USER MANUAL
NI 9760
NI Powertrain Controls VR/Hall Sensor Module (Rev C)
Contents
Introduction .............................................................................................................................. 1
Pinout........................................................................................................................................ 2
Hardware .................................................................................................................................. 2
Powering the Module................................................................................................................ 2
Platform Compatibility ............................................................................................................. 3
Input Channels Used for VR Sensor Inputs.............................................................................. 3
Input Channels Used for Hall-Effect Sensor Inputs ................................................................. 5
Custom Configuration .............................................................................................................. 6
Physical Specifications and Characteristics ............................................................................. 6
Electrical Specifications and Characteristics............................................................................ 6
Compliance and Certifications ................................................................................................. 7
