FlameGard® 5 MSIR HART
Multi-Spectral Infrared
Flame Detector
HART Communication with the
FlameGard 5 Multi-spectral
Infrared Detector
The information and technical data disclosed in this
document may be used and disseminated only for
the purposes and to the extent specifically
authorized in writing by MSA.
Instruction Manual
MSA reserves the right to change published
specifications and designs without prior notice.
Part No.
Revision
MAN5MSIRH
0
Advertisement
Table of Contents
Related Manuals for MSA FlameGard 5 MSIR HART
Summary of Contents for MSA FlameGard 5 MSIR HART
- Page 1 The information and technical data disclosed in this document may be used and disseminated only for the purposes and to the extent specifically authorized in writing by MSA. Instruction Manual MSA reserves the right to change published specifications and designs without prior notice. Part No. MAN5MSIRH Revision...
-
Page 2: Table Of Contents
FlameGard 5 MSIR HART Table of Contents 1.0 INTRODUCTION ........................1 Scope ............................1 Purpose............................1 Who should use this document?....................1 References..........................1 2.0 DEVICE IDENTIFICATION ..................... 1 3.0 PRODUCT OVERVIEW ......................2 Getting Started ...........................2 4.0 PRODUCT INTERFACES ...................... 3 Process Interface ........................3 Host Interface..........................3... - Page 3 FlameGard 5 MSIR HART 10.13 Command #140: Read Alarm Delay (MODBUS Reg 0x5B) ............12 10.14 Command #141: Set Alarm Delay (MODBUS Reg 0x5B) ............13 10.15 Command #142: Read Time Stamp (MODBUS Reg 0x6A, 0x6B, 0x6C) .......14 10.16 Command #143: Read Event Logging Counters (MODBUS Reg 0xA8, 0xB0, 0xB8, 0xC0)..14 10.17...
- Page 4 FlameGard 5 MSIR HART 12.9 Operating Modes........................35 12.10 Write Protection........................35 13.0 ANNEX A. CAPABILITY CHECKLIST ..............35 14.0 ANNEX B. DEFAULT CONFIGURATION ..............36 15.0 ANNEX C. DEVICE DESCRIPTOR LANGUAGE MENU ......... 37...
- Page 5 FlameGard 5 MSIR HART Table of Tables Table 1: Field Device Identification Data........................ 1 Table 2: Error Status Information ........................... 4 Table 3: FlameGard 5 MSIR – Common Practice Commands ................6 Table 4: FlameGard 5 MSIR – Device Specific Commands ................29 Table 5: FlameGard 5 MSIR - Operating Mode - PV Values ................
-
Page 6: Introduction
DOCUMENT RELATIONSHIP This is used to insure compliance with the HART HART Communications Communication Protocol. Protocol Specifications This is the MSA FlameGard 5 MSIR Product Instruction FlameGard 5 MSIR Manual. Instruction Manual Device Identification The following Table 1 is the Field Device Identification Data for the instrument. -
Page 7: Product Overview
Category Product Overview The FlameGard 5 MSIR is a Multi-Spectral Infrared (MSIR) Flame Detector from MSA. The FlameGard 5 MSIR employs state-of-the-art infrared detectors and a sophisticated Artificial Neural Network (ANN) to produce a system that is highly immune to false alarms such as, arc-welding, hot objects, and other sources of radiation. -
Page 8: Product Interfaces
FlameGard 5 MSIR HART Product Interfaces Process Interface This section describes all interfaces between the devices and the measured process. 4.1.1 Sensor Input Channels The unit’s pyroelectric sensors continually collect data at predetermined wavelengths. These are interpreted by an advanced Artificial Neural Network algorithm to detect flame within the field of view and to reject signals from false flame sources. -
Page 9: 7.0 Status Information
