Duct-type air conditioner (cool)

Advertisement

E S F A DB98-05501A(2)
Duct-type Air Conditioner
Aire acondicionador Tipo Canal
Climatiseur de type Conduit
OWNER'S INSTRUCTIONS
MANUAL DE INSTRUCCIONES
MANUEL D'UTILISATION
Indoor Unit
Outdoor Unit
BC052TEZA
BC052TEZX
BC052TBZA
BC052TBZX
BC070TEZA
BC070TEZX
BC070TBZA
BC070TBZX
HC105TEZA
HC105TEZX
HC105TBZA
HC105TBZX
HC140TGZA
HC140TGZX
HC140TFZA
HC140TFZX
HC175TGZA
HC175TGZX
HC175TFZA
HC175TFZX
HC230TGZA
HC230TGZX
HC230TFZA
HC230TFZX
(Cool)
(Refrigeración)
(Refroidissement)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HC175TGZA and is the answer not in the manual?

Questions and answers

Summary of Contents for Samsung HC175TGZA

  • Page 1 Aire acondicionador Tipo Canal Climatiseur de type Conduit E S F A DB98-05501A(2) OWNER’S INSTRUCTIONS MANUAL DE INSTRUCCIONES MANUEL D’UTILISATION Indoor Unit BC052TEZA BC052TBZA BC070TEZA BC070TBZA HC105TEZA HC105TBZA HC140TGZA HC140TFZA HC175TGZA HC175TFZA HC230TGZA HC230TFZA Duct-type Air Conditioner (Cool) (Refrigeración) (Refroidissement) Outdoor Unit BC052TEZX BC052TBZX...
  • Page 2: Before Starting

    Before Starting The wired remote controller, wireless remote controller and Centralized controller of the air conditioner are optional accessories. And your Owner’s Instructions is for all of them. So that before using this instruction, ensure your option(s). Safety Precautions WARNING DANGER CAUTION If the power supply cord of this air conditioner is damaged,...
  • Page 3: Table Of Contents

    Contents REPARING YOUR AIR CONDITIONER Before Starting ........2 Safety Precautions .
  • Page 4: View Of The Unit

    View of the Unit The figures are shown in this instruction may differ from yours depending on the model. Indoor Unit Indoor Unit Panel(option) HC105TEZA, HC140TGZA, HC175TGZA, HC230TGZA HC105TBZA, HC140TFZA, HC175TFZA, HC230TFZA outlet BC052TEZA, BC052TBZA, BC070TEZA, BC070TBZA outlet inlet inlet inlet...
  • Page 5: Outdoor Unit

    Outdoor Unit BC052TEZX, BC052TBZX, BC070TEZX, BC070TBZX Outdoor Unit HC105TEZX, HC105TBZX Outdoor Unit HC140TGZX, HC140TFZX, HC175TGZX, HC175TFZX Air inlet(Rear) Outdoor Unit HC230TGZX, HC230TFZX Air outlet Connection valve Air outlet Connection valve Air outlet Connection valve Air outlet Connection valve...
  • Page 6: Wireless Remote Controller-Buttons And Display

    Wireless Remote Controller-Buttons and Display The wireless remote controller is an optional accessory. To use the wireless remote controller, refer to an appropriate manual. Operating mode Temperature setting Fan speed Air flow direction On Timer setting Off Timer setting Battery discharge indicator - After cleaning the air filter, press the filter reset button, if the filter has been installed.
  • Page 7: The Indicators On The Receiver & Display Unit

    The Indicators on the Receiver & Display Unit The receiver & display unit is an optional accessory for the wireless remote controller and it is installed on the wall. To use the receiver & display unit, refer to an appropriate manual. Concealed Type Standard...
  • Page 8: Wired Remote Controller-Buttons And Display

    Wired Remote Controller-Buttons and Display The wired remote controller is an optional accessory and it is installed on the wall. To use the wired remote controller, refer to an appropriate manual. Communication error indicator On Timer setting Off Timer setting Test indicator Temperature adjustment buttons...
  • Page 9: Centralized Controller

    Centralized Controller The centralized controller is an optional accessory and it is installed on the wall.\ To use the centralized controller, refer to an appropriate manual. Operating lamp comes on when at least one air conditioner connected to the centralized controller is operating. Operating lamp All On button All Off button...
  • Page 10: Operating Recommendations

    Operating Recommendations Here are a few recommendations that you should follow when operating your air conditioner. Topic Recommendation Power failure If a power failure occurs while the air conditioner is operating, the unit will be switched off. When the power returns, the air conditioner restarts in the previous operation mode.
  • Page 11: Temperature And Humidity Ranges

    Temperature and Humidity Ranges The following table indicates the temperature and humidity ranges, within which the air conditioner can be used. If the air conditioner is used at... High temperature Low temperature High humidity levels Mode Outdoor Temperature Indoor Temperature Cooling 21°C to 54°C approx.
  • Page 12: Cleaning Your Air Conditioner

    Cleaning Your Air Conditioner HC105TEZA, HC105TBZA, HC140TGZA, HC140TFZA HC175TGZA, HC175TFZA, HC230TGZA, HC230TFZA Wired Remote Controller Wireless Remote Controller To get the best possible use out of your air conditioner, you must clean it regularly to remove the dust that accumulates on the air filter. The air filter is an optional accessory.
  • Page 13 BC052TEZA, BC052TBZA, BC070TEZA, BC070TBZA To get the best possible use out of your air conditioner, you must clean it regularly to remove the dust that accumulates on the air filter. IMPORTANT Before cleaning your air conditioner, ensure that you have switched off the electric circuit breaker used for the unit.
  • Page 14: Solving Common Problems

    Solving Common Problems Before contacting the after-sales service, perform the following simple checks. They may save your time and expense of an unnecessary call. Problem The air conditioner does not operate at all Wired Remote Controller The air conditioner does not operate with the remote controller Wired Remote Controller...
  • Page 15: Technical Specifications

    Technical Specifications Model Power Supply BC052TEZA 1Ø, 220-240V~, 50Hz BC052TEZX BC070TEZA 1Ø, 220-240V~, 50Hz BC070TEZX BC105TEZA 1Ø, 220-240V~, 50Hz BC105TEZX HC140TGZA 3Ø, 380-415V~, 50Hz HC140TGZX HC175TGZA 3Ø, 380-415V~, 50Hz HC175TGZX HC230TGZA 3Ø, 380-415V~, 50Hz HC230TGZX BC052TBZA 1Ø, 220V~, 60Hz BC052TBZX BC070TBZA 1Ø, 220V~, 60Hz BC070TBZX...
  • Page 16 THIS AIR CONDITIONER IS MANUFACTURED BY: ESTE AIRE ACONDICIONADO HA SIDO FABRICADO POR: CE CLIMATISEUR EST FABRIQUE PAR: ELECTRONICS Printed in Korea...
