Technical Data - Mutec MC-3+ Smart Clock Operating Manual

Appendix XX XX

Technical Data

Word Clock & 10.0 MHz Input (WCLK + 10.0M)
Interface
Formats & Resolutions
Supported Sampling Rates
AES3 Audio Input (AES3/11 IN)
Interface
Format, Resolution
Supported Sampling Rates
S/P-DIF Optical Audio Input (S/P-DIF IN, OP)
Interface
Format, Resolution
Supported Sampling Rates
S/P-DIF RCA Audio Input (S/P-DIF IN, CO)
Interface
Format, Resolution
Supported Sampling Rates
Word Clock Output (WCLK OUT 1–3)
Interface
Format, Resolution
Supported Sampling Rates
AES3/11 Output (AES3/11 OUT 5)
Interface
Format, Resolution
Supported Sampling Rates
S/P-DIF Optical Audio Output (S/P-DIF OUT 4, OP)
Interface
Format, Resolution
Supported Sampling Rates
S/P-DIF RCA Audio Output (S/P-DIF OUT 4, CO)
Interface
Format, Resolution
Supported Sampling Rates
Signal Processing
Digital Audio Format &
Clock Signal Conversion
Frequency Synthesis & Reference Clock Specifications
Frequency Synthesis
Oscillator Type
Clock Accuracy (shipped)
Clock Jitter
Operating Temperature
20
1 x BNC, 200 mV-7 V, unbalanced, input impedance 75 Ω (can be switched off, see Page 18/19)
Word Clock, Word Clock × 256, so-called »Super Clock«, 10.0 MHz
32.0 kHz to 192.0 kHz, 10.0 MHz,
1 x XLR female, transformer balanced, input impedance 110 Ω, 200 mV–7.0 V
AES3-1992/2003, AES11-1997/2003, IEC 60958, 16–24 bits
32.0 kHz to 192.0 kHz
1 x Toslink , EIAJ RC-5720
TM
IEC 60958, 16–24 bits
32.0 kHz to 192.0 kHz
1 x Coaxial (RCA female), unbalanced, 0.5 –1.0 Vpp @ 75 Ω, output impedance 75 Ω
IEC 60958, 16–24 bits
32.0 kHz to 192.0 kHz
1 x BNC, 200 mV–7 V, unbalanced, input impedance 75 Ω
Word Clock, Word Clock × 256, so-called »Super Clock«
32.0 kHz to 192.0 kHz
1 x XLR male, transformer balanced, 3.5Vpp @ 110Ω, output impedance 110 Ω, buffered
AES3-1992/2003, AES11-1997/2003, IEC 60958, 16–24 bits
44.1 kHz to 192.0 kHz
1 x Toslink , EIAJ RC-5720
TM
IEC 60958, 16–24 bits
44.1 kHz to 192.0 kHz
1 x Coaxial (RCA female), unbalanced, 0.5 Vpp @ 75 Ω, output impedance 75 Ω, buffered
IEC 60958, 16–24 bits
44.1 kHz to 192.0 kHz
Word Clock + AES11 conversion in every combination and direction
AES3 + AES11 + S/P-DIF (optical + coaxial) conversion in every combination and direction
10.0 MHz to Word Clock and AES11 conversion
Digital audio re-clocking, internally- and externally-referenced
MUTEC's propritary 1G-Clock Technology based on highest-clocked DDS process
XO, digitally-compensated crystal oscillator
< ± 0.1 ppm
< 1 ps (RMS)
0 °C to + 50 °C
