. If you continue to add fuel number (RON) of 91 or higher.

  • Page 3: Table Of Contents

    BEFORE DRIVING BEFORE DRIVING Keys ..................2-1 Door Locks ................2-2 Keyless Entry System Transmitter ........2-3 Security System ..............2-4 Transmitter Battery ..............2-10 Windows ..................2-13 Mirrors ..................2-14 Front Seats ................2-14 Seat Belts and Child Restraint Systems ......2-16 Supplemental Restraint System (Air bags) ......2-26 Instrument Cluster ..............2-32 Speedometer ................2-33 Fuel Gauge ................2-33...

  • Page 4: Keys

    Ask opened. KEY NUMBER: your Maruti Suzuki authorised workshop to have the system inspected. NOTE: Immobilizer System • If you lose your immobilizer ignition key, This system is designed to help prevent...

  • Page 5: Door Locks

    Keys: 8 BEFORE DRIVING Door Locks To lock a door from inside the vehicle, turn the lock knob forward. Turn the lock knob EXAMPLE Side Door Locks backward to unlock the door. To lock a rear door from outside the vehi- UNLOCK cle, turn the lock knob forward and close LOCK...

  • Page 6: Keyless Entry System Transmitter

    Door Locks: 3, 5, 8 BEFORE DRIVING Keyless Entry System NOTE: WARNING You can also lock or unlock all doors by Transmitter operating the transmitter. Refer to “Keyless Always make sure that the trunk lid is Entry System Transmitter” in this section. fully opened before using the lug- EXAMPLE NOTE:...

  • Page 7: Security System

    • If you lose one of the transmitters, ask your Maruti Suzuki authorised workshop as soon as possible for a replacement. Be sure to have your dealer program the new transmitter code in your vehicle’s memory so that the old code is erased.
  • Page 8 Door Locks: 3, 5, 8 BEFORE DRIVING Arm Stage 3) System will not Lock/Arm in following Disarm Stage In Arm Stage, your vehicle is monitored for conditions. System should be brought in Disarm Mode any unauthorized entry. In order to arm, a) If any of door is open.
  • Page 9 Door Locks: 3, 5, 8 BEFORE DRIVING GENERAL FEATURES Mute Lock/Unlock Radio Frequency Lock Out To Lock/Unlock the vehicle without siren Key Lock/Unlock/Car locator function will Illuminated Entry chirps use this function. cease to function when Key is inside Key When vehicle is unlocked, the room lamp a) Press and release the Key LOCK &...
  • Page 10 Door Locks: 3, 5, 8 BEFORE DRIVING Flashing LED Status PROGRAMMABLE FEATURES Siren Chirp ON/OFF feature The flashing LED always reflects the sta- System has some features which can be Siren Chirps can be programmed to ON or tus of the system as following. OFF.
  • Page 11 Door Locks: 3, 5, 8 Windows: 3, 8 BEFORE DRIVING Programming Drive Lock Mode Programming Drive Unlock Mode Programming Siren Chirp ON/OFF a) Open the Driver Door of your vehicle. a) Open the Driver Door of your vehicle. a) Open the Driver Door of your vehicle. b) With your vehicle key in the Key cylin- b) With your vehicle key in the Key cylin- b) With your vehicle key in the Key cylin-...
  • Page 12 Windows: 3, 8 BEFORE DRIVING Programming Shock Sensor ON/OFF Shock Sensor Sensitivity Adjustment Pre-warn Adjustment via Key a) Open the Driver Door of your vehicle. Pre-warn can be adjusted in 16 levels as mentioned below: b) With your vehicle key in the Key cylin- Full Blast adjustment der, turn Ignition ON and then switch it a) Press Lock button on Key to Lock/Arm...

  • Page 13: Transmitter Battery

    Windows: 3, 8 BEFORE DRIVING Transmitter battery Pin code entry Emergency Disarm by Personalized pin code a) Disarm the system. Replacement of the Battery The Personalized 4- Digit Pin Code acts as b) Open the Driver Door. a secret Key, to Emergency Disarm the EXAMPLE c) Turn Ignition ON then OFF.
  • Page 14 Normal battery life is approximately 2 years, but varies depending on usage. It is WARNING advisable to get battery replaced from Maruti Suzuki authorised workshop. Swallowing a lithium battery may cause serious internal injury. Do not allow anyone to swallow a lithium battery.
  • Page 15 Mirrors: 3, 8 Seat Adjustment: 3 BEFORE DRIVING TROUBLESHOOTING SYMPTOMS PROBABLE CAUSES REMEDIES Transmitter function (Unlock/Lock/car 1. Battery of the transmitter is weak. 1. Check the battery. locator function) not working 2. Transmitter is exposed to water or it is 2.

  • Page 16: Windows

    BEFORE DRIVING Windows The driver’s door has a switch (1) to oper- The driver’s window has an “auto-down” ate the driver’s window, and a switch (2) to feature for added convenience (at toll Manual Window Control operate the front passenger’s window. booths or drive-through restaurants, for example).

  • Page 17: Mirrors

    BEFORE DRIVING Mirrors WARNING EXAMPLE Inside Rearview Mirror • You should always lock the pas- senger’s window operation when EXAMPLE there are children in the vehicle. Children can be seriously injured if they get part of their body caught by the window during operation. •...
  • Page 18 BEFORE DRIVING Adjusting Seat Position Adjusting Seatbacks WARNING WARNING To avoid excessive seat belt slack, which reduces the effectiveness of All seatbacks should always be in an the seat belts as a safety device, upright position when driving, or seat make sure that the seats are adjusted belt effectiveness may be reduced.

