G3 Series EtherNet/IP
DLR Technical Manual
Terminator Module
•
Used to terminate SUB-BUS connections.
•
Must be installed on the left side of the last Sub-Bus module.
Description
Part Number
Terminator Module with Din Rail Mounting
240-245
Terminator Module without Din Rail Mounting
240-184
•
The terminator must be installed in the G3 system for proper operation.
NOTE!
TDG3EDM1-6EN
3/18
Subject to change without notice
6-54
www.asco.com/g3
