Akaso V50X User Manual

Hide thumbs Also See for V50X:

Advertisement

Table of Contents

USER MANUAL
AKASO V50X Action Camera
V1.3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the V50X and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Akaso V50X

Summary of Contents for Akaso V50X

  • Page 1 USER MANUAL AKASO V50X Action Camera V1.3...

  • Page 2: Table Of Contents

    CONTENTS What’s in the Box Your V50X Getting Started Overview of Modes Customizing Your V50X Connecting to the App Playing Back Your Content Deleting Your Content Offloading Your Content Maintaining Your Camera Maximizing Battery Life Battery Storage and Handling Remote...

  • Page 3: What's In The Box

    Mount 3 Mount 4 Mount 5 Helmet Mounts Mount 6 Mount 7 Mount 8 Protective Backdoor USB Cable Battery Charger Remote Bandages Tethers Lens Cloth Quick Start Guide AKASO V50 Pro Action Camera Wrist Strap for Remote Quick Start Guide...

  • Page 4: Your V50X

    YOUR V50X...
  • Page 5 Shutter/Select Button Lens Indicator Screen Power/Mode Button Up Button MicroSD Card Slot Speaker Micro USB Port Down Button Micro HDMI Port Battery Door Note: The camera does not record sound when it is in the waterproof case.

  • Page 6: Getting Started

    GETTING STARTED Welcome to your AKASO V50X. To capture videos and photos, you need a microSD card (sold separately) to start recording. MicroSD Cards Please use brand name memory cards that meet these requirements: • microSD, microSDHC or microSDXC • UHS-III rating •...

  • Page 7: Overview Of Modes

    OVERVIEW OF MODES There are 9 modes: Photo, Self-Timer, Burst Photo, Time Lapse Photo, Video, Slow Motion, Time Lapse Video, Still Photo and Driving Mode. Tap here Photo Mode Press the Mode button or tap the shooting mode area on the screen to switch to Photo Mode after you turn on the camera.
  • Page 8 Self-Timer Mode Press the Mode button or tap the shooting mode area on the screen to switch to Self-Timer Mode after you turn on the camera. In Self-Timer mode, press the Shutter button, it takes a self-timer photo. Press and hold the Up or Down button to adjust the zoom level.
  • Page 9 Time Lapse Photo Mode In Time Lapse Photo Mode, press the Shutter button, it captures a series of photos at specific intervals. Use this mode to capture photos of any activity, then choose the best ones later. Press and hold the Up or Down button to adjust the zoom level.
  • Page 10 Slow Motion Mode In Slow Motion Mode, press the Shutter button, the camera records slow-motion video. Press and hold the Up or Down button to adjust the zoom level. Slow Motion 1080P90fps Time Lapse Video Mode In Time Lapse Video Mode, press the Shutter button, the camera records video from frames captured at specific intervals.
  • Page 11 Still Photo Mode In Still Photo mode, press the Shutter button, the camera starts recording video, and it will take photos automatically during video recording. Press and hold the Up or Down button to adjust the zoom level. Still Photo 4K30fps Driving Mode In Driving Mode, you connect the camera with car cigarette lighter, the camera will...