  • Page 19: Seat Belts And Child Restraint Systems

    BEFORE DRIVING Adjustable Head Restraints Front Seat Belts and Child Restraint Systems EXAMPLE EXAMPLE EXAMPLE 80JS082 To raise the front head restraint, pull upward on the restraint until it clicks. To lower the restraint, push down on the 65D231 63J246 restraint while holding in the lock lever.
  • Page 20 BEFORE DRIVING EXAMPLE EXAMPLE EXAMPLE as low as possible across the hips Above the pelvis Across the pelvis 65D606 65D201 65D199 WARNING WARNING WARNING • Never allow persons to ride in the (Continued) (Continued) cargo area of a vehicle. In the event •...
  • Page 21 BEFORE DRIVING Lap-Shoulder Belt WARNING WARNING Emergency Locking Retractor (ELR) (Continued) (Continued) (if equipped) • Never use the same seat belt on • For children, if the shoulder belt The seat belt has an emergency locking more than one occupant and never irritates the neck or face, move the retractor (ELR), which is designed to lock attach a seat belt over an infant or...
  • Page 22 BEFORE DRIVING All Seat Belts Except Rear Center the belt slowly while attaching a hand to the belt or/and the latch plate. EXAMPLE EXAMPLE Low on hips Rear Center Seat Belt Lap belt TO TIGHTEN 60A040 Low on hips To reduce the risk of sliding under the belt during a collision, position the lap portion of the belt across your lap as low on your 60A036...
  • Page 23 BEFORE DRIVING NOTE: EXAMPLE The word “CENTER” is marked on the WARNING TO LOOSEN buckle and latch plate of the center lap It is absolutely essential that the belt. The buckles are designed so a latch driver and passengers wear their seat plate can not be inserted into the wrong belts at all times.
  • Page 24 MARUTI SUZUKI highly recommends that you use MARUTI SUZUKI genuine seat cover exclusively for this vehi- cle. • If you spill liquid such as liquid aro- matics, soft drinks or juice on the front passenger’s seat cushion, the sensor of the front passenger’s...
  • Page 25 NOTE: sioners activated. The airbags, the Maruti Suzuki recommends use of Maruti pretensioners and the load limiter will Suzuki Genuine accessory of “Seat cover”. only function once. In case they did not activate, consult with the Maruti Suzuki authorised workshop.
  • Page 26 Do not install a child restraint system on the front passenger's seat. 80JC007 80JC008 MARUTI SUZUKI highly recommends that you use a child restraint system to restrain infants and small children. Many different types of child restraint systems are avail-...
  • Page 27 BEFORE DRIVING Installation with Lap-Shoulder Seat WARNING WARNING Belts If you install a child restraint system Children could be endangered in a ELR type belt in the rear seat, slide the front seat crash if their child restraint systems EXAMPLE for enough forward so that the child’s are not properly secured in the vehi- feet do not contact the front seat-...
  • Page 28 BEFORE DRIVING Child Restraint System for India Child Restraint The suitability of each passenger’s seat position for carriage of children and fitting of child restraint system is shown in the table below. Whenever you carry children up to 12 years of age, properly use the child restraints which conform to AIS 072, the standard for child restraints, referring to the table.

  • Page 29: Supplemental Restraint System (Air Bags)

    Supplemental restraint EXAMPLE system (air bags) WARNING This section describes the protection provided by your MARUTI SUZUKI vehicle’s supplemental restraint sys- tem (air bags). Read and follow all instructions carefully to minimize your risk of severe injury or death in the event of a crash.
  • Page 30 Have system If the AIRBAG light in the instrument inspected by a Maruti Suzuki authorised cluster ever comes on and stays on, workshop as soon as possible. it means that something may be wrong with the airbag system. If this...
  • Page 31 Driver’s front air bag the air bag covers to identify the location of lision. ;Have your vehicle inspected the air bags. by a Maruti Suzuki authorised work- shop. Refer to “Seat belts and child restraints systems” section for details on securing your child.
  • Page 32 BEFORE DRIVING EXAMPLE EXAMPLE EXAMPLE 80J102 80J098E 80J100E • Frontal collision to a stopped vehicle at • Strong impact equivalent to frontal colli- less than about 50 km/h. • Falling into a deep hole or ditch. sion such as above at left and right EXAMPLE EXAMPLE angles of about 30 degrees (1) or less...
  • Page 33 BEFORE DRIVING How the system works EXAMPLE EXAMPLE In a frontal crash, the crash sensors will detect rapid deceleration, and if the con- troller judges that the deceleration rep- resents a severe frontal crash, the controller will trigger the inflators. The infla- tors inflate the appropriate air bags with nitrogen or argon gas.
  • Page 34 EXAMPLE age, have the air bag system inspected by tended air bag deployment or could render a Maruti Suzuki authorised workshop to the air bag inoperative. Either of these two ensure that it works properly. conditions may result in severe injury.

  • Page 35: Instrument Cluster

    BEFORE DRIVING Instrument Cluster 1. Speedometer 2. Fuel gauge 3. Temperature gauge 4. Information display 5. Trip meter selector knob 6. Indicator selector knob 7. Warning and indicator lights EXAMPLE 74LM02018 2-32 74LH0-74E...

  • Page 36: Speedometer

    BEFORE DRIVING Speedometer Fuel Gauge When the low fuel warning light (1) comes on, a ding sounds once to remind you to fill the fuel. EXAMPLE EXAMPLE If you do not fill the fuel, a ding sounds every time when the ignition switch is turned to “ON”...

  • Page 37: Temperature Gauge

    BEFORE DRIVING Temperature Gauge Brightness Control NOTE: • If you do not turn the brightness control knob within about 5 seconds of activat- EXAMPLE EXAMPLE ing the brightness control display, the brightness control display will be can- celed automatically. • When you reconnect the battery, the brightness of the instrument panel lights will be reinitialized.

