9. Specifications

9.1 Specs for the Accessory Port Pinout

Connector Type: Weipu Socket 7Pin
Mating Plug: Weipu Plug 7Pin SF1210/P7II
Pin
1
2
3
4
5
6
7
Vortex8 User Manual
Description
TRIGGER Input +Ve (5-24V Input, referenced to GND)
DMX Data (-Ve)
DMX Data (+Ve)
GND, Ground Reference
+12V Output, 200mA maximum
Page 29 Version 1.0
