8. Power
8.2 Pinout for DC Power connector on Vortex8
Choose a 4 core cable of >15AWG (1.5mm2) and wire all 4 pins
Part Number
CSV-8 Vortex8
Pin
E
1
2
3
Vortex8 User Manual
Connector
Manufacturer
Ecomate 4 Pin Female
Amphenol
Wire To
- Ve
- Ve
+ Ve
+ Ve
Part Number
C016 20D003 110 10
Page 28
Version 1.0