  • Page 38: Information Display

    BEFORE DRIVING Information Display Trip meter / Instantaneous fuel con- Push the trip meter selector sumption / Average fuel consump- knob (1). tion / Driving range EXAMPLE When the ignition switch is in the “ON” Push the indicator selector position, the display (A) shows one of the knob (2).
  • Page 39 BEFORE DRIVING while when the display shows the trip actual instantaneous fuel consumption is average fuel consumption, the display indi- meter. higher. cates the value of average fuel consump- • The indication on the display may be tion which includes average fuel NOTE:...
  • Page 40 BEFORE DRIVING NOTE: NOTE: blinks. To change the hour indication Depending on the vehicle’s specification, • If you refuel when the ignition switch is in quickly, turn and hold the indicator the fuel consumption units of initial setting the “ON” position, the driving range may selector knob (2).

  • Page 41: Warning And Indicator Lights

    If this happens, occur, you should immediately ask you should: your Maruti Suzuki authorised work- 1) Pull off the road and stop carefully. shop to inspect the brake system. • If the brake system warning light...
  • Page 42 ABS system. refer to “Seat Belts and Child Restraint sure to periodically check the Systems” in this section. If one of these happens, have the system engine oil level. inspected by a Maruti Suzuki authorised workshop. 2-39 74LH0-74E...
  • Page 43 Ask your Maruti Suzuki autho- you can check that the light is working. The malfunction indicator light comes on...
  • Page 44 BEFORE DRIVING Low Fuel Warning Light erly. Have the system inspected by your Turn Signal Indicators Maruti Suzuki authorised workshop. NOTE: Following operations of the steering wheel while parking or driving at a very low- speed may have steering effort bigger gradually.

  • Page 45: Lighting Control Lever

    BEFORE DRIVING Lighting Control Lever To turn the lights on or off, twist the knob Light Reminder Buzzer on the end of the lever. There are three A buzzer sounds to remind you to turn off positions: the lights if they are left on when the igni- EXAMPLE tion key is removed and the driver’s door is OFF (1)

  • Page 46: Headlight Leveling Switch

    BEFORE DRIVING Headlight Leveling Switch Turn Signal Control Lever Normal turn signal EXAMPLE EXAMPLE EXAMPLE 74LHT0227 Move the lever all the way upward or 80JM040 downward to signal. When the turn is com- 65D611 Level the headlight beam according to the pleted, the signal will cancel and the lever load condition of your vehicle by turning will return to its normal position.

  • Page 47: Hazard Warning Switch

    BEFORE DRIVING Hazard Warning Switch Windshield Wiper and Washer position is very convenient for driving in mist or light rain. In the “LO” position, the Lever wipers operate at a steady low speed. In EXAMPLE the “HI” position, the wipers operate at a EXAMPLE steady high speed.

  • Page 48: Tilt Steering Lock Lever

    BEFORE DRIVING Tilt Steering Lock Lever WARNING NOTICE EXAMPLE • To prevent windshield icing in cold To help prevent damage to the wind- weather, turn on the defroster to shield wiper and washer system heat the windshield before and components, you should take the fol- during windshield washer use.

  • Page 49: Horn

    BEFORE DRIVING Horn EXAMPLE 68LM240 Press the horn button of the steering wheel to sound the horn. The horn will sound with the ignition switch in any position. 2-46 74LH0-74E...
  • Page 51 OPERATING YOUR VEHICLE OPERATING YOUR VEHICLE Exhaust Gas Warning ............3-1 Daily Inspection Checklist ..........3-1 Engine Oil Consumption ............ 3-2 Ignition Switch..............3-3 Parking Brake Lever ............3-4 Pedal ..................3-5 Starting the Engine .............. 3-6 Using Transaxle ..............3-6 Parking Sensors ..............

  • Page 52: Exhaust Gas Warning

    Exhaust Gas Warning: NO Daily Inspection Checklist: NO OPERATING YOUR VEHICLE Exhaust Gas Warning Daily Inspection Checklist WARNING Before Driving EXAMPLE (Continued) EXAMPLE • Do not park with the engine run- ning for a long period of time, even in an open area. If it is necessary to sit for a short time in a parked vehi- cle with the engine running, make sure the air intake selector is set to...

  • Page 53: Engine Oil Consumption

    Daily Inspection Checklist: NO Engine Oil Consumption: OPERATING YOUR VEHICLE 5) Check the headlights, turn signal lights, Maintenance Schedule” Oil consumption: brake lights and horn for proper opera- “INSPECTION AND MAINTENANCE” Max. 1.0 L per 1000 km tion. section for lubrication schedule. When judging the amount of oil consump- 6) Adjust the seat and adjustable head tion, note that the oil may become diluted...

  • Page 54: Ignition Switch

    Starting the Engine: 1 OPERATING YOUR VEHICLE Ignition Switch LOCK START This is the normal parking position. It is the This is the position for starting the engine only position in which the key can be using the starter motor. The key should be EXAMPLE removed.

  • Page 55: Parking Brake Lever

    Using the Transaxle: 10 OPERATING YOUR VEHICLE Parking Brake Lever WARNING WARNING (Continued) EXAMPLE • Never drive your vehicle with the • Always return the ignition switch to parking brake on: rear brake effec- the “LOCK” position and remove tiveness can be reduced from over- the ignition key when leaving the heating, brake...

