Summary of Contents for Akaso V50 Elite
- Page 1 USER MANUAL AKASO V50 Elite Action Camera v1.1...
-
Page 2: Table Of Contents
Connecting Your V50 Elite With Remote Controlling Your V50 Elite With Your Voice Connecting to the AKASO DV App Playing Back Your Content Deleting Videos and Photos on Your V50 Elite Offloading Your Content Offloading Your Content to Smartphone or Tablet Adjusting the Zoom Level... -
Page 3: What's In The Box
Mount 3 Mount 4 Mount 5 Mount 6 Mount 7 Mount 8 Helmet Mounts Battery Charger Protective Backdoor USB Cable Wrist Strap Bandages Tethers Lens Cloth for Remote Quick Start Guide AKASO V50 Elite Action Camera Remote Quick Start Guide... -
Page 4: Your V50 Elite
YOUR V50 ELITE 14 3... - Page 5 Shutter/Wifi/Select Button Touch Screen Power/Mode/Exit Button Up Button Micro USB Port Down Button microSD Slot Tripod Hole Micro HDMI Port Battery Door Lens Note: The camera does not record sound when it is in the waterproof case.
-
Page 6: Getting Started
GETTING STARTED Welcome to your AKASO V50 Elite. To capture videos and photos, you need a microSD card (sold separately). MICROSD CARDS Use brand name memory cards that meet these requirements: • microSD, microSDHC, or microSDXC • UHS-3 rating only •... -
Page 7: Overview Of Modes
TURNING ON/OFF Wifi To turn on Wifi Turn on camera, in Video or Photo Mode press and hold Wifi button for three seconds to turn on Wifi. To turn off Wifi Press and hold Wifi button for three seconds to turn off Wifi. TURNING ON/OFF BT To turn on BT Turn on camera, in Video or Photo Mode press and hold Down button for three... - Page 8 Video Mode Video Mode is the default mode when you turn on the camera. In Video Mode, press Shutter button, the camera starts recording video. Press Shutter button to stop recording video. 00:00:00 | 01:07:55 Video 4K 30fps Time Lapse Video Mode In Time Lapse Video Mode, press Shutter button, the camera takes video at 1 Sec/ 3 Sec/5 Sec/10 Sec/30 Sec/1 Min intervals.
- Page 9 Slow Motion Mode In Slow Motion Mode, Press Shutter button, the camera takes slow motion video. 00:00:00 | 01:40:51 Slow Motion 1080P 120fps Photo Mode Press Mode button once to switch to Photo Mode after you turn on camera. In Photo Mode, press Shutter button, the camera takes a photo. 2 / 3320 Photo 20MP...
- Page 10 Time Lapse Photo Mode In Time Lapse Photo Mode, press Shutter button, the camera takes a serial of photos at 3 Sec/5 Sec/10 Sec/30 Sec/1 Min intervals. 2 / 3220 Time Lapse Photo 20MP Setting Mode Press and hold Up button for 3 seconds to enter Setting Mode. Photo Resolution Time Lapse Interval Time Lapse Duration...
-
Page 11: Customizing Your V50 Elite
CUSTOMIZING YOUR V50 ELITE Video Setting 1. Video Resolution: 4K 60FPS, 4K 30FPS, 2.7K 60FPS, 2.7K 30FPS, 1080P 120FPS, 1080P 60FPS, 1080P 30FPS, 720P 240FPS, 720P 120FPS, 720P 60FPS Default setting is 4K 30FPS. Note: When capturing video at high resolutions or high frame rates in warm ambient temperatures, the camera may become warm and use more power. - Page 12 If you record for 5 minutes and do not press the Shutter button to stop recording and save, the camera records a new 5-minute interval by recording over your previous 5 minutes of footage. When the microSD card is full, the new files will cover the old one if loop recording is on.
- Page 13 9. Wind Noise Reduction: On / Off Default setting is Off. Turn on Wind Noise Reduction, it can lower the noise to an acceptable level. 10. Angle: Wide/Medium/Narrow Default setting is Wide. The angle refers to how much of the scene can be captured through the camera lens.Wide angle captures the largest amount of the scene, while Narrow angle captures the least.
