  • Page 1 Low Harmonics Notch Filter Hardware and Installation Manual...
  • Page 3 Variable Speed Drive Hardware and Installation Manual Edition: December 2012 SD7FLMTHW02AI Rev. A...
  • Page 4 SD700FL SERIES POWER ELECTRONICS...

  • Page 5: Safety Symbols

    SD700FL SERIES POWER ELECTRONICS SAFETY SYMBOLS Always follow safety instructions to prevent accidents and potential hazards from occurring. This symbol means improper operation may results in serious personal WARNING injury or death. Identifies shock hazards under certain conditions. Particular attention should be given because dangerous voltage may be present.
  • Page 6 SD700FL SERIES POWER ELECTRONICS Revisions Date Revision Description 14 / 12 / 2012 First edition...
  • Page 7 SD700FL SERIES POWER ELECTRONICS INDEX SAFETY INSTRUCTIONS ......................INTRODUCTION ........................CONFIGURATION TABLE & STANDARD RATINGS ............2.1. Configuration Table ..................... Standard ratings – 400Vac ..................2.2. Standard ratings – 690Vac ..................2.3. TECHNICAL CHARACTERISTICS ..................RECEPTION, HANDLING AND TRANSPORTATION ............
  • Page 8 SD700FL SERIES POWER ELECTRONICS 12. OPTIONAL EQUIPMENT ..................... 12.1. Accessories......................... 12.2. Extension Box ......................12.3. Plinths ......................... 12.4. Dynamic Braking Unit B150 ..................12.5. Touch-Graphic Display ....................12.6. Communication boards ....................12.7. IP54 Solutions for Frames 1 to 4................. 12.8. Input Protection Module for Frames 5 to 11 ..............

  • Page 9: Safety Instructions

    Read this manual carefully to maximise the performance of this product and to ensure its safe use and installation.  Power Electronics accepts no responsibility or liability for any damage resulting from inappropriate use of the equipment.  In this manual, safety messages are classified as follows: WARNING Do not remove the metal cover while the power is applied or the unit is in operation.
  • Page 10 SD700FL SERIES POWER ELECTRONICS CAUTION Install the drive on a non-flammable surface. Do not place flammable material nearby. Otherwise fire could occur. Disconnect the input power if the drive is damaged. Otherwise, it could result in a secondary accident or fire.

  • Page 11: Connection Precautions

     Before operating the drive, read this manual thoroughly to gain and understanding of the unit. If any doubt exists then please contact POWER ELECTRONICS, (902 40 20 70 / +34 96 136 65 57) or your nearest agent. ...

  • Page 12: Earth Connection

    SD700FL SERIES POWER ELECTRONICS EARTH CONNECTION  Ground the drive and adjoining cabinets to ensure a safety operation and to reduce electromagnetic emission.  Connect the input PE wire only to the dedicated PE terminal of the drive. Do not use the cabinet or the chassis screw for grounding.
  • Page 13 POWER ELECTRONICS 1. INTRODUCTION SD700 low voltage drives by Power Electronics is the most extensive product family with a power range from 1.5kW to 2000kW. It has been designed focused on maximum motor care, components durability and easy maintenance. SD700 portfolio is divided in 3 products series that comply with specific demands and standards in worldwide installations thanks to its own specific features: SD700, SD700KOMPAKT, SD700FREEMAQ (SD700FR &...

  • Page 14: Configuration Table

    [1] Verify the rated current of the motor nameplate to guarantee the compatibility with the selected drive. [2] Consult Power Electronics for different input voltages. [3] Degree of protection values exposed in the table correspond to the drive. Filters‟ modules degree of protection is always IP42.
  • Page 15 SD700FL SERIES POWER ELECTRONICS 2.2. Standard ratings – 400Vac Operation Temperature 50ºC HEAVY DUTY CODE FRAME I(A) Motor Power 150% Overload Rated (kW) at 400VAC SD7FL0006 5 6 SD7FL0009 5 6 SD7FL0012 5 6 SD7FL0018 5 6 SD7FL0024 5 6...

  • Page 16: Heavy Duty

    SD700FL SERIES POWER ELECTRONICS 2.3. Standard ratings – 690Vac Operation Temperature 50ºC HEAVY DUTY CODE FRAME I(A) Motor Power 150% Overload Rated (kW) at 690VAC SD7FL0052 6 6 SD7FL0062 6 6 SD7FL0080 6 6 SD7FL0105 6 6 SD7FL0130 6 620...

  • Page 17: Technical Characteristics

    [2]: The harmonics are lower than those in the IEEE519 for I [3]: For operation frequencies higher than 100Hz consult Power Electronics. [4]: SC: Shielded cable, USC: Unshielded Cable. Follow Power Electronics installation recommendations. For greater cable lengths, consult Power Electronics.

  • Page 18: Control Panel

    SD700FL SERIES POWER ELECTRONICS SD700FL SERIES 5 programmable, Active high (24Vdc), Isolated power supply DIGITAL INPUTS Active high (24Vdc), 1 PTC input, isolated power supply DIGITAL OUTPUTS 2 programmable changeover relays (250Vac, 8A or 30Vdc, 8A) 2 programmable differential inputs. 0 – 20mA, 4 – 20mA, 0 – 10Vdc and 10Vdc.