FlameGard 5 MSIR HART 7.0 Status Information The error status, which is returned via Common Practice Command #48, is shown in Table 2 and corresponds to MODBUS register 0x01. This also shows any COPM Faults. These bits may be set at power up to indicate an instrument failure. -
Page 10: 8.0 Universal Commands
FlameGard 5 MSIR HART Byte Description Class Device Status Bits Set Not Used Not Used Not Used Not Used Not Used Not Used Not Used Not Used Maintenance Required Error Not Used Not Used Not Used Not Used Not Used... -
Page 11: 9.0 Common Practice Commands
FlameGard 5 MSIR HART 9.0 Common Practice Commands The following common practice commands are implemented. Supported Commands The following common-practice commands shown in Table 3 are implemented: Table 3: FlameGard 5 MSIR HART – Common Practice Commands Command Byte Meaning Number... -
Page 12: 10.0 Device Specific Commands
10.0 Device Specific Commands The Device Specific commands are used strictly for the unique features of the FlameGard 5 MSIR and at the discretion of MSA. They are described here in section 10.0 and are summarized in Table 4 10.1 Command #128: Read DIP Switch Override Register (MODBUS Reg 0x07) Read the DIP Switch Override Register. -
Page 13: Command #130: Read Dip Switch Settings Register (Modbus Reg 0X46)
FlameGard 5 MSIR HART Code Class Description Success No Command-Specific Errors 1- 2 Undefined Error Passed Parameter Too Large 4 – 127 Undefined Error Too Few Data Bytes Received 10.3 Command #130: Read DIP Switch Settings Register (MODBUS Reg 0x46) Reads the DIP Switch Settings Register. -
Page 14: Command #132: Write Unit Options Register (Modbus Reg 0X08)
FlameGard 5 MSIR HART Code Class Description Success No Command-Specific Errors 1-127 Undefined 10.5 Command #132: Write Unit Options Register (MODBUS Reg 0x08) Write the Unit Options Register. Request Data Bytes Byte Format Description Bits Unit Options – See Table 10... -
Page 15: Command #134: Clear Copm Faults (Modbus Reg 0X13)
FlameGard 5 MSIR HART Command-Specific Response Codes Code Class Description Success No Command-Specific Errors 1-127 Undefined 10.7 Command #134: Clear COPM Faults (MODBUS Reg 0x13) Clear the COPM Faults Register. Request Data Bytes Byte Format Description None Response Data Bytes... -
Page 16: Command #137: Read Instrument Temperature (Modbus Reg 0X14)
FlameGard 5 MSIR HART Test the Remote Alarm. Request Data Bytes Byte Format Description Bits Test Remote Alarm: 0 = Turn off, 1 = Turn on Alarm Response Data Bytes Byte Format Description Bits Test Remote Alarm: 0 = Alarm Off, 1 = Alarm On... -
Page 17: Command #139: Read Test Lamp Mode (Modbus Reg 0X5A)
FlameGard 5 MSIR HART Set/Reset the Test Lamp Mode. Request Data Bytes Byte Format Description Bits Set/Reset Test Mode: 1 = Test Mode, 0 = Non-Test Mode Response Data Bytes Byte Format Description Bits Test Mode: 1 = Test Mode, 0 = Non-Test Mode... -
Page 18: Command #141: Set Alarm Delay (Modbus Reg 0X5B)
FlameGard 5 MSIR HART Read the Alarm Delay. Request Data Bytes Byte Format Description None Response Data Bytes Byte Format Description Unsigned-8 Alarm Delay Command-Specific Response Codes Code Class Description Success No Command-Specific Errors 1 – 127 Undefined 10.14 Command #141: Set Alarm Delay (MODBUS Reg 0x5B) Set the Alarm Delay. -
Page 19: Command #142: Read Time Stamp (Modbus Reg 0X6A, 0X6B, 0X6C)
FlameGard 5 MSIR HART 10.15 Command #142: Read Time Stamp (MODBUS Reg 0x6A, 0x6B, 0x6C) Read the last time that the test lamp check was successfully performed. Request Data Bytes Byte Format Description None Response Data Bytes Byte Format Description... -
Page 20: Command #143: Read Event Logging Counters (Modbus Reg 0Xa8, 0Xb0, 0Xb8, 0Xc0)
