Summary of Contents for Akaso V50 ELITE

  • Page 1 V50 ELITE A C T I O N C A M E R A V39-K...

  • Page 2: Table Of Contents

    Your V50 Elite----------------------------------------------------------------------------------- 04 Getting Started--------------------------------------------------------------------------------- 06 Overview of Modes--------------------------------------------------------------------------- 08 Customizing Your V50 Elite ---------------------------------------------------------------- 10 Controlling Your V50 Elite with Your Voice------------------------------------------- 18 Connecting to the AKASO GO App ------------------------------------------------------ 20 Playing Back Your Content----------------------------------------------------------------- 21 Offloading Your Content ------------------------------------------------------------------- 23...

  • Page 3: What's In The Box

    What’s in the Box AKASO V50 Elite Waterproof Battery Charger Battery USB Cable Housing x 1 Remote Control Protective Bandage Helmet Mount 1 Helmet Mount 2 Backdoor x 1 Buckle Mount J-Hook Mount A Mount C Mount D Mount F Mount...

  • Page 4: Camera Specifications

    Camera Specifications Model V50 Elite Dimensions 61 × 42 × 33mm 2.0-inch TFT LCD Display 320 x 240 Video/Photo Format MOV / JPG Battery life Around 50mins of recording time in 4K. Note: The actual battery life may vary based on the environment and usage.

  • Page 5: Important Messages

    Congratulations on your new AKASO Action Camera V50 Elite! You must be excited to use your AKASO V50 Elite. However, please spend time reading this manual before using it. You need to get to know all the features now so as to get the most out of it.

  • Page 6: Your V50 Elite

    Your V50 Elite 14 3 Shutter / Wifi / Select Button Power / Mode / Exit Button Micro USB Port Memory Card Slot Micro HDMI Port Lens...
  • Page 7 Touch Screen Up Button Down Button Tripod Hole Battery Cover Note: The camera does not record sounds when it is in the waterproof case.

  • Page 8: Getting Started

    Getting Started Welcome to your AKASO V50 Elite. To capture video and photos, you need a memory card (sold separately). Memory Cards Use brand name memory cards that meet these requirements: • microSD, microSDHC, or microSDXC • U3 • Capacity up to 64GB (FAT32) Note: 1.
  • Page 9 To Exit Mode: Press the Mode button to exit mode. Turning on/off Wifi To turn on Wifi: On the preview screen, press and hold the Wifi button to turn on Wifi. You can also tap the Wifi icon in the mode menu to turn on Wifi. The Wifi indicator will be flashing when Wifi...

  • Page 10: Overview Of Modes

    Overview of Modes There are 6 modes of this camera: Video, Time Lapse Video, Slow Motion, Photo, Time Lapse Photo, and Wifi. To access these modes, first turn on the camera. Then, tap the mode at the bottom of the camera screen to enter the mode menu and select the mode you want.
  • Page 11 Slow Motion Mode The camera is capable of recording 00:00:00 | 01:40:51 videos at specific resolutions and zoom levels. For instance, if you select the option 2.7K 2X to shoot a video that lasts for a minute, the camera will generate a 2-minute slow-motion video at 2.7K resolution.

