- Page 1 OWNER’S INSTRUCTIONS MANUAL DE INSTRUCCIONES MANUEL D’UTILISATION ISTRUZIONI PER L’USO MANUAL DE INSTRUÇÕES GEBRAUCHSANWEISUNG √¢∏°π∂™ Ã∏™∆∏ àçëíêìäñàü èéãúáéÇÄíÖãü DH052EAM DH070EAM DH094EAM HH105ECM HH140ECM HH175ECM HH175EZM Duct-type Air Conditioner (Cool and Heat) Aire acondicionador Tipo Canal (Refrigeración y Calefacción) Climatiseur de type Conduit (Refroidissement et Chauffage) Condizionatore d’aria Tipo Conduttura...
-
Page 2: Safety Precautions
Safety Precautions The following safety precautions must be taken when using your air conditioner. Risk of electric shock. • Can cause injury or death. • Disconnect all WARNING remote electric power supplies before servicing, installing or cleaning. • This must be done by the manufacturer or its service agent or a similar qualified person in order to avoid a hazard. -
Page 3: Table Of Contents
Contents REPARING YOUR AIR CONDITIONER Safety Precautions ........2 View of the Unit . -
Page 4: View Of The Unit
View of the Unit The figures are shown in this instruction may differ from yours depending on the model. Indoor Unit 052/070/094 outlet inlet Air filter Indoor Unit 105/140/175 outlet inlet... - Page 5 Outdoor Unit TYPE A Air outlet Connection valve Outdoor Unit TYPE B Air outlet Connection valve Outdoor Unit TYPE C Air outlet Connection valve Outdoor Unit TYPE D Air outlet Connection valve If the heat exchanger in the outdoor unit gets dusty, cooling efficiency may fall. So clean the heat exchanger with water when it becomes dirty.
-
Page 6: Wireless Remote Controller-Buttons And Display
Wireless Remote Controller-Buttons and Display The wireless remote controller is an optional accessory. To use the wireless remote controller, refer to an appropriate manual. Mode selection button Operating mode Temperature adjustment Temperature setting buttons Filter Reset button Fan speed Fan speed adjustment button Air flow direction Swing button (Not operated) -
Page 7: The Receiver & Display Unit
The Receiver & Display Unit The Receiver & Display unit is an optional accessory and it is installed on the wall. To use the receiver & display unit, refer to an appropriate manual. Concealed Type Filter sign indicator Fan indicator Timer indicator Remote control sensor On/Off indicator(Blue) &... -
Page 8: Wired Remote Controller-Buttons And Display
Wired Remote Controller-Buttons and Display The wired remote controller is an optional accessory and it is installed on the wall. To use the wired remote controller, refer to an appropriate manual. Type A Operating mode Centralized controller indicator Removing frost indicator (In case of installing the Centralized controller) Communication error indicator... - Page 9 Type B Operating mode Centralized controller indicator Removing frost indicator (In case of installing the Centralized controller) Communication error indicator Temperature setting On Timer setting Fan speed Off Timer setting Air flow direction Test indicator Filter Sign indicator On/Off button Temperature adjustment On/Off indicator buttons...
-
Page 10: Centralized Controller
Centralized Controller The centralized controller is an optional accessory and it is installed on the wall. To use the centralized controller, refer to an appropriate manual. Front View Operating lamp All On button All Off button On/Off indicators On/Off buttons Index The operating lamp comes on even when only one air conditioner connected to the centralized controller is operating. -
Page 11: Function Controller
Function Controller The function controller is an additional controller which is used with the centralized controller. To use the function controller, refer to an appropriate manual. Operating mode Removing frost indicator Centralized controller indicator Communication error indicator Temperature setting Room number display Fan speed Air flow direction Test indicator... -
Page 12: Operating Recommendations
Operating Recommendations Here are a few recommendations that you should follow when operating your air conditioner. Topic Recommendation Heating The heat pump function of the air conditioner absorbs heat from outside air and brings performances it indoors. As the temperature of the outside air drops, the heating performance of air conditioner will decrease. -
Page 13: Cleaning Your Air Conditioner
Cleaning Your Air Conditioner 052/070/094 For the best use of your air conditioner, you must clean it every 2 weeks regularly to remove the dust that accumulates on the air filter. IMPORTANT Before cleaning your air conditioner, ensure that you have switched off the electric circuit breaker used for the unit. -
Page 14: Cleaning Your Air Conditioner (Optional)
Cleaning Your Air Conditioner (Optional) 105/140/175 For the best use of your air conditioner, you must clean it every 2 weeks regularly to remove the dust that accumulates on the air filter. The air filter is an optional accessory. IMPORTANT Before cleaning your air conditioner, ensure that you have switched off the electric circuit breaker used for the unit. -
Page 15: Solving Common Problems
Solving Common Problems Before contacting the after-sales service, perform the following simple checks. They may save your time and expense of an unnecessary call. Problem Explanation/Solution The air conditioner does not Check that the breaker used for the air conditioner is switched on. operate at all Wired Remote Controller The air conditioner does not... - Page 16 THIS AIR CONDITIONER IS MANUFACTURED BY: ESTE AIRE ACONDICIONADO HA SIDO FABRICADO POR: CE CLIMATISEUR EST FABRIQUE PAR: QUESTO CONDIZIONATORE D’ARIA È PRODOTTO DA: ESTE APARELHO DE AR CONDICIONADO É FABRICADO POR: DIESE KLIMAANLAGE IST FABRIZIERT VON: AYTH H ™Y™KEYH KATA™KEYA™THKE A¶O: ùíéí...
