After extracting the instrument, the operator can adjust the rotation speed of the micromotor by setting the
number of revolutions (rpm) using the
display of the instrument table.
3.2.4.1.
The button
progressive speed (the display shows whether the speed is fixed or progressive):

when the button is disabled (corresponding LED off), the micromotor speed is progressive and ranges
from the minimum speed to the pre-set number of revolutions depending on the foot control lever
position;

when the button is enabled (corresponding LED on), the micromotor speed is fixed on the number of
revolutions shown on the display within the entire field of action of the foot control lever
3.2.4.2.
To reverse the sense of direction, place the instrument in its rest position and activate the inversion control
on the instrument table.
Note:
Invert the sense of rotation with the instrument in its rest position, so that the micro-motor is
not damaged.
Doing the same operation again makes you revert to the starting situation.
Spray is pre-selecting entering the command
MICROMOTOR OPERATION.
The water delivered to the spray is regulated by opening/closing the tap located under the micromotor
module: when turned anticlockwise, the flow of water to the spray is gradually reduced; when turned
clockwise, the opposite occurs. We recommend not using other regulation devices located alongside the spray
tap. If the system is equipped with an optic fibre lighting system, the lights go on when the control
installed in the main table keyboard.
Note:
For further details refer to the manufacturer's operating instructions enclosed.
Speed or fixed/progressive power control
enables micromotor operation at fixed speed depending on the setpoint or at
Sense of direction
OMS LINEA PATAVIUM S.T.01/3X ED.0 REV.8 09/2017
and buttons. The revolution setpoint is shown on the
on the main keyboard. Also see paragraph
