Zycoo X10 User Manual

Sip paging gateway
Hide thumbs Also See for X10:
Table of Contents

Advertisement

Quick Links

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the X10 and is the answer not in the manual?

Questions and answers

Related Manuals for Zycoo X10

Summary of Contents for Zycoo X10

  • Page 2: Table Of Contents

    Contents Overview ..........................1 Product Overview ........................1 Product Specifications ......................1 Basic Settings ........................... 2 Web Interface Login ......................2 Device Info ..........................3 SIP Account ........................... 5 P2P Account .......................... 7 Audio Codecs ......................... 7 Advance SIP Settings ......................8 Advanced Settings ........................

  • Page 4: Overview

    Based on the compact hardware design, open standard SIP protocol support, rich functionality and high performance. Industry users can customize the X10 SIP paging gateway into any desired form of intercom device or paging speaker. These can then be widely used for smart and safe city applications, to increase the efficiency of communication and information sharing.

  • Page 5: Basic Settings

    For the safety of the SIP paging gateway, it is recommended to change the default password on first login, please go to Settings -> Change Password page to change the password. IP SIP Paging Gateway User Guide | ZYCOO Co., Ltd.

  • Page 6: Device Info

    After login, you’ll first see the Device Info screen. SIP STATUS • SIP Account: The SIP number configured on this device. • SIP Server: The SIP server (ZYCOO IP Audio Center or other IP PBX) address. • Register Status: The SIP number registration status. DEVICE INFORMATION •...
  • Page 7 Default Gateway: Shows the current default gateway of the device. • Primary DNS: Shows the current primary DNS of the device. • Alternative DNS: Shows the current alternative DNS of the device. IP SIP Paging Gateway User Guide | ZYCOO Co., Ltd.

  • Page 8: Sip Account

    SIP accounts to proceed various tasks. If the current device needs to cooperate with the ZYCOO IP Audio Center, please turn on the ‘ZYCOO IP Audio Center’ option. Please go to SIP Settings -> Primary SIP Account / Secondary SIP Account-1 / Secondary SIP Account-2...
  • Page 9 Secondary SIP 2 Account IP SIP Paging Gateway User Guide | ZYCOO Co., Ltd.

  • Page 10: P2P Account

    The network speakers support 4 audio codecs: G.722 (wideband codec), G.711(Ulaw), G.711(Alaw) and Opus To enabled or disable an audio codec/codecs, please go to SIP Settings -> Audio Codecs page. IP SIP Paging Gateway User Guide | ZYCOO Co., Ltd.

  • Page 11: Advance Sip Settings

    This setting represents the end RTP port that the system will use for media sessions. • RTP Timeout (sec): This setting represents in a specific time range, if the system doesn’t receive the RTP stream, then the call will end. IP SIP Paging Gateway User Guide | ZYCOO Co., Ltd.

  • Page 12: Advanced Settings

    For press-to-talk (or push-to talk), any desired number can be setup here. As a result, when the call button has been pressed, the SIP safety intercom will try to call this number. IP SIP Paging Gateway User Guide | ZYCOO Co., Ltd.
  • Page 13 Enable/Disable, enable this option if you need to dial a number when the corresponding digital signal is received. Number: The number that need to dial Line: Line represents the line that will be using to dial the call. IP SIP Paging Gateway User Guide | ZYCOO Co., Ltd.
  • Page 14 If “Incoming”, the dry contact relay output will be triggered when the SIP paging gateway gets an incoming SIP paging/intercom call. If “Hangup”, the dry contact relay output will be triggered when a SIP call ends on the SIP paging gateway. IP SIP Paging Gateway User Guide | ZYCOO Co., Ltd.

  • Page 15: Multicast Settings

    The multicast port range is 2000 - 65535 • Name: Customize a name of the multicast address • GPIO Trigger: Options to choose from are ‘Disabled’, ‘On’, ‘Fast Flashing’, ‘Slow Flashing’ IP SIP Paging Gateway User Guide | ZYCOO Co., Ltd.

  • Page 16: Audio Collection

    SIP Paging Gateway. The Audio Collection can collect external audio sources through the 3.5 Audio in the interface of the model X10 and play the audio source through the paging endpoints. This feature is required to use with the ZYCOO IP Audio Center.

  • Page 17: Language Settings

    Language Settings The language of local voice prompts, like IP address announcements, can be set on Settings -> Language Settings page. IP SIP Paging Gateway User Guide | ZYCOO Co., Ltd.

  • Page 18: Settings

    Time Settings The network speakers obtain time from the network time servers using NTP, to change the NTP settings please go to Settings -> Time Settings page. IP SIP Paging Gateway User Guide | ZYCOO Co., Ltd.

  • Page 19: Upgrade

    You’ll first see the current firmware version of the network speaker and the last upgrade time. Upload the .img file provided by ZYCOO to perform the upgrade action. If you wish to reset the network speaker to factory defaults after upgrading, please enable the “Reset Factory Defaults” parameter.

  • Page 20: Reboot & Reset

    Press and hold the RST button for 10 seconds (5 seconds for IP address announcements) and release, now you should hear voice prompts “Resetting factory defaults, rebooting…”, it means the speaker will now reset. IP SIP Paging Gateway User Guide | ZYCOO Co., Ltd.

  • Page 21: Maintenance

    The purpose of the Ethernet capture tool is to capture ethernet network packets and store then in a standard Wireshard compatible packet capture “.pacp” file for immediate viewing and data analyzing. IP SIP Paging Gateway User Guide | ZYCOO Co., Ltd.
  • Page 22 @ 2020 Zycoo Co., Ltd. All rights reserved. www.zycoo.com ZYCOO, NEEQ Code 839487, is the leading developer and manufacturer of IP telephony devices and related systems, devoting itself over the past years to R&D powerful and scalable voice over IP (VoIP) solutions that...
