Debugging code Progress code
LED1
progress
Code
17_Debugging 01-
finished 04
Step 19: after debugging is finished, some functions can be set up according to project's
actual needs. For specific details, please refer to System Functions Setup . If no special
requirements, skip this step.
Step 20: deliver the product to user and inform user about usage precautions.
5.2.3 Appendix: judgment reference of normal operational parameters
Reference of Debug Parameters of
N
Debug item
o.
1
2
3
4
5
6
System
parameters
ODU
7
8
9
LED2
Display Display
code
status status
Light OF Light
Parameter name
Outdoor ambient temp
Discharge tube temp of
inverter compressor 1
Casing top temp of
inverter compressor 1
Discharge tube temp of
inverter compressor 2
Casing top temp of
inverter compressor 2
Defrost temp 1
System high pressure
System low pressure
Opening angle of
heating EXV
Photovoltaic Direct-driven Inverter VRF
Status code
LED3
Display
Code
status
Debugging is finished. System is on
standby condition. LED1 displays
OF Light
module address. LED2 and LED3
display "OF".
photovoltaic multi VRF
Unit
º C(° F) ——
● When system compressor starts up, temp of
º C(° F)
discharge tube or casing top in cooling mode is
within 70~95º C (158~203° F), and at least 10
º C(° F)
º C(50° F) higher than system high pressure
saturation temp; Temp in heating mode is within
65~80º C(149~176° F), and at least 10º C(50° F)
º C(° F)
higher than system high pressure saturation temp.
● When inverter compressor starts but inverter
compressor 2 stops, the discharge tube temperature
º C(° F)
of inverter compressor 2 is almost the same with
ambient temp.
● In cooling mode, defrost temp1 is 5~11ºC
(41~51.8° F) lower than system high pressure value;
º C(° F)
● In heating mode, defrost temp1 is about 2ºC
(35.6° F) different from system low pressure value.
● System's normal high pressure value is within
20~25º C(68~77° F) According to the change in
ambient temp and system operational capacity,
system's high pressure value is 10~40
º C(50~104° F) higher than ambient temp The higher
ambient temp is, the smaller temp difference is.
º C(° F)
● When ambient temp is 25~35ºC(77~95°F),
system's high pressure value in cooling mode is
44~53º C(111.2~127.4° F).
● When ambient temp is -5~10º C(23~50° F),
system's high pres sure value in heating mode is
40~52º C(104~125.6° F).
● When ambient temp is 25~35ºC(77~95°F),
system's low pressure value in cooling mode is
0~8º C(32~46.4° F).
º C(° F)
● When ambient temp is -5~10º C(23~50° F),
system's low pressure value in heating mode is
-15~5º C(5~41° F).
● In cooling mode, heating electronic expansion
valve remains 480PLS.
● In heating mode, the opening angle of adjustable
PLS
electronic expansion valve varies within
120~480PLS.
