Operation; Function Of Displays; Function Of Buttons - simatherm IH 240 Instructions For Use Manual

5

Operation

5.1

Function of displays

A
B
A) The main display shows the selected time or temperature for heating.
Display
t
°C
°F
B) The power display shows the selected power setting.
Display
•
••
•••
••••
•••••
5.2

Function of buttons

Button Function
POWER Press to adjust the power in steps of 20%.
The selected power is indicated on the power display.
MODE Press to switch between TIME MODE and TEMP MODE.
UP (+) Press to increase the value shown on the main display.
DOWN (-) Press to decrease the value shown on the main display.
START/STOP Press to start or stop the heater. The LED on the
START/STOP button is lit when the heater is heating and
fl ashes during temperature measurement.
© simatec ag
Indication
time in minutes
temperature in degrees Celsius
temperature in degrees Fahrenheit
Indication
20% power
40% power
60% power
80% power
100% power
Induction Heater IH 240 / IH 240-L 23
