4. Transport and Safety

4.3 Filter Rails

There are various accessories that are available for V8 that can slide into the front two accessory rails. Eg
a standard diffuser and a honeycomb grid. Accessories slide into the rail system and lock securely with
unique lock and latch system.
1
The filter rail slot has a unique locking mechanism
that locks the initial filter in while allowing second
filter to be inserted without unlocking.
3
Push top latch down to engage the lock.
Vortex8 User Manual
2
Latch in unlock position.
4
Push gold button to release to unlock.