FlameGard 5 MSIR HART Code Class Description Success No Command-Specific Errors 1-127 Undefined 10.17 Command #144: Clear Event Logging Counters (MODBUS Reg 0xC1) This resets the event logging counters to zero – effectively clearing out the event logs of all of the previous information. -
Page 21: Command #146: Read Alarm Event Log
FlameGard 5 MSIR HART Command-Specific Response Codes Code Class Description Success No Command-Specific Errors 1-127 Undefined 10.19 Command #146: Read Alarm Event Log Read Alarm Event Log as specified by the event log number. Event 0 is the most recent event. Event 1 is the one just before that and so forth. -
Page 22: Command #148: Read Maintenance Event Log
FlameGard 5 MSIR HART Response Data Bytes Byte Format Description 0 - 3 Unsigned-32 Event Running Time (in Seconds) 4 - 6 Date Event Date – Day, Month, Year – 1900 Unsigned-8 Event Hour Unsigned-8 Event Minute Unsigned-8 Event Second Unsigned-8 Event Cause –... -
Page 23: Command #149: Set Clock
FlameGard 5 MSIR HART 10.22 Command #149: Set Clock Set the internal real-time clock. Request Data Bytes Byte Format Description 0 – 2 Date Date in Day, Month, Year-1900 Unsigned-8 Hours Unsigned-8 Minutes Unsigned-8 Seconds Response Data Bytes Byte Format Description 0 –... -
Page 24: Command #151: Set Run Time Meter
FlameGard 5 MSIR HART Command-Specific Response Codes Code Class Description Success No Command-Specific Errors 1-127 Undefined 10.24 Command #151: Set Run Time Meter Set the internal run time meter. Request Data Bytes Byte Format Description 0 - 3 Unsigned-32 Run Time Meter Value... -
Page 25: Command #153: Read Power Cycle Flag
FlameGard 5 MSIR HART 10.26 Command #153: Read Power Cycle Flag Read the Power cycle flag. This flag is set equal to one whenever the power is cycled to the unit. When the clock is set via either by command number 149 or 151, this flag is reset to zero. -
Page 26: Command #155: Read Event Log Index
FlameGard 5 MSIR HART 10.28 Command #155: Read Event Log Index Read the Event Log Index to a specified value. This index is used by commands 145, 146, 147, & 148 to retrieve the event information stored in the instrument. The events are accumulated automatically by the instrument. -
Page 27: Command #157: Set Warning Relay Latched Status
FlameGard 5 MSIR HART 10.30 Command #157: Set Warning Relay Latched Status This sets the warning relay to either latched or un-latched. If the DIP override flag is set, then the command will return an ACCESS RESTRICTED code. Request Data Bytes... -
Page 28: Command #160: Read Warning Relay De-Energized/Energized Status
FlameGard 5 MSIR HART Request Data Bytes Byte Format Description Response Data Bytes Byte Format Description Unsigned-8 Relay setting: 1 = Energized, 0 = De-Energized Command-Specific Response Codes Code Class Description Success No Command-Specific Errors 1 - 15 Undefined Error... -
Page 29: Command #162: Read Alarm Relay Latched Status
FlameGard 5 MSIR HART Response Data Bytes Byte Format Description Unsigned-8 Alarm Relay Status: 1 = Latched, 0 = Unlatched Command-Specific Response Codes Code Class Description Success No Command-Specific Errors 1 - 15 Undefined Error Write Protect Mode 17 - 127 Undefined 10.35... -
Page 30: Command #164: Read Alarm Relay De-Energized/Energized Status
FlameGard 5 MSIR HART Command-Specific Response Codes Code Class Description Success No Command-Specific Errors 1 - 15 Undefined Error Access Restricted 17 - 127 Undefined 10.37 Command #164: Read Alarm Relay De-Energized/Energized Status This reads the Energized/De-Energized status of the alarm relay. -
Page 31: Command #166: Read Sensitivity Level