  • Page 56: Pedal

    Using the Transaxle: 10 OPERATING YOUR VEHICLE Pedal Brake Pedal (2) WARNING Your MARUTI SUZUKI vehicle is equipped with front and rear drum brakes. Depress- When parking vehicle EXAMPLE ing the brake pedal applies both sets of extremely cold weather, the following brakes.

  • Page 57: Starting The Engine

    Using the Transaxle: 10 Braking: 6 OPERATING YOUR VEHICLE Starting the Engine Using Transaxle Starting a Cold and Warm Engine With your foot off the accelerator pedal, Before Starting the Engine crank the engine by turning the ignition key EXAMPLE to “START”.

  • Page 58: Parking Sensors

    Braking: 6 OPERATING YOUR VEHICLE Parking Sensors Downshifting maximum allowable speeds WARNING • The parking sensor system uses ultra- sonic sensors to detect obstacles near • Reduce your speed and downshift (For Petrol Model) the rear bumper. If obstacles are sensed to a lower gear before going down while you are parking or moving the Downshifting...
  • Page 59 • The sensors can detect an obstacles sensors on it may not work prop- such as wall up to about 1.5 m (5 ft) from erly. If this occurs, have the sen- the rear of vehicle. sors inspected by a Maruti Suzuki authorised workshop. 74LH0-74E...
  • Page 60 OPERATING YOUR VEHICLE • The system may calculate the distance WARNING WARNING to a road sign or similar obstacle to be shorter than the actual distance. Under the following conditions, the (Continued) parking sensor system may not work – Sensors have intercepted ultra- Obstacle indication by parking sensor normally because the sensors cannot sonic noise from another vehi-...

  • Page 61: Braking

    OPERATING YOUR VEHICLE Braking Anti-Lock Brake System (ABS) WARNING ABS will help you avoid skidding by elec- tronically controlling braking pressure. It If water gets into the brake drums, EXAMPLE will also help you maintain steering control brake performance may become poor when braking on slippery surfaces or when unpredictable.
  • Page 62 Drive carefully, avoiding hard be a problem with the ABS system. shorter stopping distances with braking as much as possible. Ask your Maruti Suzuki authorised conventional brake systems than workshop to inspect the ABS sys- with ABS. How the ABS works tem immediately.
  • Page 63 OPERATING YOUR VEHICLE WARNING The ABS may not work properly if tires or wheels other than those specified in the owner’s manual are used. This is because the ABS works by comparing changes in wheel speed. When replacing tires wheels, use only the size and type specified in this owner’s manual.

  • Page 65: Driving Tips

    DRIVING TIPS DRIVING TIPS Running-in ................4-1 Catalytic Converter ............. 4-1 Improving Fuel Economy ........... 4-2 Highway Driving ..............4-3 Driving on Hills ..............4-3 Driving on Slippery Roads ..........4-4 Driving on Wet Roads ............4-5 Do’s & Don’ts for Safe Driving ........... 4-6 Margin for Safety ..............

  • Page 66: Running-In

    DRIVING TIPS Running-in Catalytic Converter EXAMPLE NOTICE EXAMPLE The future performance and reliabil- ity of the engine depends on the care and restraint exercised during its early life. It is especially important to observe the following precautions during the initial 960 km of vehicle operation.

  • Page 67: Improving Fuel Economy

    DRIVING TIPS Improving Fuel Economy NOTICE EXAMPLE The following instructions will help you improve fuel economy. To minimize the possibility of catalyst or other vehicle damage: Avoid excessive idling • Maintain the engine in the proper If you are to wait for more than a minute operating condition.

  • Page 68: Highway Driving

    DRIVING TIPS Keep the air cleaner clean Highway Driving Driving on Hills When driving at high speeds, pay attention EXAMPLE to the following: EXAMPLE • Stopping distance progressively increases with vehicle speed. Apply the brakes far enough ahead of the stopping point to allow for the extra stopping dis- tance.

  • Page 69: Driving On Slippery Roads

    DRIVING TIPS Driving on Slippery Roads Tire Chains WARNING Tire chains should only be used if they are needed to increase traction or are required EXAMPLE Try not to hold the brake pedal down by law. Make sure that the chains you use too long or too often while going are the correct size for your vehicle’s tires.

  • Page 70: Driving On Wet Roads

    2) If your vehicle remains stuck after a few overheating or transaxle damage. minutes of rocking, we recommend you NOTICE to consult your Maruti Suzuki autho- • When driving on wet roads, avoid rised workshop or a roadside assis- driving through large amount of tance service.

  • Page 71: Do's & Don'ts For Safe Driving

    DRIVING TIPS Do’s and Dont’s for Safe 4) Don’t accelerate suddenly, since it is WARNING dangerous and wastes fuel. Driving In addition to following the driving Exercise care in handling your vehicle. Be General driving tips in this section, it is important to conscious of not only your own safety but observe the following precautions.
  • Page 72 DRIVING TIPS 6) Don’t attempt zigzag driving as it will Braking skid and a collision may occur. It is hinder your control over the vehicle and especially dangerous when the tyres EXAMPLE may cause an accident. are worn out as they skid more. 7) Avoid reckless high speed driving and try to drive at a safe speed suitable for EXAMPLE...

  • Page 73: Margin For Safety

    DRIVING TIPS Night time driving 3) Don’t use headlights on high beam Margin for Safety unless its use is inevitable. It may It is important to allow yourself a margin for EXAMPLE cause visual impairment to the driver of safety during driving so that you can cope the oncoming vehicle or the vehicle with erroneous or unexpected driving of ahead of you, which may cause an...
  • Page 74 DRIVING TIPS 67LH3-74E...
  • Page 75 OTHER CONTROLS AND EQUIPMENT OTHER CONTROLS AND EQUIPMENT Fuel Filler Cap ..............5-1 Engine Hood ................ 5-2 Sun Visor ................5-2 Interior Light ................ 5-3 Accessory Socket ............... 5-4 Assist Grips ................. 5-4 Glove Box ................5-4 Floor Mats (if equipped) ............. 5-5 Frame Hooks ...............

