Hubbell NX Distributed Intelligence NXSMP-LMO Installation And Operation Instructions

PRECAUTIONS
Read and understand all instructions before beginning installation.
• CAUTION: FOR USE WITH CLASS 2, LOW VOLTAGE SYSTEMS ONLY. DO NOT USE IN HIGH VOLTAGE APPLICATIONS.
• NOTICE: Class 2 Device, 12-24V, 10mA
• NOTICE: Raintight Device
• NOTICE: Suitable for Use in Other Environmental Air Space (Plenums) in Accordance with Section 300.22, (C) of the National Electrical Code.
• NOTICE: For installation by a licensed electrician in accordance with National and/or local Electrical Codes and the following instructions.
• Confirm device ratings are suitable for application prior to installation. Use of device in applications beyond its specified ratings or
in applications other than its intended use may cause an unsafe condition and will void manufacturer's warranty.
• Use only approved materials and components (i.e. wire nuts, electrical box, etc.) as appropriate for installation.
• NOTICE: Do not install if product appears to be damaged.
• FCC ID: YH9NXSMP IC: 9044A-NXSMP
• This device complies with FCC part 15 Rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference,
2. This device must accept any interference received, including interference that may cause undesired operation.
• FCC Interference Statement (Part 15.105 (b))
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
• FCC Part 15 Clause 15.21: Changes or modifications not expressly approved by the party responsible for compliance could void the user's
authority to operate the equipment.
• ISED RSS-Gen Notice:
This device complies with Industry Canada's licence-exempt RSSs. Operation is subject to the following two conditions:
1. This device may not cause interference; and
2. This device must accept any interference, including interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux
deux conditions suivantes:
1. l'appareil ne doit pas produire de brouillage;
2. l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre
le fonctionnement.
SAVE THESE INSTRUCTIONS!
Copyright © 2018 Hubbell Control Solutions, a division of Hubbell Lighting, Inc. All rights reserved. All product and company names, logos and product
identifiers are trademarks ™ or registered trademarks ® of Hubbell Lighting, Inc. or their respective owners. Use of them does not necessarily imply any
NXSMP-LMO Low Mount Outdoor Smart Sensor Module
NXSMP-HMO Low Mount Outdoor Smart Sensor Module
701 Millennium Blvd. | Greenville, SC 29607 | (864) 678-1000 | (866) 898-0131 - fax www.hubbellcontrolsolutions.com
affiliation with or endorsement by such respective owners.
INSTALLATION AND OPERATION INSTRUCTIONS
72-00629 Rev F
3603B 020218
