Basic Module
GMV-Y72WM/C-F(U)
GMV-Y96WM/C-F(U)
GMV-Y120WM/C-F(U)
Select the branch of outdoor module
Select the branch of outdoor module
4.2.5.3 Fitting pipe between two manifolds from basic modules
Pipe size (between two manifolds from basic modules) is based on the total capacity of
upstream modules.
Total capacity of upstream modules
C(Btu/h)
144000
168000
192000
216000
240000
Photovoltaic Direct-driven Inverter VRF
Pipe between module and branch of ODU
Gas Pipe mm(in.)
Φ19.05(3/4)
Φ22.2(7/8)
Φ28.6(1-1/8)
Fig.4.2.9
Pipe size between manifolds
Gas pipe size mm(in.)
Φ28.6(1-1/8)
Φ28.6(1-1/8)
Φ28.6(1-1/8)
Φ28.6(1-1/8)
Ф34.9(1-3/8)
20
Liquid Pipe mm(in.)
Φ9.52(3/8)
Φ9.52(3/8)
Φ12.7(1/2)
Model
ML01/A
Liquid pipe size mm(in.)
Φ12.7(1/2)
Φ15.9(5/8)
Φ15.9(5/8)
Φ15.9(5/8)
Φ15.9(5/8)
