2-1/8"
DIA.
6 ft. CORD
1
Work
Surface
*Table thickness: 3/4" Min. to 1-5/8" Max.
Measure the thickness of the work surface with
the caliper. (e.g. 25mm or 1")
*When using supplied drill bit.
TABLE OF CONTENTS:
...........................1X WCS4
....................1X AC Adapter
.................1X Plastic caliper
2020.07.17
LED
GENERAL INFORMATION
1.
19/32"
2.
3.
4.
Caliper
.............1X Depth Stopper
.................1X Forstner Bit
1
Mobile device must be equipped with a wireless charging
receiver (Wireless charging accessories not included.)
Check mobile manufacturer for compatibility.
USB cable and AC adapter included. AC adapter
specifications 5.0 Volts at 2 Amps output.
Wireless output 5W to 10W MAX.
Use forstner bit for MDF or particle board wood types ONLY.
2
Depth
Stopper
Forstner
Bit
Loosen set screw on depth stopper with hex key.
.......................1X Drill Bit
Set
Screw
Hex key
....................1X Hex Key
.................1X Set screw
.....................2X Screws
.......................1X Decal