  • Page 12: Customizing Your V50X

    CUSTOMIZING YOUR V50X Video Settings 1. Resolution: 4K30fps/2.7K30fps/1080P90fps/1080P60fps/1080P30fps/ 720P120fps/720P60fps/720P30fps Default setting is 4K30fps. Note: When capturing video at high resolutions or high frame rates in warm ambient temperatures, the camera may become warm and use more power. 2. Image Stabilization: OFF/ON Default setting is off.
  • Page 13 6. Still Photo: 4K30fps Default setting is 4K30fps. 7. Still Photo Time: 3 Sec/5 Sec/10 Sec/30 Sec Default setting is 3 Sec. In still photo mode, the camera takes a photo every 3 Sec/5 Sec/10 Sec/30 Sec automatically during video recording. 8.
  • Page 14 12. Exposure Value: -2/-1.7/-1.5/-1.3/-1/-0.5/-0.3/0/+0.3/+0.5/+1/+1.3/+1.5/+1.7/+2 Default setting is 0. By default, your camera uses the entire image to determine the appropriate exposure level. However, Exposure lets you select an area that you want the camera to prioritize when determining exposure. This setting is particularly useful in shots where an important region might otherwise be over- or underexposed.
  • Page 15 Photo Settings 1. Resolution: 20MP/12MP/8MP/5MP/3MP Default setting is 20MP. 2. Output Format: JPEG/JPEG+DNG Default setting is JPEG. DNG file extension refers to a raw Image format. The image data is uncompressed and kept in a lossless state. 3. Self-Timer: 1 Sec/3 Sec/5 Sec/10 Sec/30 Sec Default setting is 3 Sec.
  • Page 16 camera to prioritize when determining exposure. This setting is particularly useful in shots where an important region might otherwise be over- or underexposed. 8. Exposure Time: Auto/2 Sec/5 Sec/10 Sec/30 Sec Default setting is Auto. The exposure time, respectively period of exposure means the time span for which the film of a traditional camera or a sensor of a modern digital camera is actually exposed to the light so as to record a picture.
  • Page 17 12. Sharpness: Strong/Normal/Soft Default setting is Normal. Sharpness controls the quality of details captured in your video footage or photos. 13. Color: Natural/Black & White/Sepia Default setting is Natural. 14. Photo Quality: Fine/Normal/Economy Default setting is Fine. System Settings 1. Sounds: Volume/Key Tone/Touch Tone/Boot Tone You can adjust the volume of the camera and turn on/off...
  • Page 18 5. WDR: ON/OFF Default setting is OFF. Wide Dynamic Range (WDR) retains a greater level of detail in the dark and bright areas of an image. The result is a photo that is properly exposed for both of these extremes. This setting is especially useful for scenes that are backlist or that have large bright regions and a dark foreground.
  • Page 19 16 Set Date: MM/DD/YYYY You can set the date of the camera. 17. Reset: Reset to factory? Cancel/Confirm This option resets all settings to their default values. 18. About: Model/Version You can check the model and version of your V50X.

  • Page 20: Connecting To The App

    2. Connect the Wifi “V50X” and enter the password on your smartphone WLAN setting. 3. Open the AKASO GO app, tap “+” icon on the upper right corner. Add “V50X” and click the “Live Preview”. 4. Your camera will be connected with the AKASO GO app.

  • Page 21: Playing Back Your Content

    4. To exit Playback mode, tap Return icon or press the Mode button. Deleting Files on AKASO App 1. Open the AKASO GO app. Connect the camera with the app. 2. Tap Playback icon to see all the videos and photos.

  • Page 22: Offloading Your Content

    files by using file explorer. Offloading Your Content to Smartphone 1. Open the AKASO GO app. Connect the camera with the app. 2. Tap Playback icon to see all the videos and photos. 3. Select the photo or video you want to download and then tap the More icon at the right upper corner, and choose Download.

  • Page 23: Maximizing Battery Life

    MAXIMIZING BATTERY LIFE If the battery reaches 0% while recording, the camera will save the file and power off. To maximize battery life, follow these guidelines when possible: • Turn off Wireless Connections • Capture video at lower frame rates and resolutions •...

  • Page 24: Remote

    REMOTE Photo Button Video Button Splashproof only, not waterproof VIDEO To record a video, verify the camera is in Video mode. To start recording: Press the gray Video button. The camera beeps and the camera light flashes while recording. To stop recording: Press the gray Video button again.
  • Page 25 CR2032 BATTERY REPLACEMENT FOR REMOTE 1. Remove the 4 screws on the back cover of the remote with a 1.8mm Phillips tip screwdriver. 2. Remove another 4 screws on PCB board. 3. Lift the PCB board and slide out the battery, as shown in the picture. Note: Do NOT rotate the PCB board to avoid reversing the camera and video button functions.

  • Page 26: Mounting Your Camera

    4. Install the new battery, keeping the “+” pole facing up. 5. Install all 4 screws back onto the PCB board. 6. Install all 4 screws back into the cover. MOUNTING YOUR CAMERA Attach your camera to helmets, gear and equipment.

  • Page 28: Contact Us

    CONTACT US For any inquiries with AKASO products, please feel free to contact us, we will respond within 24 hours. E-mail: cs@akasotech.com Tel: (888) 466-9222 (US) Mon-Fri (except holiday) 9am-5pm (EST) Official website: www.akasotech.com The microSD, microSDHC, microSDXC and SD marks and logos are trademarks of...
