  • Page 1 Infrared Model IR-B01...
  • Page 2 All of our manufactured or assembled parts conform to the listed regulations. If you change the machine without our explicit agreement, this declaration will be herewith invalidated. Product type: Painting- and drying equipment (paint dryer) Type designation: IR-B01 Serial-#: Construction year: 2015...

  • Page 3: Table Of Contents

    Table of Contents 1. Important Information ..........................4 2. Safety Regulations and Maintenance Advice ................... 4 2.1 Work Area ............................4 2.2 Use ..............................5 2.3 Maintenance and Care ........................5 2.4 More Information ..........................5 3. Technical Description of the Machine ...................... 6 3.1 Technical Information.........................

  • Page 4: Important Information

    In order to get the best, safe use of this equipment, please read these instructions thoroughly before commencing assembly or operation of the machine. Failure to do so could result in damage or injury for which B-TEC Systems will accept no responsibility or liability.

  • Page 5: Use

    2.2 Use  To reduce the risk of explosion, DO NOT use in paint spray booths or within 10ft of spraying operations, as per the requirement of UL 499.  This unit must be operated in a well-ventilated area.  Isolate mains supply before removing any covers.

  • Page 6: Technical Description Of The Machine

    3. Technical Description of the Machine 1. The infrared head has multiple angle adjustment. 2. The infrared head can be used stand mounted, or as a hand-held, offering great flexibility. 3. The head height is adjustable up to an average vehicles glass line. 4.

  • Page 7: Spare Parts

    B01-19 Handle big B03-11 Handle B01-20 Transformer 220V/6W B01-9 Power cord B01-21 Heat Dissipating Relays 10A B03-30 B01-22 Plate Lid Control Box B01-11 Locking Ring B01-23 Bent Plate B01-12 B-TEC Systems reserves the right to make technical changes without notice.

  • Page 8: Assembly / Installation

    4. Assembly / Installation 1. Insert the upper section ③ of the vertical bar into the lower section ②. 2. Take out the pedestal ①, insert the vertical bar into the pedestal ① and fasten the screws. 3. Fit the lamp bracket ④ onto the vertical bar. 4.

  • Page 9: Operating Instructions

    Note: We suggest that when curing high build primers and dark colors. You move back to 18” and add 5 minutes to the bake time. If possible consult B-TEC SYSTEMS or your distributor for the availability of a paint curing data sheet for your paint brand.

  • Page 10: Replacement Of Emitter Lamp Tube

    6. Replacement of Emitter Lamp Tube Un-plug from the power supply, before replacing the infrared emitter / tube. 1. Remove the side panel. 2. Release the radiating panel. 3. Loosen the two leads in the lamp and remove them. 4. Remove the protective grill in front of the emitter. 5.

  • Page 11: Troubleshooting

    IF IN ANY DOUBT ABOUT ASSEMBLY OR OPERATION OF THE UNIT PLEASE DO NOT HESITATE TO CONTACT YOUR DISTRIBUTOR OR THE B-TEC SYSTEMS SERVICE DEPARTMENT AT (480) 621-5304. Above specifications and diagrams are subject to revision. B-TEC Systems reserves the right to make any changes without notification.
