Using Special Function Keys

The function key activates special functions when it is pressed in combination with
another keys.
<Fn> Key Key Name
Combinations
<Esc/ > Rest
<F2/ > Gauge
<F4/ > LCD/CRT
<F6/Mute> Mute
<F7/ > S/PDIF
<F8/ > 3D sound
<F9/ > Touchpad
<F10/ > Low-Noise Mode
<F11/Num Lock> Number Lock
Key Function
Puts the computer into suspended mode. To escape suspended mode,
press the power button. (p109).
Shows the current power source and the remaining battery charge.
Switches the display between the LCD and external display device
when an external display device is connected. (p107)
Turns the audio output on and off.
Turns the S/PDIF function on and off.
Turns S/PDIF on
Extends the spatial sound of the stereo speakers so that the listener
can experience even greater stereophonic sound.
Turns 3D sound on
Note. The 3D sound function is only supported through the internal
speaker of the computer and the headphones. This function is not
supported through the S/PDIF port.
Note. When using the 3D function, even if the balance is turned
completely to the left or right, some audio may still be heard through
the other speaker.
Caution. Some distortion may be experienced when the 3D function is
used, depending on the audio source.
Turns the touchpad function on and off.
Turns Touchpad on
You can select Low-Noise Mode when you need a tranquil work
environment.
Enables the numeric keypad. (p10)
Turns S/PDIF off
Turns 3D sound off
Turns Touchpad off
Getting Started 11