  • Page 76: Fuel Filler Cap

    WARNING If you need to replace the fuel cap, EXAMPLE use a MARUTI SUZUKI genuine cap. Use of an improper cap can result in a malfunction of the fuel system or emission control system. It may also result in fuel leakage in the event of an accident.

  • Page 77: Engine Hood

    Pedal: 6 OTHER CONTROLS AND EQUIPMENT Engine Hood Sun Visor tration. While pushing the lever, lift up the engine hood. EXAMPLE EXAMPLE EXAMPLE 79J161 The sun visors can be pulled down to block 63J063 glare coming through the windshield, or To open the engine hood: they can be unhooked and turned to the side to block glare coming through the side...

  • Page 78: Interior Light

    Gearshift Lever: 10 Fuel Filler Cap: 5 OTHER CONTROLS AND EQUIPMENT will remain on for about 15 seconds and Trim Partition NOTICE then fade out. If you insert the key into the EXAMPLE ignition switch during this time, the light will •...

  • Page 79: Accessory Socket

    Fuel Filler Cap: 5 Folding Rear Seat: 3 OTHER CONTROLS AND EQUIPMENT Glove Box When you open the trunk lid, the trunk light NOTICE comes on and remains on as long as you keep the lid open. EXAMPLE Use of inappropriate electrical acces- sories can cause damage to your vehicle’s electrical system.

  • Page 80: Floor Mats (If Equipped)

    To use passenger side cup holder, push it. weather floor mats, we highly recommend The cup holder slides out automatically. using MARUTI SUZUKI genuine floor mats After using the holder, push it back to 74LM05004 for proper fitting.

  • Page 81: Frame Hooks

    OTHER CONTROLS AND EQUIPMENT Frame Hooks storage bag under the spare tyre in the luggage compartment EXAMPLE Front EXAMPLE EXAMPLE 62J161 63J117 4) To tighten the towing hook (1), turn it clockwise by using a wheel brace (B) The towing hook (1) is provided on the 68LM546 until the hook (1) is securely installed.
  • Page 82 OTHER CONTROLS AND EQUIPMENT Rear Other Hooks EXAMPLE NOTICE EXAMPLE Never use the hooks (1) for trailer/ train shipping and sea shipping pur- poses to prevent damage to the vehi- cle. Luggage Carpet Hook EXAMPLE 74LHT0536 74LM05003 The hooks (3) (if equipped) is provided for The frame hook (2) is provided on the rear trailer/train shipping purposes only.

  • Page 83: Manual Heating And Air Conditioning System

    OTHER CONTROLS AND EQUIPMENT Manual Heating and Air Conditioning System 1. Windshield defroster outlet 2. Side defroster outlet Air Outlet 3. Side outlet 4. Center outlet EXAMPLE 5. Floor outlet 74LHT0501 74LH0-74E...
  • Page 84 OTHER CONTROLS AND EQUIPMENT Side outlet Description of Controls Air flow selector (3) EXAMPLE EXAMPLE EXAMPLE 68LM502 (4) (5) Move the knob (1) vertically and the dial 74LHT0503 (2) horizontally, to adjust the direction of 63J048 Temperature selector (1) airflow as desired. When “Open”, air This is used to select one of the functions comes out from the side outlets regardless This is used to select the temperature by...
  • Page 85 OTHER CONTROLS AND EQUIPMENT Bi-level (b) Heat & defrost (d) Air intake selector (4) EXAMPLE EXAMPLE EXAMPLE 68LM511 74LHT0507 74LHT0505 This selector is used to select the following Temperature-controlled air comes out of Temperature-controlled air comes out of modes. the floor outlets and cooler air comes out the floor outlets, the windshield defroster of the center and side outlets.
  • Page 86 OTHER CONTROLS AND EQUIPMENT Air conditioning switch (5) ture position and the blower speed selector You can switch the air intake selector to To turn on the air conditioning system, to the desired blower speed position. Set- either “FRESH AIR” or “RECIRCULATED push in the “A/C”...

  • Page 87: Radio Antenna

    OTHER CONTROLS AND EQUIPMENT NOTE: Maintenance Radio Antenna Because the air conditioner dehumidifies If you do not use the air conditioner for a the air, turning it on will help keep the win- long period, such as during winter, it may EXAMPLE dows clear, even when blowing heated air not give the best performance when you...

  • Page 88: Installation Of Radio Frequency Transmitters

    OTHER CONTROLS AND EQUIPMENT Installation of Radio Frequency Transmitters We recommend that you always ask a Maruti Suzuki authorised workshop about frequency band, output power, antenna position at vehicle and specific conditions for installation and/or use before installing a radio transmitter in your vehi- cle.
  • Page 89 VEHICLE LOADING AND TOWING VEHICLE LOADING AND TOWING Vehicle Loading ..............6-1 Trailer Towing ..............6-1 54G215 74LH0-74E...

  • Page 90: Vehicle Loading

    Vehicle Loading Trailer Towing WARNING Your vehicle was designed for specific Your MARUTI SUZUKI was originally weight capacities. The weight capacities of designed to carry people and a normal Never overload your vehicle. The your vehicle are indicated by the Gross amount of cargo, not to tow a trailer.
  • Page 91 INSPECTION AND MAINTENANCE INSPECTION AND MAINTENANCE Maintenance Schedule ............7-2 Periodic Maintenance Schedule ........7-2 Drive Belt ................7-6 Engine Oil and Filter ............7-6 Engine Coolant ..............7-10 Air Cleaner ................7-11 Spark Plugs ................. 7-12 Gear Oil ................7-13 Clutch Pedal ................
  • Page 92 INSPECTION AND MAINTENANCE EXAMPLE WARNING WARNING (Continued) (Continued) • When the engine is running, keep • Be careful not to cause accidental hands, clothing, tools, and other short circuits between the positive objects away from the fan and drive and negative battery terminals. belt.

