2.6 Safety instructions for installation and mainte-
nance work
The operator must ensure that all installation
and maintenance work is carried out by author-
ised and qualified personnel, who are sufficiently
informed from their own detailed study of the
operating instructions.
Work on the product/unit must only be carried out
when at a standstill. It is mandatory that the pro-
cedure described in the installation and operating
instructions for shutting down the product/unit
be complied with.
Immediately on conclusion of the work, all safety
and protective devices must be put back in posi-
tion and/or recommissioned.
2.7 Unauthorised modification and manufacture of
spare parts
Unauthorised modification and manufacture of
spare parts will impair the safety of the product/
personnel and will make void the manufacturer's
declarations regarding safety.
Modifications to the product are only permissible
after consultation with the manufacturer. Original
spare parts and accessories authorised by the
manufacturer ensure safety. The use of other
parts will absolve us of liability for consequential
events.
2.8 Improper use
The operating safety of the supplied product is
only guaranteed for conventional use in accord-
ance with Section 4 of the operating instructions.
The limit values must on no account fall under
or exceed those specified in the catalogue/data
sheet.

3. Transport and interim storage

When receiving the material, check that there has
been no damage during the transport. If shipping
damage has occurred, take all necessary steps
with the carrier within the allowed time.
CAUTION! Outside influences may cause dam-
ages.
If the delivered material is to be installed later on,
store it in a dry place and protect it from impacts
and any outside influences (humidity, frost etc.).

4. Product and accessories

4.1 Application
The domestic water system is designed to pres-
surise a water network in which the pressure is
too low or non-existent. For domestic applica-
tion.
Water supply and distribution possible from a
well, a stream or a tank.
Installation and operating instructions - Wilo-Initial JET system
4.2 Technical data
Max. flow rate
Max. delivery head
Temperature range
Max. ambient temperature
DN suction / delivery
Mains voltage
Setting range of start /stop
pressure of the pump
4.3 Description (Fig. 1, 2)
1 - Pump
2 - Filling plug
3 - Drain plug
4 - Diaphragm pressure vessel
5 - Manometer
6 - Power cable with plug
7 - Pressure contactor
8 - Pump/diaphragm pressure vessel connecting hose
9 - Pressure valve
HA- Maximum suction head
(See technical data)
Accessories (optional)
10 - Foot valve with strainer
(maximum opening width 1 mm)
11 - Suction valve
12 - Discharge valve
13 - Piping support
4.4 Motor protection
Thermal protection of motor integrated in wind-
ing; automatic reset.
4.5 Dry-running protection
We recommend protecting it by a suitable device
(float switch, pressure switch, control box).
4.6 Operating principle
The pump in operation discharges water into the
diaphragm pressure vessel, compressing the air in
the tank. When the max. set pressure is reached,
the pump stops.
The air presses on the diaphragm, driving water
into the distribution pipe when a tap is opened.
When enough water is pumped off for the mini-
mum pressure to be reached, the pump starts to
deliver water and refill the diaphragm pressure
vessel.
The pressure contactor (pos. 7) automates the
operation of the domestic water system; the
pressures can be read on the pressure gauge.
The storage of water in the diaphragm pressure
vessel means that water can be pumped without
starting the pump.

5. Installation and electrical connection

5.1 Place of installation
The domestic water system must be installed in
a shelter or in a room which is easily accessible,
normally ventilated, and protected from frost.
See name plate
7 m
+ 5 to 35 °C
+ 40 °C
G1»
1~230 V, ± 10 % (50Hz)
3-4-19 = 1.4 / 2.8 bar
4-4-50 = 1.6 / 3.2 bar