  • Page 12: Customizing Your V50 Elite

    Customizing Your V50 Elite Video Settings 1. Video Resolution 4K 60fps, 4K 30fps, 2.7K 60fps, 2.7K 30fps, 1080P 120fps, 1080P 60fps, 1080P 30fps, 720P 240fps, 720P 120fps, 720P 60fps (Default setting is 4K 60fps) This camera is capable of recording video up to 4K60fps, with higher resolution offering greater clarity and detail due to the increased number of pixels.
  • Page 13 4. Time Lapse Interval Off/1S /3S /5S /10S /30S /1 Min (Default setting is Off) This option enables you to specify the frequency at which the video frames are captured and compiled. The camera will capture series of videos at the set interval, making it ideal for taking photos in dynamic or changing scenes, such as clouds, stars, sunsets, and more.
  • Page 14 When Wind Noise Reduction is enabled, the noise will be lowered to an acceptable level, allowing for better video quality. 9. Microphone Internal/External (Default setting is Internal) You have the option to select either a built-in microphone or an external one. To use an external microphone for better sound quality, select the “External”...
  • Page 15 Photo Settings 1. Photo Resolution 20MP/16MP/12MP/10MP/8MP/5MP (Default setting is 20MP) This camera is capable of capturing 20MP photos, with higher resolution offering greater clarity and detail due to the increased number of pixels. However, higher resolution photo also results in larger file sizes. 2.
  • Page 16 Night Lapse is made to capture time lapse videos in dark and low-light environments. It automatically adjusts the shutter speed to let in more light and picks the interval that will give you the best result. Note: Night Lapse is available only in Time Lapse Photo mode. 7.
  • Page 17 Camera Settings 1. Sounds Shutter: On/Off (Default setting is on) Boot-up: On/Off (Default setting is on) Beep: On/Off (Default setting is on) Volume: 0/1/2/3 (Default setting is 2) You can turn on the shutter, boot-up, beep sounds on or off. 2.
  • Page 18 12. Language English, 日本語 , Deutsch, Italiano, Español, Français, 简体中文 , 繁體中文 (Default setting is English) You can choose the system language for your V50 Elite action camera. 13. Format Card Yes/No (Default setting is No) To keep your memory card in good condition, reformat it on a regular basis.
  • Page 19 Card Info: Capacity/Free Space In the System option, you can check the model, version and updated time of your V50 Elite. The card Info option allows you to check the capacity and free space of your memory card. Warm Tip: Some functions cannot be used at the same time.

  • Page 20: Controlling Your V50 Elite With Your Voice

    Controlling Your V50 Elite with Your Voice This camera allows you to capture photos and videos with a single voice command in any of the 8 supported languages. To control the camera with your voice, you need to enable the voice control feature on the remote. To take advantage of the voice control feature, make sure to keep the remote's microphone within 10 centimeters of your mouth and speak clearly in a quiet environment.
  • Page 21 Action Command Description Action Start Video Starts capturing video Action Stop Shooting Stops capturing video Action Photo Captures a single photo Camera Turn Off Powers off the camera AKASO Wifi on Enables Wifi mode AKASO Wifi off Quit Wifi mode...

  • Page 22: Connecting To The Akaso Go App

    App Store or Google Play to your smartphone first. When your camera is connected to the AKASO GO app, you can control it to capture, or change its settings using your phone. You can also live preview, playback, download, edit, and share videos via this app.

  • Page 23: Playing Back Your Content

    TV. With this method, playback resolution depends on the resolution of the device and its ability to play back that resolution. Viewing Videos or Photos on Your V50 Elite 1. Turn on your camera.
  • Page 24 Note: If your memory card contains a lot of content, it might take a minute to load them. Deleting Videos or Photos on Your V50 Elite 1. Enter the playback mode. 2. Tap video file icon or photo file icon 3.

  • Page 25: Offloading Your Content

    files to your computer or delete selected files using File Explorer. Downloading Your Content to A Smartphone 1. Open the AKASO GO app, then connect it to the camera. 2. Tap the Album icon in the bottom left corner to view all the photos and videos captured by the camera.

  • Page 26: Reformatting Your Memory Card

    Reformatting Your Memory Card To keep your memory card in good condition, reformat it on a regular basis. Reformatting erases all of your content, so be sure to offload your photos and videos first. 1. Turn on your camera, and enter the system settings screen. 2.

  • Page 27: Battery Storage And Handling

    Battery Storage and Handling The camera contains sensitive components, including the battery. Avoid exposing your camera to very cold or very hot temperatures. Low or high temperature conditions may temporarily shorten the battery life or cause the camera to temporarily stop working properly.
  • Page 28 Micro USB Port Splashproof only, not waterproof Button Operation Instructions Before using the remote, make sure it's activated. To do this, simply press any button. Voice Control Button To control the camera using your voice, press the Voice Control button to enable the voice control feature.

  • Page 29: Mounting Your Camera

    Mounting Your Camera Attach your camera to helmets, gear and equipment.

  • Page 30: Contact Us

    Contact Us (888) 466-9222 (US) cs@akasotech.com www.akasotech.com For any inquiries with AKASO products, please feel free to contact us. We will respond within 24 hours.
