  • Page 1 Operator’s Manual JM 2040 IDENTIFICATION Owner: ......................................Address: ................................... Nº ....Telephone: .............. City: ................ State ..Zip Code: ....- .... Machine Model: ................Serial Number: ................Manufacturing Year: ..............Invoce Nº: ................
  • Page 2 2.3. If the PRODUCT is sold to the farmer by a dealer who is not JUMIL´s , the right of Warranty will remain, but in this case, it must be made directly from JUMIL, in the terms of this Certificate.

  • Page 3: Table Of Contents

    Operator’s Manual JM 2040 ÍNDEX 1 - INTRODUCTION ....................04 2 - PRESENTATION ....................05 3 - NORMS OF SAFETY ..................06 4 - TECHNICAL SPECIFICATIONS ..............08 5 - OPTIONAL PARTS ..................09 5.1 - Discs and Wedges .................... 10 5.2 - Kit for seeding (Optional Parts) ...............

  • Page 4: Introduction

    Congratulations, you have just purchased an equipment which is manufactured with the most modern process in technology and efficiency on the market, it is guaranteed by the well-known JUMIL Trade Mark. This manual has the aim of instructing you in the correct use so that you can get the best performance and advantages the equipment has.

  • Page 5: Presentation

    As it is equipment that allies quality with technology it is necessary that uses this manual to get its largest acting. In case of doubt, contact our technical services. Phone: (16) 3660-1061 Fax: (16)3660-1116 e-mail:vendasmaq@jumil.com.br...

  • Page 6: Norms Of Safety

    Operator’s Manual JM 2040 3 - NORMS OF SAFETY When JUMIL manufactures its Agricultural Machines and Implements has the main objective to thel the Man to develop a better LIVING STANDARD. However, in the use of these machines some cares must be RESPECTED: DO NOT DESTRUCT THE UNVIERSAL BIOLOGICAL EQUILIBRIUM WITH INCORRECT AGRICULTUEAL WORKS.
  • Page 7 The equipments which cover the tractor rear signing lights must have alternative read signal light. ATTENTION When receiving your JUMIL equipment, check attentively its components which are delivered with the equipment and read carefully the warranty certificate in the first page of...

  • Page 8: Technical Specifications

    Operator’s Manual JM 2040 4 - TECHNICAL SPECIFICATIONS - JM2040 MODEL JM 2040PD Toolbar 1,80 m 3,00 m 3,40 m 3,86 m Maximum Nº of Rows Minimum Spacing Among Rows 400 mm Fertilizer Box Capacity 39 lt Seed Box Capacity 39 lt Fertilizer Flow 100 to 1000 kg / ha...

  • Page 9: Optional Parts

    Operator’s Manual JM 2040 5 - OPTIONAL PARTS DESCRIPTION CODE FRONTAL FURROWER COMPLETE SET FOR MAIZE 28.01.140-6 RIGHT/LEFT ROW MARKER COMPLETE SET 32.40.135-3 SET OF THE PRESS WHEEL BAND 7X18 27.11.020-6 17" GROOVED CUTTING DISC SET WITH SUPPORT 27.13.010-0 SEED DISTRIBUTION KIT (PARTIAL) 32.40.870-6 CONVENTIONAL SEED DISTRIBUTION KIT 32.40.860-9...

  • Page 10: Discs And Wedges

    Operator’s Manual JM 2040 5.1 - Discs and Wedges For the seed distribution Jumil uses the horizontal drilled disc system, of larger precision due to the unique characteristics of project. JUMIL possesses several discs for be used in agreement with the type of culture and/or seed size to be used.
  • Page 11 Operator’s Manual JM 2040 DESCRIPTION CODE MAIZE DISC 24FXE4,5XF14,0 27.28.700 MAIZE DISC 24FXE7,5XF12,0 *27.28.693 MAIZE DISC 28FXE4,5XF10,5X15,0 27.10.054 MAIZE DISC 28FXE4,5XF11,0X16,0 27.10.055 MAIZE DISC 28FXE4,5XF13,0 27.10.051 MAIZE DISC 28FXE4,5XF8,5X11,5 27.10.053 MAIZE DISC 28FXE4,5XF9,0X13,8 27.10.052 MAIZE DISC 28FXE4.5XF12.0 27.10.061 SOYBEAN DISC 110FXE4,5XF7,0 27.10.062 SOYBEAN DISC 38FXE8,5XF9,0X22,0 *27.10.146...

