SWITCH REFERENCE CONTINUED
ID Name Node
C1 DIP 1 0
C10 Service Plus 0
C11 Service Minus 0
C12 Service Back 0
C17 Headphone Detect 0
C18 Headphone Kit Cable 0
Detect
C19 Volume Encoder 1 0
C2 DIP 2 0
C20 Volume Encoder 2 0
C24 DC Sense 0
C3 DIP 3 0
C4 DIP 4 0
C5 DIP 5 0
C6 DIP 6 0
C7 DIP 7 0
C8 DIP 8 0
C9 Service Select 0
