Menu structure: There are three menu levels. The levels beneath the display of
the basic settings are always accessed from 1 level by pressing the control
button
for different lengths of time.
Level 1 – Status display (display of the operating state)
Level 2 – Operation menu (setting the basic functions):
• Pressing the control button longer than 1 s
Level 3 – Options menu (additional settings):
• Pressing the control button longer than 6 s
NOTE: After 30 s without any new entry being made, the display jumps back to
Level 1 (display of the operating state). Temporary, non-acknowledged
modifications are discarded.

7 Installation and electrical connection

Installation and electrical work in compliance with any local codes and by
qualified personnel only!
DANGER! Electrical shock hazard!
Dangers caused by electrical energy must be excluded.
National Electrical Codes, local codes and regulations must be followed.
WARNING! Bodily injury!
Existing regulations for the prevention of accidents must be observed.
7.1 Pump installation
• Installation within a building: install the pump in a dry, well ventilated and
frostresistant room.
• Installation outside a building (outdoor installation):
• Install the pump in a shaft (e.g. light well, annular shaft) with cover or in a
cupboard/housing as weather protection.
• Avoid exposure of the pump to direct sunlight.
• Protect the pump against rain. Dripping water from above is permitted,
provided the electrical connection is established in accordance with the
installation and operating instructions and the terminal box is closed properly.
CAUTION! Possible damage of the pump!
Dirt and solder drops in the pump body can effect the pump operation.
• It is recommended that any welding and soldering work be done before
installing the pump.
• Thoroughly flush the system prior to installing and operating the pump.
• Foreign material in the system resulting from construction may damage the
pump and is not warrantable.