  • Page 12: Kit For Seeding (Optional Parts)

    Operator’s Manual JM 2040 5.2 - Kit for seeding (Optional Parts) 1 - Kit for seeding of Conventional Grains(Optional) In case of acquisition of kits for assembly, come in the following way: 1-Remove the subset “K” (Fig.003) or the set “G” (Fig.002). 2-Set up the subset “B”...
  • Page 13 Operator’s Manual JM 2040 2 - Kit for seeding of cotton with linter (Optional) 1- Remove the set “A” (Fig.001) or the set “K (Fig.003). 2- Set up the set “G” (Fig.002). 3- In the case of requesting the wheel change, change the wheel “H” (Fig.002) by the wheel “I”.
  • Page 14 Operator’s Manual JM 2040 3 - Kit for Peanut Seeding (Optional). 1- Remove the subset “B” (Fig.001) or the set “G” (Fig.002). 2- Set up the subset “K” (Fig.003) or the set “J” (Fig.003). 3- Remove the conductor “D” (Fig.001) from the subset “C” (Fig.001). 4- Set up the conductor “M”...
  • Page 15 Operator’s Manual JM 2040 ATTENTION Loose the screws “A” to remove the base of the seeding “C”. Remove the conductor “B”. With the disassembled base of the seeding “C”, place the conductor “D” and force it against the base “C” doing the rotation movement in counterclockwise sense.

  • Page 16: Product Composition

    Operator’s Manual JM 2040 6 - PRODUCT COMPOSITION Check the following items that accompany each row of your machine attentively: DESCRIPTION CODE QUANT. GEAR Z-7 04.27.046-0 GEAR Z-8 04.27.047-9 GEAR Z-10 04.27.048-7 GEAR Z-15 04.32.015-8 GEAR Z-17 04.32.036-0 SET OF THE HOSE INFERIOR LOCK 27.08.005-6 MAIZE DISC SET 28FXE4,5XF9,0X13,8 27.10.052-9...

  • Page 17: Product Assembly

    Operator’s Manual JM 2040 7 - PRODUCT ASSEMBLY The machine leaves from the factory semi-assembled and it is necessary only to proceed with the assembly of the unities in agreement with the wanted spacing. The spacing among rows is fundamental for any plant because it provides to them the same ideal conditions to their development and then they can produce the maximum of their potential.

  • Page 18: Preparation For Use

    If the disc is not the more adequate because its size, shape and/or number of holes, consult our technical services. Jumil possess several discs to use in agreement with the culture type and/or seed type to be used. Ps: consult the item optional parts of this manual.

  • Page 19: Change Of The Discs For Seed

    Operator’s Manual JM 2040 8.2 - Change of the discs for seed To make the assembly or change of the disc, loosen the butterfly, loosen the lock and after turn the deposit back. Remove the disc and in the same position place the wanted disc, observing the recording that indicates “THIS SIDE DOWN”.
  • Page 20 Operator’s Manual JM 2040 Due to great variety of discs with several drillings, for each type and size of the seeds, it is necessary the use of specific sheaves. We related the existent models bellow and they should be used in agreement with the chart of the discs.
  • Page 21 Operator’s Manual JM 2040 Fig. 006 IMPORTANT To improve the seed flow in the box and seed distribution, we recommended the use of lead powder in the mixture of the seeds. That care will avoid the obstructions and wastes of the components sensibly. ATTENTION Before place the seeds in the boxes it is important to check in the sets of seed distribution if the pawls are free...

  • Page 22: Deflector For Conventional Grains

    Operator’s Manual JM 2040 8.4 - Deflector for Conventional Grains. The deflector is a component used in the interior of the seed box to avoid the seed pressure on the limiter of the seed box, except for the rice planting. This system provides a more uniform distribution and also avoids damages to the seed.

  • Page 23: Till Or Coventional Planting

    Operator’s Manual JM 2040 8.5 - No-till or Coventional Planting Your planter makes the no-till or conventional planting and in the no-till planting it is used the cutting disc set (optional) (Fig.008) and in the conventional planting the set can be removed. 8.6 - Cutting Disc of the no-till planting.

  • Page 24: Fertilizer Applicators

    Operator’s Manual JM 2040 8.7 - Fertilizer Applicators The fertilizer application is made through the offset double disc. 8.7.1 - Fertilizer Offset Double Disc The fertilizer offset double disc (Fig.009) possesses in its interior a plastic fertilizer conductor with the aim of conduct the fertilizer in the ideal position for the germination and development of the plant.

  • Page 25: Adjustments

    Operator’s Manual JM 2040 9 - ADJUSTMENTS 9.1 - Quantity and Seed Distribution The distribution and quantity of seeds are regulated by the change of drilled discs and by the exchange of the gears that accompany each seeding unit. Next are presented the charts for the seed distribution and for seeding of several cultures.
  • Page 26 DRIVEN should be certified that the quantity distributed is really the wanted. For that to do practical tests before beginning the planting. DRIVEN DRIVE ATTENTION To consult Jumil for the DRIVE orientation on the seeding of other culture types.
  • Page 27 Operator’s Manual JM 2040...
  • Page 28 Operator’s Manual JM 2040...
  • Page 29 For that to do practical tests before beginning the planting. ATTENTION To consult Jumil for the orientation on the seeding of other culture types. ATTENTION There is a plain disc (model 27.28.701) that accompanies the row unit which can be holed by the costumer.

  • Page 30: Drillling Of The Blind Disc

    Operator’s Manual JM 2040 9.2 - Drillling of the blind disc (thermoplastic) The blind disc (27.28.701) that accompanies the machine can be drilled by the agriculturist being just enough to define the diameter and the quantity of holes. For to make the drilling, we recommended following the instructions below: 1-The disc should be very fixed and leaned in plain surface.