FlameGard 5 MSIR HART Command-Specific Response Codes Code Class Description Success No Command-Specific Errors 1 -15 Undefined Error Access Restricted 17-127 Undefined 10.39 Command #166: Read Sensitivity Level This reads the unit sensitivity. It may have values of high, medium, or low. -
Page 32: Command #168: Read Error Status
FlameGard 5 MSIR HART Command-Specific Response Codes Code Class Description Success No Command-Specific Errors 1-127 Undefined 10.41 Command #168: Read Error Status Read the Instrument Error Status. This is similar to MODBUS Register 0x02 except that the errors are prioritized as listed in the description. -
Page 33: Command #170: Read Analog Voltage
FlameGard 5 MSIR HART Command-Specific Response Codes Code Class Description Success No Command-Specific Errors 1-127 Undefined 10.43 Command #170: Read Analog Voltage This replicates the functionality of Command #2 for the AMS. Request Data Bytes Byte Format Description Response Data Bytes... -
Page 34: Tables
FlameGard 5 MSIR HART 11.0 Tables 11.1 FlameGard 5 MSIR – Device Specific Commands Summary The following Table 4 is a summary of the FlameGard 5 MSIR Device Specific Commands. The Reg values in the Meaning Column denote the corresponding MODBUS Register. -
Page 35: Flamegard 5 Msir - Operating Mode - Pv Values
FlameGard 5 MSIR HART Command Byte Number Meaning Number Command 148 Read Maintenance Event Log Register Command 149 Set Clock Command 150 Read Clock Command 151 Set Run Time Meter Command 152 Read Run Time Meter Command 153 Read Power Cycle Flag... -
Page 36: Copm Fault Register
FlameGard 5 MSIR HART Primary Variable Value Operating Mode in Decimal Warn Latching Only, Alarm Off Alarm Latching Only Warn & Alarm Latching Ready State Alarm Test COPM Fault Detected Warn Latching, Alarm Non-latching, Alarm On Test Lamp Cycle Test Lamp Cycle – Fire 11.3... -
Page 37: Dip Switch Settings Register
FlameGard 5 MSIR HART Table 8: Maintenance Event Log – Cause Description Bits Cause Test Lamp Successful Calibrate 1 – 15 11.6 DIP Switch Settings Register The following Table 9 describes the description of the unit options registers: Table 9: DIP Switch Settings Register Description... -
Page 38: Unit Options Settings Register
FlameGard 5 MSIR HART 11.7 Unit Options Settings Register The following Table 10 describes the description of the unit options registers: Table 10: Unit Options Settings Off = 0, On = 1, De = De-energized, En = Energized, La = Latched, NL = Non-Latched... -
Page 39: Performance
FlameGard 5 MSIR HART 12.0 Performance 12.1 Sampling Rates The FlameGard 5 MSIR Flame Detector samples each detector at 10 msec intervals. 12.2 Power-up On power up, the FlameGard 5 MSIR Flame Detector executes a self-test procedure, which requires approximately 15 seconds. During this time, the analog output is set to 3.5mA. After the self-test is satisfactorily completed, the unit sets the PV to a value representing the mode of the instrument. -
Page 40: Operating Modes
FlameGard 5 MSIR HART 12.9 Operating Modes The FlameGard 5 MSIR reports flame detection by setting the instrument in a series of different modes. 12.10 Write Protection The FlameGard 5 MSIR does not support any write protection mode. 13.0 Annex A. Capability Checklist... -
Page 41: Annex B. Default Configuration
FlameGard 5 MSIR HART 14.0 Annex B. Default Configuration Table 13: Default Configuration Parameter Default value Lower Range Value Upper Range Value PV Units FlameGard 5 MSIR Operating Mode Sensor type Pyroelectric Infrared Number of wires Damping time constant Fault-indication jumper... -
Page 42: Annex C. Device Descriptor Language Menu
FlameGard 5 MSIR HART 15.0 Annex C. Device Descriptor Language Menu... - Page 43 MINE SAFETY APPLIANCES COMPANY CRANBERRY TOWNSHIP, PENNSYLVANIA, USA 16066 1-800-MSA-INST www.msanet.com...
