VERSION WITH FLOOR SPITTOON UNIT
The spittoon unit houses all the electric, water and pneumatic control systems of the dental unit as well as
aspiration devices (liquid-air), if fitted. Access is gained using the supplied key after cutting out voltage (as
instructed in paragraph SAFETY RULES).
The power switch isolates the equipment from the mains electricity. So, before
performing any operations in the equipment, make sure that the power switch is
off.
MAIN UNIT AIR PRESSURE
An air pressure regulator is installed in the spittoon unit that keeps air pressure constant in table instruments.
The regulator is calibrated during the testing phase at O.M.S. and calibration can be changed exclusively for
technical reasons. This operation must be performed by an authorised technician.
The regulator collects any condensate present in the compressed air. For condensate draining refer to
paragraph CONDENSATE DRAINAGE.
OMS LINEA PATAVIUM S.T.01/3X ED.0 REV.8 09/2017
DANGER