- Page 14 2. ISO: Auto / 100 / 200 / 400 / 800 / 1600 / 3200 Default setting is Auto. ISO determines the camera’s sensitivity to light, and creates a trade-off between brightness and resulting image noise. Image noise refers to the degree of graininess in the image.
- Page 15 8. Long Exposure: Off/1 Sec/2 Sec/5 Sec/8 Sec/30 Sec/1 Min Default setting is Off. Long exposures are easiest to accomplish in low-light conditions, but can be done in brighter light using neutral density filters or specially designed cameras. Note: Long Exposure is disabled when Burst Photo is on. 9.
- Page 16 LCD display again, press any button on the camera. 9. Auto Power Off: Off/1 Min./2 Min. Default setting is 2 Min. Powers off your V50 Elite after a period of inactivity to save battery life. 10. Power-on Auto Record: On/Off Default setting is Off.
- Page 17 14. Reset Wifi Setting: Yes/No Default setting is No. This option can erase the Wifi data of V50 Elite. 15. Language: English, Português, 日本語, Deutsch, Italiano, Español, Français Default setting is English. 16. Format Card: Yes/No Default setting is No.
-
Page 18: Connecting Your V50 Elite With Remote
System Info option let you check the model, version and updated time of your V50 Elite. Card Info option let you check the capacity and free space of your microSD card. Some functions cannot be used at the same time. Please refer to the information below. -
Page 19: Controlling Your V50 Elite With Your Voice
CONTROLLING YOUR V50 ELITE WITH YOUR VOICE You can control your V50 Elite with your voice using a set of specific commands (see list below). Note: Voice Control performance may be impacted by distance, wind, and noisy conditions. Keep the product clean and clear of debris. -
Page 20: Connecting To The Akaso Dv App
Features include full camera control, live preview, playback, download, sharing of content and setting camera. 1. Download AKASO DV app to your mobile device from the Apple App Store or Google Play. 2. Turn on camera, in Video or Photo Mode press and hold Wifi button for three seconds to turn on Wifi. - Page 21 ...7845.JPG ...7843.JPG 5.90MB 4K 30FPS 00:00:02 / 00:05:34...
-
Page 22: Deleting Videos And Photos On Your V50 Elite
DELETING VIDEOS AND PHOTOS ON YOUR V50 ELITE 1. Enter playback mode. 2. Tap video file icon or photo file icon 3. Tap the video or photo file you want to delete. 4. Tap . The screen shows “Delete This File? Yes/No”. -
Page 23: Offloading Your Content To Smartphone Or Tablet
The Zoom function lets you adjust how close or far away the subject appears in your video or photo. The default is no zoom. Zoom function is available in Video mode and Photo mode. V50 Elite can 8X zoom. 1. Turn on V50 Elite. -
Page 24: Reformatting Your Microsd Card
REFORMATTING YOUR MICROSD CARD To keep your microSD card in good condition, reformat it on a regular basis. Reformatting erases all of your content, so be sure to offload your photos and videos first. 1. Turn on camera and enter Camera Setting. 2. -
Page 25: Battery Storage And Handling
BATTERY STORAGE AND HANDLING The camera contains sensitive components, including the battery. Avoid exposing your camera to very cold or very hot temperatures. Low or high temperature conditions may temporarily shorten the battery life or cause the camera to temporarily stop working properly. -
Page 26: Remote
To record Video, verify the camera is in Video mode. Photo Button To capture a photo, verify the camera is in Photo mode. CONNECTING YOUR V50 ELITE WITH REMOTE 1. Turn on camera. 2. Press and hold the Down button for three seconds to turn on BT. The screen shows “BT ON”... -
Page 27: Mounting Your Camera
MOUNTING YOUR CAMERA Attach your camera to helmets, gear and equipment. -
Page 28: Contact Us
CONTACT US For any inquiries with AKASO products, please feel free to contact us, we will respond within 24 hours. E-mail: cs@akasotech.com Tel: (888) 466-9222 (US) Mon-Fri (except holiday) 9am-5pm (EST) Official website: www.akasotech.com The microSD, microSDHC, microSDXC and SD marks and logos are trademarks of...
