Selecting Scoreboard Model

The next press of the Options key will display one of the following screens. It indicates which of
the scoreboard model series the control is currently configured to operate. Use the "+" key to
toggle thru the scoreboard models. Press HALF / SCORE to exit the options routine. The last
scoreboard series displayed will become the new control configuration.
MPCX
Control
1520, 1525, 9505, 9515, 1620, 1625, 9605, 9715, 1020, 1025, 9405, 9410
3502, 3504, 3514, 3515, 3516, 3520, 3525, 3534, 3550, 3555, 1632, 9605,
9505, 9715, 9515, 3402, 3404, 3414, 3415, 3416, 3425, 3434, 3455, 9405
Soccer
7604, 7605, 7614, 7615, 7616, 7620, 7624, 7625, 7630, 7631, 7632, 3600,
3602, 3604, 3614, 3615, 3616, 3617, 3618, 3619, 3620, 3621, 3625, 3634,
3650, 3655, 3656, 7505, 7516, 7520, 7525, 7530, 9605, 9715, 9505, 9515,
200, 230, 24xx, 25xx, 26xx, 27xx, 9510, 9515, 9710, 9715
Scoreboard Model
1515, 9505, 9515, 1615, 9605, 9715, 1415
7504, 7524, 9505, 9515, 9605, 9715, 7405, 7424
7405, 7416, 7425, 7430, 9405, 9410
3657
4755, 4555, 4565, 4765
12
Screen to Select
Type A (+)
Type B (+)
Type C (+)
Type D (+)
Type E (+)
Type F (+)
Type G (+)
Type H (+)