  • Page 93: Maintenance Schedule

    “T”: Tighten to Specified Torque WARNING “O”: Rotate MARUTI SUZUKI recommends that NOTE: maintenance on your Maruti Suzuki This table includes services as scheduled vehicle should be performed by up to 80,000 km mileage. Beyond 80,000 Maruti Suzuki authorised workshop.

  • Page 94: Inspection And Maintenance

    Periodic Maintenance Schedule: 1, 2, 3, 4, 5, 6, 9, 10 INSPECTION AND MAINTENANCE FREE INSPECTION PERIODIC MAINTENANCE AT COST Interval: This interval should be judged by odometer reading or months, whichever comes first. km (x1000) months ENGINE 1-1. Water pump drive belt (Tension, Wear) –...
  • Page 95 Drive Belt: 1, 2 Engine Oil and Filter: 1, 2 INSPECTION AND MAINTENANCE FREE INSPECTION PERIODIC MAINTENANCE AT COST Interval: This interval should be judged by odometer reading or months, whichever comes first. km (x1000) months 5-2. Drive shaft boot (Damage) –...
  • Page 96 Engine Oil and Filter: 1, 2 INSPECTION AND MAINTENANCE FREE INSPECTION PERIODIC MAINTENANCE AT COST Interval: This interval should be judged by odometer reading or months, whichever comes first. km (x1000) months 10-4. Wiper (Operation) 10-5. Horn (Operation) 10-6. Accessory socket (Operation) –...

  • Page 97: Drive Belt

    If you need to replace or adjust the belt SAE 0W-20 (1) is the best choice for good (5) Air conditioner compressor have it done by your Maruti Suzuki autho- fuel economy, and good starting in cold rised workshop. weather.
  • Page 98 Engine Oil and Filter: 1, 2 INSPECTION AND MAINTENANCE Refilling EXAMPLE NOTICE Upper EXAMPLE Failure to check the oil level regularly Lower could lead to serious engine trouble due to insufficient oil. Open Close 81A147 NOTICE It is important to keep the engine oil at the correct level for proper lubrication of your Failure to check the oil level regularly vehicle’s engine.
  • Page 99 Gear Oil: 10 INSPECTION AND MAINTENANCE Changing Engine Oil and Filter Drain the engine oil while the engine is still 4) Reinstall the drain plug and new gasket EXAMPLE (1). Tighten the plug with a wrench to warm. the specified torque. EXAMPLE Open Close...
  • Page 100 (2) 3/4 turn face. tightened, have vehicle inspected by your Maruti Suzuki EXAMPLE NOTICE authorised workshop. To prevent oil leakage, make sure that the oil filter is tight, but do not over-tighten it.

  • Page 101: Engine Coolant

    Automatic Transaxle (AT) Fluid: 10 INSPECTION AND MAINTENANCE Engine Coolant Adding Coolant NOTICE Selection of Coolant WARNING To avoid damaging your cooling sys- To maintain optimum performance and tem: Engine coolant is harmful or fatal if durability of your engine, use MARUTI •...

  • Page 102: Air Cleaner

    Coolant replacement work requires techni- EXAMPLE cal skill. Do not replace the coolant by EXAMPLE yourself. Trust this job to Maruti Suzuki authorised workshop. 74LHT0713 If the air cleaner is clogged with dust, there will be greater intake resistance, resulting...

  • Page 103: Spark Plugs

    Engine Coolant: 1, 2 INSPECTION AND MAINTENANCE Spark Plugs To access the spark plugs: NOTICE 1) Unclamp the air cleaner cover. 2) Remove the engine top cover. • When disconnecting the spark plug 3) If necessary, disconnect the coupler (1) cables, pull on the boot, not on the while pushing the release lever.

  • Page 104: Gear Oil

    We highly recommend you use: “a” fire etc., the cause may be located not only "MARUTI SUZUKI GEAR OIL 75W-80" for on spark plugs but also on deteriorated manual transmission oil. ignition wirings (generally, used for more than 80,000 km or five years).

  • Page 105: Clutch Pedal

    Gear Oil Change uine Brake Fluid” (MGBF). inspected by your Maruti Suzuki autho- Since special procedures, materials and rised workshop. tools are required, it is recommended that you trust this job to your Maruti Suzuki authorised workshop. 7-14 74LH0-74E...
  • Page 106 Solution can be poisonous Should the light come on, immedi- to animals. Keep out of the reach of ately ask your Maruti Suzuki autho- children and animals. 54G108 rised workshop to inspect the Pedal to floor carpet minimum dis- brake system.

  • Page 107: Steering

    Maruti Suzuki by your Maruti Suzuki authorised work- authorised workshop. shop.

  • Page 108: Tires

    The front and rear tire pressure specifica- Under-inflation can cause unusual inspected by your Maruti Suzuki autho- tions for your vehicle are listed on the Tire handling characteristics or can rised workshop. Information Label. Both the front and rear...
  • Page 109 WARNING The vehicle is equipped with Tubeless Tires. In tubeless tire, a thin layer of butyl • Your MARUTI SUZUKI is equipped rubber is used for lining the inside of the with tires which are all the same tubeless tire. This layer is to prevent air type and size.

