- Page 1 DUKE Instruction Manual date R. S. G. Q. Technical Dir. General Dir. 21/04/2011 DUKE S.T.01/3AR rev.0 4/2011...
- Page 2 DUKE S.T.01/3AR rev.0 4/2011...
-
Page 3: Table Of Contents
FORM TO REPORT ACCIDENTS TO PERSONS ..........................19 WARNING Before using the equipment, read the O.M.S. instruction manual completely and any instructions supplied with the accessories. O.M.S. reserves the right to make changes to its products without prior notice. DUKE S.T.01/3AR rev.0 4/2011... - Page 4 DUKE S.T.01/3AR rev.0 4/2011...
-
Page 5: General Information
The equipment must be installed by an authorised OMS technician; the choice of piping is made by the designer of the system and this must be laid by a technician qualified pursuant to the laws in force in the country of installation. -
Page 6: Admissible Ambient Conditions
Atmospheric pressure range: 500 to 1060 hPa 1.2.2 ADMISSIBLE AMBIENT CONDITIONS FOR OPERATION Temperature range: +10 to +40°C Relative humidity range: 30 to 75% Atmospheric pressure range: 800 to 1060 hPa Nominal operating altitude: ≤ 2000m DUKE S.T.01/3AR rev.0 4/2011... -
Page 7: Warranty
Operating field (at 700 mm): 60x180 mm Max. luminous intensity (at 700 mm): 25000 Lux. GCOMM POLARIS LAMP Power voltage: 17-24 Vac Colour temperature: 4200-6000 °K Focal distance: 700 mm Operating field (at 700 mm): 70x140 mm DUKE S.T.01/3AR rev.0 4/2011... -
Page 8: Id Plate Data
(*) Supplied only if specifically requested in the purchase order. Outside each crate a tag shows the purchase order number, the order acknowledgement number and the equipment model. N.B.: if an O.M.S. stool is included in the supply, this is packed separately. DUKE S.T.01/3AR rev.0 4/2011... -
Page 9: Installation
NOTE: we recommend closing the general water tap whenever leaving the dental surgery in order to prevent flooding due to accidental system breakages. WARNING: before performing any operations in the equipment, always make sure that the power switch is off. DUKE S.T.01/3AR rev.0 4/2011... -
Page 10: Controls - Adjustments - Warning Signs
Optic fibre lighting pre-selection control D. Optic fibre lighting pre-selection LED Spray pre-selection control Spray pre-selection LED Power LED (power on) H. Reset position call-up control dental chair back rise (up) control; dental chair pantographic arm rise (up) control; DUKE S.T.01/3AR rev.0 4/2011... - Page 11 If the system is equipped with an optic fibre lighting system, the lights go on when the control “N” installed in the table pushbutton panel is engaged (when this function is enabled, it has an impact on all the instruments). The enabled function is shown by LED (D) coming on. DUKE S.T.01/3AR rev.0 4/2011...
-
Page 12: Dental Chair
The foot control lever (A) (see figure 8), positioned with light pressure to the left (position A1), excludes all chair movements, allowing the operator to carry out all operations without dynamic instruments on the patient and without the risk of any accidental movement of the chair. DUKE S.T.01/3AR rev.0 4/2011... -
Page 13: Foot Control
O.M.S. and calibration can be changed exclusively for technical reasons. This operation must be performed by an authorised technician. The regulator has a filter that must be checked periodically and replaced, if necessary, as described in paragraph 9.3 WATER FILTERS. DUKE S.T.01/3AR rev.0 4/2011... -
Page 14: Scialytic Lamp
Perform these operations in reverse order to put it back in place after removal and ensure that the armrest is all the way down in its seat before turning it. The operations required to remove and install the armrest must be performed gently without forcing any movement especially if difficulties are experienced. DUKE S.T.01/3AR rev.0 4/2011... -
Page 15: Scheduled Maintenance
Dental tips must be thoroughly cleaned and sterilised. We recommend brushing the cannulas both inside and outside using the supplied pigs (to be found in the “aspiration system accessory kit”) and a suitable detergent. Aspiration end pieces supplied by O.M.S. can be autoclaved at a temperature of 130°C. DUKE S.T.01/3AR rev.0 4/2011... -
Page 16: Daily Cleaning And Disinfection
The fuses installed on the electronic boards (positioned inside the guard on the chair base) must be replaced by an authorised O.M.S. technician. Below is an indicative list of the values required for the main fuses installed in the equipment: (Figure 2) general fuse 8AT, 230 Vac (Figure 13) DUKE S.T.01/3AR rev.0 4/2011... -
Page 17: Adjustment Of The Swingarm Spring
(see B in figure 18) rotation of instrument table (see A in figure 18) rotation of tray holder table arm (see C in figure 18) rotation of tray holder table (see D in figure 18) DUKE S.T.01/3AR rev.0 4/2011... - Page 18 DUKE S.T.01/3AR rev.0 4/2011...
-
Page 19: Form To Report Accidents To Persons
Signature ___________________________ AREA RESERVED TO THE COMPANY (GENERAL MANAGEMENT) OPERATIVE DECISIONS ______________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ CORRECTIVE ACTIONS _______________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ Date _______________________________ Signature ___________________________ In the event of an accident send the form to O.M.S. S.p.A. promptly. DUKE S.T.01/3AR rev.0 4/2011...
