Summary of Contents for Inseego SKYUS 100 Series
- Page 1 SKYUS 100 SERIES Quick Start Guide...
-
Page 2: Getting Started
gettingstarted 4 Pin IO Connector (Power/IO) RJ45 Ethernet Port USB Micro-B Port Power Button Green Solid Normal Operation Green Blinking Charging Battery (Off ) Blue Solid Good Battery Yellow Solid Mid-Level Battery Red Solid Low Battery Red Blinking System Error Startup/Software White Blinking Update In Process... - Page 3 gettingstarted Off (No Color) GPS Turned Off Yellow Blinking Searching Green Solid Fix Obtained Wireless, Wi-Fi/Bluetooth Green Solid Wi-Fi On (Bluetooth Off ) Blue Solid Bluetooth On (Wi-Fi Off ) Green/Blue Wi-Fi On, Bluetooth On Alternate Blinking Blue Fast Blink Bluetooth Pairing Mode Mobile Network Green Solid...
-
Page 4: Setting Up Your Device
3. Connect the device to a power supply and ensure that the device is turned on. * NOTE: If using the power cable make sure it is connected to a supported power source. For complete information about your device, accessories, and safety and regulatory information, visit www.inseego.com/iot-gateways/ or www.inseego.com/support/... -
Page 5: Connecting To Your Device
deviceconnect CONNECTING TO YOUR DEVICE To connect a device to Wi-Fi: 1. Connect the device via the appropriate power source. 2. Ensure that the device is powered on. 3. Connect the device using the SSID and Wi-Fi password printed on the label on the bottom of the device. - Page 6 USING THE EMBEDDED WEB INTERFACE TO CUSTOMIZE SETTINGS You can access and customize your Skyus 100 Series device settings from the embedded Web Interface. To configure the settings of your Skyus 100 Series device: 1. Browse to http://my.skyus/ or 192.168.1.1 on any connected device to access the device Web Interface Home page.
-
Page 7: Device Features
SKYUS 100 SERIES - PRODUCT FEATURES • Reliable, Industrial Grade LTE Connectivity, Wi-Fi, and GPS • Flexible Data Options • RJ45, USB, Serial over USB, Wi-Fi, BT [select models only] • Flexible Power Options • Power over Ethernet (POE or POE+ Source Required) •... -
Page 8: Optional Accessories
STANDARD ACCESSORIES / CONTENTS • Skyus 100 Series Device • 4400 mAh Rechargeable Battery • Whip Antennas • AC or DC Power Cable OPTIONAL ACCESSORIES • Whip, Mag Mount, Bulkhead Mount, and Adhesive Mount Antenna Options Available • USB Cable •... - Page 9 52mm (2.05 in) Use this drawing as a mounting template for your Skyus 100 series device INSTRUCTIONS 1. Install a #4 or #6 screw for the keyhole (1) into mounting surface 77mm of at your desired mounting location. Note: Use a screw type that...
- Page 10 © 2018 Inseego Corp. All rights reserved. Complying with all copyright laws is the responsibility of the user. Without limiting the rights under copyright, no part of this document may be reproduced, stored in or introduced into a retrieval system, or transmitted in any form or by any means (electronic, mechanical, photocopying, recording or otherwise), or for any purpose without the express written permission of Inseego Corp.