  • Page 110: Battery

    8) In case of any problem, please get in Remove corrosion using a stiff brush and hydrogen gas. Keep flames and touch with Maruti Suzuki authorised sparks away from the battery or an ammonia mixed with water, or baking soda workshop.
  • Page 111 Clutch Pedal: 6 Tires: 6 INSPECTION AND MAINTENANCE Replacement of the battery 2) Tighten the retainer nuts and battery NOTICE cables securely. EXAMPLE NOTE: If the battery liquid is added more When the battery is disconnected, some of than the upper level line “MAX”, liq- uid may leak by vibrations during the vehicle’s function will be initialized and/ or deactivated.

  • Page 112: Fuses

    Tires: 6 INSPECTION AND MAINTENANCE Fuses (14) 60 A Power steering Your vehicle has three types of fuses, as (31) (15) 30 A Radiator fan (32) described below: (33) (16) 40 A ABS 1 (34) Main fuse (17) (28) The main fuse takes current directly from (18) (29) (17)
  • Page 113 If the main fuse or a primary fuse engine compartment. If the main fuse blows, be sure to have your vehicle blows, no electrical component will func- (10) inspected by a Maruti Suzuki autho- tion. If a primary fuse blows, no electrical (11) (12) (13)

  • Page 114: Bulb Replacement

    Frequent replacement of a bulb indi- (31) 10 A Tail lamp cates the need for an inspection of (32) 20 A the electrical system. This should be carried out by your Maruti Suzuki (33) 7.5 A CNG IGS authorised workshop. (34) 10 A Meter (35) 7.5 A...
  • Page 115 However if NOTE: there is water leakage inside the lamp, You can see the position of retaining spring contact your Maruti Suzuki authorised (3) from the hole of headlight. workshop. Side Turn Signal Light Interior Light...
  • Page 116 Fuses: 7 INSPECTION AND MAINTENANCE Other General Lights (3) Removal Rear combination light (4) Installation (tail, stop, turn signal, etc.) Bulb holder EXAMPLE There are two types of bulb, “Full glass EXAMPLE type” (1) and “Glass/metal type” (2). To remove and install a full glass type bulb (1), simply pull out or push in the bulb.

  • Page 117: Wiper Blades

    If so, consult your To remove license plate light, cover trim on Maruti Suzuki authorised workshop for the license lamp needs to be removed. To proper replacement method. open the trim (1), insert a flat blade screw...
  • Page 118 INSPECTION AND MAINTENANCE wise, the wiper arms may interfere with each other. EXAMPLE EXAMPLE EXAMPLE 60A260 EXAMPLE EXAMPLE 71LMT0707 (4) Locked end 5) Install the new blade in the reverse order of removal, with the locked end positioned toward the wiper arm. Make sure the blade is properly retained by all the hooks.

  • Page 119: Windshield Washer Fluid

    Refill it if necessary. Use a good quality Since special procedures are required, we windshield washer fluid, diluted with water recommend you take your vehicle to your as necessary. Maruti Suzuki authorised workshop for the air conditioner filter replacement. WARNING 74LHM0702 Do not use “anti-freeze” solution in...
  • Page 121 EMERGENCY SERVICE EMERGENCY SERVICE Tire Changing Tool ............. 8-1 Jacking Instructions ............8-2 Jump Starting Instructions ..........8-5 Towing .................. 8-7 If the Starter Does Not Operate .......... 8-8 If the Engine is Flooded ............8-9 If the Engine Overheats ............8-9 Warning Triangle ..............

  • Page 122: Tire Changing Tool

    Jacking Instructions: 5 EMERGENCY SERVICE Tire Changing Tool NOTICE Type A Spare tire and tire changing tool Make sure that the spare tire is fixed EXAMPLE securely. Loosely fixed tire may cause noise during driving. NOTICE When stowing the jack, place the shaft facing to the left as shown in the illustration.

  • Page 123: Jacking Instructions: 5

    Jacking Instructions: 5 EMERGENCY SERVICE WARNING WARNING EXAMPLE After using the tire changing tools, be • Be sure to shift into “R” (Reverse) sure to stow them securely or they when you jack up the vehicle. can cause injury if an accident •...
  • Page 124 Jacking Instructions: 5 EMERGENCY SERVICE 7) Continue to raise the jack slowly and smoothly until the tire clears the EXAMPLE ground. Do not raise the vehicle more than necessary. CAUTION Never jack up the vehicle with pas- sengers inside the vehicle. To Raise the Vehicle with a Garage Jack •...
  • Page 125 EMERGENCY SERVICE Changing Wheels 5) Remove the wheel nuts and wheel. 6) Before installing the new wheel, clean To change a wheel, use the following pro- WARNING any mud or dirt off from the surface of cedure: • Use the jack only to change wheels the wheel and hub with a clean cloth.

  • Page 126: Jump Starting Instructions

    60G309 and the jump leads remain clear by a Maruti Suzuki authorised work- from pulleys, belts, or fans. Insert a piece of cloth between the spokes shop. • Batteries...
  • Page 127 EMERGENCY SERVICE NOTICE EXAMPLE WARNING Your vehicle should not be started by Never connect the jump lead directly pushing or towing. This starting to the negative (–) terminal of the dis- method could result in permanent charged battery, or an explosion may damage to the catalytic converter.

  • Page 128: Towing

    EMERGENCY SERVICE TOWING METHOD A Towing If you need to have your vehicle towed, 1) Secure the front wheels on a towing contact a professional service. Your dealer dolly according to the instructions pro- can provide you with detailed towing vided by the dolly manufacturer.

