Main Structure - Launch TWC-481 Installation And Parts Manual

LAUNCH

Main Structure

A Return spring B
E Clam Jaw F
I Bead breaker J
control pedal
M Tool box N
Q Bead breaker arm S
V Air Pressure Regulator, Gauge and Lubricator Assembly
Swing arm
C Hexagonal bar
Turntable G Stop Screw knob
Turntable control pedal K Hexagonal column
Clamping cylinder O Lube bucket
assembly
T
Bead breaker shovel
D
H
L
locking handle
P
U
Tire lever
2
Tire Changer TWC-481
Mount/demount head
Clamping cylinder control pedal
Column
Bead breaker handle
Inflation pedal
