Recommended ambient charging temperature
TECHNICAL DATA
Rated voltage
Quick charge current Li-Ion
Recommended ambient charging temperature
Weight - not including battery pack
CoMPATIble bATTeRY PACKS
Battery pack
Voltage
L1820R TYPE II
L1820S
L1825R TYPE II
L1830R-X5
L1840R TYPE II
18 V
L1850R TYPE II
L1860R TYPE II
L1860R-X5
L1890R
WARNING! Read all safety warnings instructions, illustrations and
specifications provided with this power tool. Failure to follow all instructions
listed below may result in electric shock, fire and/or serious injury. Save all
warnings and instructions for future reference.
ChARGeR SAFeTY WARNINGS
Do not dispose of used battery packs in the household refuse or by burning
them. AEG Distributors offer to retrieve old batteries to protect our environment.
Do not store the battery pack together with metal objects (short circuit risk).
Use only System AEG GBS chargers for charging System AEG GBS battery packs.
Do not use battery packs from other systems.
Do not try to charge non-rechargeable batteries with this charger.
No metal parts must be allowed to enter the battery section of the charger (short
circuit risk).
Never break open battery packs and chargers and store only in dry rooms. Keep
dry at all times.
Do not touch the tool with conducting objects.
Never charge a damaged battery pack. Replace by a new one.
Before use, check machine, cable, and plug for any damages or material fatigue.
Repairs should only be carried out by authorised service agents.
AddITIoNAl bATTeRY SAFeTY WARNINGS
WARNING! To reduce the risk of fire, personal injury, and product damage
due to a short circuit, never immerse your tool, battery pack or charger in fluid or
allow a fluid to flow inside them. Corrosive or conductive fluids, such as seawater,
certain industrial chemicals, and bleach or bleach containing products, etc., can
cause a short circuit.
SPeCIFIed CoNdITIoNS oF USe
The quick charger is intended to charge AEG system slide 18V batteries.
Do not use the product in any way other than those stated for intended use.
BATTEry CHArgEr
Battery capacity
Number of cell for battery
≤ 2.0 Ah
≤ 2.0 Ah
≤ 2.5 Ah
≤ 3.0 Ah
≤ 4.0 Ah
≤ 5.0 Ah
≤ 6.0 Ah
≤ 6.0 Ah
≤ 9.0 Ah
5
Cell type
5
5
5
5
5 x 2
Lithium-Ion
5 x 2
5 x 2
5 x 2
5 x 3
MAINS CoNNeCTIoN
Connect only to single-phase A.C. current and only to the system voltage
indicated on the rating plate.
bATTeRIeS
Battery packs which have not been used for some time should be recharged
before use.
Temperatures in excess of 50°C (122°F) reduce the performance of the battery
pack. Avoid extended exposure to heat or sunshine (risk of overheating).
The contacts of chargers and battery packs must be kept clean.
For an optimum life-time, the battery packs have to be fully charged, after used.
To obtain the longest possible battery life remove the battery pack from the
charger once it is fully charged.
For battery pack storage longer than 30 days:
Store the battery pack where the temperature is below 27°C and away from
moisture.
Store the battery packs in a 30% - 50% charged condition.
Every six months of storage, charge the pack as normal.
ChARACTeRISTICS
After inserting the battery into the reception of the charger the battery will
automatically be charged (green lamp is flashing).
When a hot or cold battery pack is inserted into the charger (orange lamp is
illuminated continuously), charging will begin automatically once the battery
reaches the correct charging temperature (0°C - 50°C).
Charging time varies depending on the battery temperature, charge needed and
the type of battery pack being charged.
As soon as charging is completed, the charger switches over to trickle charge
to maintain the full capacity (green control lamp is illuminated continuously, red
lamp off).
If red lamp is illuminated continuously, either the battery has not been completely
bl18S
18 V
2.0 A
+5 to +40 °C
0.35 kg
Approximate charge time
90 minutes
90 minutes
110 minutes
125 minutes
170 minutes
190 minutes
210 minutes
210 minutes
375 minutes
5