  • Page 129: If The Starter Does Not Operate

    EMERGENCY SERVICE TOWING METHOD B If the Starter Does Not Operate 1) Try turning the ignition switch to the “START” position or try 1) Shift the manual transaxle lever into neutral. pressing the engine switch to change the ignition mode to 2) Turn the ignition key to the “ACC”...

  • Page 130: If The Engine Is Flooded

    EMERGENCY SERVICE If the Engine is Flooded If the Engine Overheats pump, and radiator and heater hoses. If you locate any leaks that may have If the engine is flooded with fuel, it may be The engine could overheat temporarily caused the overheating, do not run the hard to start.

  • Page 131: Warning Triangle

    EMERGENCY SERVICE Warning Triangle • Remove the warning triangle carefully WARNING from the cover as shown by arrow 1. • Open both the reflector arms as shown EXAMPLE • It is hazardous to remove the radia- by arrow and lock the arms with each tor cap when the water temperature other with the clip provided in the right is high, because scalding fluid and...
  • Page 133 APPEARANCE CARE APPEARANCE CARE Corrosion prevention ............9-1 Vehicle cleaning ..............9-2 60G412 56RH0-74E...

  • Page 134: Corrosion Prevention

    APPEARANCE CARE Corrosion prevention This information illustrates the necessity of specifically intended for your purposes. keeping your vehicle (particularly the Follow the manufacturer’s directions when It is important to take good care of your underbody) as clean and dry as possible. It using these special cleaners.

  • Page 135: Vehicle Cleaning

    APPEARANCE CARE Park your vehicle in a dry, well-venti- Vehicle cleaning Cleaning interior lated area Vinyl upholstery Do not park your vehicle in a damp, poorly- EXAMPLE Prepare a solution of soap or mild deter- ventilated area. If you often wash your gent dissolved in warm water.
  • Page 136 APPEARANCE CARE NOTE: Seat belts CAUTION • In order to keep leather upholstery look- Clean seat belts with a mild soap and ing good, it should be cleaned at least water. Do not use bleach or dye on the • Do not spill liquid or semi-solid on twice a year.
  • Page 137 APPEARANCE CARE Washing When washing the vehicle, park it in the NOTICE place where direct sunlight does not fall on it and follow the instructions below: WARNING Do not use chemical products that 1) Flush the underside of body and wheel contain silicon to wipe electrical •...
  • Page 138 APPEARANCE CARE sponge or soft cloth. The sponge or Washing by an automatic car wash Waxing cloth should be frequently soaked in the soap solution. NOTICE EXAMPLE If you use an automatic car wash, NOTICE check that your vehicle’s body parts, When using a commercial car wash such as spoilers, cannot be dam- product, observe the cautions speci-...

  • Page 139: General Information

    GENERAL INFORMATION GENERAL INFORMATION Vehicle identification ............10-1 FASTag (if equipped) ............10-1 High Security Registration Plate (HSRP) ......10-2 Provision for AIS140: Intelligent Transportation System (ITS) ......10-3 84MM01001 56RH0-74E...

  • Page 140: Vehicle Identification

    As per Ministry of Road Transport and Chassis serial number information. Whenever you have occasion Highways, the FASTag (1) is mandatory for to consult your Maruti Suzuki authorised each vehicle for the purpose of electronic workshop, remember to identify your vehi- EXAMPLE toll collection or any other purpose as may cle with this number.

  • Page 141: High Security Registration Plate (Hsrp)

    GENERAL INFORMATION As seen from inside of the vehicle As seen from outside of the vehicle High Security Registration Plate (HSRP) EXAMPLE EXAMPLE As per Ministry of Road Transport and Highways, every new vehicle must have HSRP. Easy to Cruise HSRP contains;...

  • Page 142: Provision For Ais140: Intelligent Transportation System (Its)

    GENERAL INFORMATION Third license plate - As seen from out- • In the event of any replacement of the Provision for AIS140: side of the vehicle third license plate may please contact Intelligent Transportation the approved authority. EXAMPLE System (ITS) Third license plate - As seen from This vehicle has provision of Power Con- inside of the vehicle...

  • Page 143: Specifications

    Specifications: 1, 2, 5, 6, 7, 10, 11 SPECIFICATIONS SPECIFICATIONS NOTE: Specifications are subject to change without notice. Petrol: Petrol (K12M) engine model ITEM: Dimensions UNIT: mm Overall length 3995 Overall width 1695 Overall height 1555 Wheelbase 2430 Front 165 tyre 1485 Track Rear...
  • Page 144 Specifications: 1, 2, 5, 6, 7, 10, 11 SPECIFICATIONS ITEM: Engine Type K12M (DOHC) Number of cylinders Bore 73.0 mm Stroke 71.5 mm Piston displacement 1197 cm Compression ratio 11.0:1 ITEM: Electrical Standard spark plug NGK LKR6F-10 Battery 12V 34B20L Fuses See “INSPECTION AND MAINTENANCE”...
  • Page 145 Specifications: 1, 2, 5, 6, 7, 10, 11 SPECIFICATIONS ITEM: Lights WATTAGE BULB No. Headlight 12V 60/55W Front 12V 21W PY21W Turn signal light Rear 12V 21W PY21W Side turn signal light (on fender) 12V 5W WY5W Position light 12V 5W Tail/brake light 12V 5/21W P21/5W...
  • Page 146 Specifications: 1, 2, 5, 6, 7, 10, 11 SPECIFICATIONS ITEM: Wheel and Suspension Tyre size, front and rear 165/80R 14 Tyre size, spare 165/80R14 (Steel Wheel) Rim size 165 tyre: 14X5J For the specified tyre pressure, see the Tyre Information Label located on the Tyre pressures driver’s door lock pillar.

Table of Contents
