500 Series Extended Coil Capability

The Extended Coil manifolds must be connected to a G3 Electronics Node to operate. Not all G3
supported protocols will support the Extended Coil Manifolds. Below is a list of the hardware and
minimum firmware levels that support the Extended Coil Manifolds.
Extended Solenoid Coil Capability requirements:
Module
Communication Module
Valve Driver Module
Module firmware revision levels can be confirmed in the integrated graphic display and the built-in web browser. See pg.
46 for more information.
9.6

Extended Coil Configuration

The Extended Coil Manifold can be configured to control 3 additional extended coil valve driver
assemblies; unless already configured from the factory. Modify the configuration with either the graphic
display interface as shown on page 34 or using the integrated web server configuation page shown on
page 83.
Number of Extended
Valve Series
501
502/503
G3 Series EtherNet/IP
Part Number
240-325
P599AE508827001
Total number of coils
Coil Valve Drivers
0
1
2
3
0
1
2
3
TDG3EDM1-6EN
Subject to change without notice
www.asco.com/g3
TM
DLR Technical Manual
Firmware
Rev 1.01 Build 42509
Rev 4.019
Configuration
Selection
3-32 32 coils
33-64 64 coils
65-96 96 coils
97-128 128 coils
1-32 32 coils
33-48 64 coils
49-64 64 coils
65-80 96 coils
