General
Model Name
LCD Panel
General
Size
PowerSaver
Preset Timing
Display area
Modes
Pixel Pitch
Type
Synchronization
Horizontal
Vertical
Display Color
16,194,277 Colors
Resolution
Optimum resolution
Maximum resolution
Input Signal, Terminated
RGB Analog 0.7 Vpp positive at 75 ohms
Separate H/V sync, Composite, Sync-on-Green
TTL level positive or negative
Maximum Pixel Clock
80 MHz
Power Supply
AC 90 ~ 264 VAC, 60/50 Hz ± 3Hz
Signal Cable
15pin to 15pin D-sub cable, Detachable

Power Consumption

Less than 32W
Dimensions (WxDxH) / Weight
353.0 x 152 x 350.0 mm / 3.8kg
VESA Mounting Interface
75mm x 75mm (for use with Specialty(Arm) Mounting hardware.)

Environmental considerations

Operating
Storage
Plug and Play Capability
This monitor can be installed on any Plug & Play compatible system. Interaction of the monitor and
computer systems will provide the best operating conditions and monitor settings. In most cases,
monitor installation will proceed automatically, unless the user wishes to select alternate settings.
Dot Acceptable
TFT LCD panel manufactured by using advanced semiconductor technology with precision of 1ppm
SyncMaster 153S
15.0 inch diagonal
304.1 (H) x 228.1 (V)
0.297 (H) x 0.297 (V)
a-si TFT active matrix
31 ~ 61 kHz
56 ~ 75 Hz
1024 x 768@60Hz
1024 x 768@75Hz
Temperature: 50°F ~ 104°F(10°C ~ 40°C)
Humidity: 10% ~ 80%, non-condensing
Temperature: -4°F ~113°F (-20°C ~ 45°C)
Humidity: 5% ~ 95%, non-condensing
