Summary of Contents for Jumil 3070PD
- Page 3 Thus, it is possible to launch specific products to leverage the volume or productions in all types of crops. Today, JUMIL ranks as one of the main companies of agricultural implements all over the world and precursor of agribusiness, exporting their products to more than 36 countries.
-
Page 5: Table Of Contents
3060/70 - 3080/90 - 7080/90PD TABLE OF CONTENTS PRODUCT PRESENTATION ......................7 EASYTECH SYSTEM ........................7 INTRODUCTION ..........................7 1 - SYSTEM OVERVIEW ........................8 1.1 - Easytech Controller Functions ....................8 2 - INSTALLING THE EASYTECH ....................8 2.1 - Electrical Installation........................8 2.2 - Hydraulic Installation .........................9 3 - SYSTEM OPERATION .........................9 3.1 - Easytech System Interface......................9 3.2 - Seed Configuration........................10... -
Page 7: Product Presentation
Easytech system, which came to make the rural producer’s life easier in the field. Easytech JUMIL is a fixed rate control system, which does not make use of GPS. It controls the equipment, the fertilizers distribution, both in wagons, seeders/fertilizers, through hydraulic motors and an electronic controller, mi- nimizing the vibrations in seeders/fertilizers making the operation more accurate and efficient. -
Page 8: System Overview
Easytech - planting 1 - SYSTEM OVERVIEW The Easytech controller is a Planter/Fertilizer management system, it has many other complimentary func- tions that assist and facilitate operations in the field. 1.1 - Easytech Controller Functions - Fixed rate control Seed; - Fixed rate control Manure;... -
Page 9: Hydraulic Installation
3060/70 - 3080/90 - 7080/90PD 2.2 - Hydraulic Installation According to: 3 - SYSTEM OPERATION It is recommended to power on the tractor before the Easytech display is switched on. ATTENTION: The Easytech should be used only by people qualified/trained on the correct use of the equipment. Its incorrect operation can cause physical damage to the system or any component. -
Page 10: Seed Configuration
Easytech - planting 3.2 - Seed Configuration To configure the seed rate to be applied, click on the function in the work main screen. Checking the seeds volume: CURSOR SELECT CURSOR BACK BECKER MENU In the field Seeds in 50ml enter the number of seeds collected in the Becker that comes with the machine. This value is important for the seeds deposit volumetric reference. - Page 11 3060/70 - 3080/90 - 7080/90PD START CALIBRATION PROCEDURE To start the calibration procedure, enter the desired rate to be distributed per hectare in the field Manure Rate and then click on ATTENTION: Before beginning the calibration procedure, make sure that all the manure distributors are not clogged / stuffed with any impurity that might impair the material collection.
- Page 12 Easytech - planting If anything wrong occurs, immediately press to cancel the procedure and the transmission stops spinning. As soon as the procedure is concluded, a new war- ning will be displayed informing that the collection was conclu- ded and that all the collected material should be weighted and inserted in the next screen.
-
Page 13: Brachiaria Gauging
3060/70 - 3080/90 - 7080/90PD Make sure that the procedure was correct and vali- date the result clicking on (Yes) in the function again. If you are not sure of the procedure performed, click on (No) in the function To confirm the calibration, click on 3.4 - Brachiaria Gauging NOTE: This function will be enabled only in machines that have brachiaria deposit. -
Page 14: Pneumatic Springs Configuration
Easytech - planting NOTE: In this procedure, only the seed transmission shaft will spin. After the end of the collection time, it will stop by itself. After the samples have been collected, weight them individually and compare the results with the reference on the display “Doser adjustment to obtain”. -
Page 15: Deposits Volumetric Reference
3060/70 - 3080/90 - 7080/90PD SYMBOL FOR STOP MOTOR STOP MOTOR ACTUATION BUTTON In the main screen, press to power on the motors. 3.7 - Deposits Volumetric Reference The Easytech system has two volumetric indicators for seed and manure deposits available to the operator. -
Page 16: Machine A Or B Section Manual Power Off
Easytech - planting Function indicators (green color) - Rows OK. (red color) - Rows with problem. (yellow color) - Attention: Temporary failure in a row. (red color) - One or more rows with problem. 3.9 - Machine A or B Section Manual Power Off This function is available only for the combined machines configuration, where, without leaving the tractor, the operator can power off the machine A or the machine B manually in the display to perform the finishing in the area to prevent undesired overlapping, etc. -
Page 17: Operational Clock
3060/70 - 3080/90 - 7080/90PD NOTE: To activate the section again, click on for the machine A and for the machine B. When deactivating any section, the symbol will be displayed permanently on the work screen indication that any of the sections is deactivated. 3.10 - Operational Clock To view the Easytech system operational report, click on the work screen in In this screen, the following information is available... -
Page 18: Modo De Teste - Rpm Dos Motores
Easytech - planting AVAILABLE TO THE OPERATOR AVAILABLE ONLY FOR AUTHORIZED TECHNICIANS ATTENTION: Only The basic and necessary configurations are accessible to the Easytech system user. The other configurations are protected by passwords so that the equipment misuse does not occur. Only authorized and properly trained and qualified Technicians can have access to the respective changes. -
Page 19: Test Mode - Seeds Monitor
3060/70 - 3080/90 - 7080/90PD 4.1.1 - Test mode - Seeds Monitor After selecting the test mode option and the seeds monitor measurement, pass the cleaning brush inside the seeds conductor, as soon as the equipment issues a sound signal and indicates a quantity of seeds in the display. If it occurs, the sensor is operating correctly. -
Page 20: Planter Adjustment
Easytech - planting 4.2 - Planter Adjustment To enter in the planter adjustment icon in the main screen, press the adjustment menu icon , then “Adjust planter”. In the option “Adjust planter”, we have: - Collection recipient volume This option changes the volume to be collected, the seed deposit level is used as reference. - Number of custom holes Create an new disc in the case it is not in the pre-configured drilling - Low population error... -
Page 21: Occurrences, Possible Causes And Solutions
3060/70 - 3080/90 - 7080/90PD 5 - OCCURRENCES, POSSIBLE CAUSES AND SOLUTIONS Occurrences Possible Causes Note Solutions Battery low voltage Change the battery / alternator Monitor does not power on Power cables C1 in short-circuit / broken Use of multimeter Replace the power cable C1 Fuse 15A blown out Change the fuse 15A... - Page 22 Easytech - planting SEEDS MONITORING Occurrences Possible Causes Note Solutions Power cable (CM1 PWR) 12v of the Use of multimeter seed module (broken or improperly / check for fitted) connectors improperly fitted Communication cable (CM1 Can) of / connectors pins module (broken or improperly fitted) Clean and check the insulated by dirty...