  • Page 31: Prepararation Of The Fertilizer Distribution Units

    Operator’s Manual JM 2040 9.3 - Prepararation of the fertilizer distribution units In your planter the fertilizer is distributed by a rotative plate and by a directional pawl that give a uniform distribution of the fertilizer quantity. The fertilizer quantity is regulated coming unfastened the butterfly (Fig.014 “a”) from the regulator ring (Fig.014 “b”) turning between 0 (close) and 8 (open) in agreement with the gradation scale.(Fig.014”c”).

  • Page 32: Fertilizer Distribution Chart

    Operator’s Manual JM 2040 9.3.1 - Fertilizer Distribution Chart...

  • Page 33: Fertilizer Distribution Chart - Endless Thread (Optional)

    Operator’s Manual JM 2040 9.3.2 - Fertilizer Distribution Chart Endless thread (optional)
  • Page 34 Operator’s Manual JM 2040...
  • Page 35 Operator’s Manual JM 2040...
  • Page 36 Operator’s Manual JM 2040...
  • Page 37 Operator’s Manual JM 2040...

  • Page 38: Row Marker

    Operator’s Manual JM 2040 9.4 - Row Marker It is IMPORTANT AND NECESSARY the use of Row markers with the aim of doing a complete use of the land and at the same time the plants can be distributed equally and so they can make a good use equally of the soil conditions, nutritious elements, luminosity, etc.
  • Page 39 Operator’s Manual JM 2040 The arm total length of the row marker must be calculated by the formula: D = e (n + 1) - b For the marking by the nearest tire from the sowed row D = e (n + 1) + b For the marking by the most distant tire from the sowed row Where : D= Distance from the marker disc to the double disc center from the external seeding unit;...

  • Page 40: Adjustments In The Field

    Operator’s Manual JM 2040 9.5 - Adjustments in the field In this phase presumes that you already prepared your JM2040 to work, in other words, set up in agreement with the wanted spacing, regulated the quantity of fertilizer and seed in agreement with the soil and the culture and now it will beginning the planting.

  • Page 41: Fertilizer Double Disc Adjustment

    Operator’s Manual JM 2040 is being badly conduct – rotation lack of the cultures, of straw of covering, etc) and the planter has difficult to penetrate. Its use is very simple, it leaves regulated from the factory and there is no need of another adjustment.

  • Page 42: Depth Adjustment And Seed Cover

    Operator’s Manual JM 2040 9.9 - Depth adjustment and seed cover. The seed depth placement in the soil is determined by the back press wheel (“a”Fig.020) through drilled sheet “b” of an exclusive design and of the locking pin “c”. The locking pin placement in a determined hole is what will determine as the wheel can arise, lowering in this way the set of the double disc.

  • Page 43: Spacing Among Rows

    Operator’s Manual JM 2040 9.10 - Spacing among rows The spacing among rows or seeding units is made being marked firstly in the toolbar the wanted distances and is tended as reference the center of the same. So, for the spacing among rows it is used 3 seeding units in a toolbar and the two units of the extremity are distanced about 1,0m from the central unit.

  • Page 44: Operation

    Operator’s Manual JM 2040 10 - OPERATION 10.1 - Coupling to the tractor The system of three points of the three-points hitch of the tractor makes possible that just an operator can make the coupling of the implement to the tractor; it is a quite practical system, being the system components (arms, tighter, threads of adjustment of the length of the arms, etc.,) are working well ( see preparation of the tractor).

  • Page 45: Tractor Preparationr

    Operator’s Manual JM 2040 10.1.1 - Tractor Preparationr Proceed to a general revision in the tractor, in way to make the planting without interruptions motivated by damages with the tractor - Remember that your period of planting is short, and it is dependent of climatic conditions, on which won't have influence.

  • Page 46: Lubrication

    Operator’s Manual JM 2040 11 - LUBRICATION 11.1 - Lubrication Aims The lubrication is the best warranty of the good operation and acting of the equipment. This practice prolongs the useful life of the parts and it helps in the economy of the maintenance costs. Before beginning the work, be certified that the equipment is appropriately lubricated, following the orientations of the Plan of Lubrication.
  • Page 47 Operator’s Manual JM 2040...
  • Page 48 Operator’s Manual JM 2040...
  • Page 49 Operator’s Manual JM 2040...

  • Page 50: Incidents, Possible Causes And Solutions

    Operator’s Manual JM 2040 12 - INCIDENTS, POSSIBLE CAUSES AND SOLUTIONS ATTENTION Before requesting the technical services, check the following items: It is not distributing seed and fertilizer Possible Causes Solutions 1- Empty boxes; 1- Complete the boxes; 2- Obstructed exits; 2-Check the pipelines.
  • Page 51 Operator’s Manual JM 2040 Fall of seed out of the furrower Possible Causes Solutions 1- High planting speed; 1 - To adjust for 5 km/h; 2- Worn-out double discs; 2- To change and to align; 3- Double discs out of the furrower. 3- To level the machine, to adjust the depth and the pressure of the springs...
