PCS126
!
· For indoor use only.
· For use on a normally dry work surface.
·
If any malfunction occurs, do not attempt to disassemble or
repair.
·
Avoid placing the charger in a high temperature environment
or near fire.
·
Avoid liquid spills into outlet.
·
Do not insert foreign objects into the socket.
SPECIFICATIONS
· 6 ft. cord length.
· USB-A and USB-C ports are for charging use only.
· Table thickness is 1/2" MIN. to 2" MAX.
1
Make a cut out in the desired location on your work surface.
Allow enough clearance for unit operation. DO NOT place unit
where cable is strained or trapped.
2022.09.12
WARNING
!
100.00mm DIA.
[3-15/16"]
TOP VIEW
80.00mm DIA.
[3-5/32"]
CUT OUT
TABLE OF CONTENTS
. . . . . . . . . . . . 1X PCS126
. . . . . . . . . . . 1X Lock Ring
76.00mm
[3"]
(80.00mm
FRONT VIEW
2
Install the PCS126 into the cut out and make sure it is fully
leveled onto the work surface.
79.00mm
[3-1/8"]
[3-5/32"]
CUT OUT)