  • Page 19: Electromagnetic Compatibility

    SD700FL SERIES POWER ELECTRONICS SD700FL SERIES CERTIFICATIONS CE, cTick, UL , cUL EMC Directive (2004/108/CE) ELECTROMAGNETIC IEC/EN 61800-3 COMPATIBILITY IEEE519 LVD Directive (2006/95/CE) REGULATIONS IEC/EN 61800-2 General requirements IEC/EN 61800-5-1 Safety DESIGN AND CONSTRUCTION IEC/EN 60146-1-1 Semiconductor converters IEC60068-2-6 – Vibration IEC/EN61800-5-2 Safe Torque Off (STO) certified by Tüv Rheinland...

  • Page 20: Reception And Storage

    The SD700FL is carefully tested and perfectly packed before delivering. In the event of transport damage, please ensure that you notify the transport agency and Power Electronics: 902 40 20 70 (International +34 96 136 65 57) or your nearest agent, within 24hrs from receipt of the goods.
  • Page 21 SD700FL SERIES POWER ELECTRONICS To unpack, if necessary, unscrew the bolts that fix the wooden or the cardboard box with the pallet. Then, unscrew all the fixation screws of the L shapes. To rise to an upright position use a crane or forklift equipped with belts or slings.

  • Page 22: Mechanical Installation

    SD700FL SERIES POWER ELECTRONICS 5. MECHANICAL INSTALLATION CAUTION The installation must be done by qualified personal. Otherwise, it could lead to people injury and cause damaged to the equipment. 5.1. Environmental ratings It is recommended to follow the instructions of this manual to ensure the correct operation of the drive.

  • Page 23: Drive Mounting

    5.2.1. Wall mounting drives The variable speed drives SD700FL series from frame 1 to 4 are wall-mounting drives. Additionally frame 4 has available an optional plinth that converts it into a stand-alone cabinet.
  • Page 24 SD700FL SERIES POWER ELECTRONICS 5.3. Clearances The SD700FL must be installed in vertical position, and firmly fastened through the dedicated anchorages placed in the rear part of the drive that avoid any movement. If the equipment is installed inside a cabinet, ensure that the hot air expelled from the drive is evacuated outside.
  • Page 25 The heat sources inside the equipment correspond with the inverter bridge (IGBTs), rectifier bridge, the input RFI filter and the output dV/dt filter. SD700FL series present an overall efficiency higher than 97% at rated power, so the heat dissipation approximately corresponds to 3% of the input power.
  • Page 26 SD700FL SERIES POWER ELECTRONICS The following figure identifies the gratings and fans of the different cooling areas. Figure 5.6 SD700 gratings and fans The internal air speed of the drive varies depending on the ambient conditions or the grating status.
  • Page 27 SD700FL SERIES POWER ELECTRONICS 5.4.2. Cooling system for the SD700FL corresponding to the filter side. The Freemaq filters are individual cabinets. Inside the cabinets, the inductances and capacitors generate heat, so each cabinet presents an independent cooling system. In frame 1 filters, an axial fan installed in the bottom part of the cabinet blows the fresh air through the hottest components.
  • Page 28 SD700FL SERIES POWER ELECTRONICS The SD700FL filters frame 5 on have been designed in a modular way. Inside the modules, the inductances generate heat, so each module presents an independent cooling system. The modules integrate air inlet gratings in their front part. Behind them are placed axial fans that allow blowing the fresh air to the hottest components (inductances and capacitors).

  • Page 29: Power Connection

    SD700FL SERIES POWER ELECTRONICS 6. POWER CONNECTION CAUTION Read carefully the following installation instructions for a correct electrical installation. Otherwise, it could lead to people injury and cause damage to the equipment. 6.1. Basic configuration Proper peripheral devices must be selected and correct connections must be done to ensure proper operation.
  • Page 30 The inverter bridge generates the PWM wave that controls the motor performance (voltage, current, torque, etc...). SD700FL Series by Power Electronics, integrate as standard output dV/dt filters and a CLAMP system that reduces significantly the dV/dt rise time below 500V/μs - 800V/μs, therefore, it reduces the voltages peaks at the motor windings, the common mode currents and the EMC emissions.
  • Page 31 SD700FL SERIES POWER ELECTRONICS The following schemes illustrate the SD700FL internal power structure for different frames. Figure 6.3 General connections diagram for frames 1 and 2 Figure 6.4 General connections diagram for frames 3 to 11 POWER CONNECTION...
  • Page 32 SD700FL SERIES POWER ELECTRONICS Figure 6.5 Parallel module connection functional diagram frames 3 to 11 POWER CONNECTION...

  • Page 33: Power Connection And Wiring

    SD700FL SERIES POWER ELECTRONICS 6.3. Power connection and wiring CAUTION The following installation recommendations are suitable for TN and TT grids, for IT grids check the dedicated section. Otherwise, it could lead to people injury and cause damage to equipment.
  • Page 34 SD700FL SERIES POWER ELECTRONICS As standard, the input and output terminals are made of tin plated copper. If they are oxidized prior to its installation, the connections will be poorly executed and will cause overheating. To avoid this effect is recommended to follow the next steps.
  • Page 35 SD700FL SERIES POWER ELECTRONICS Figure 6.10 Recommended cable bundling scheme CAUTION Line voltage (input supply) must never be connected to U, V and W terminals. Otherwise, the drive will be damaged. It is necessary that installer guarantee the correct observance of the law and the regulations that are in force in those countries or areas where this device is going to be installed.
  • Page 36 SD700FL SERIES POWER ELECTRONICS It is recommended to route in separately cable racks, trays or ducts, the following cable types:  Single-wire signal or data cables with V< 60V  Single wire cable with 60V<V< 230V  Input power cables with low level of interferences 230V<V<1000V ...

  • Page 37: Ground Connection

    SD700FL SERIES POWER ELECTRONICS 6.3.2. Recommended Cable Section for 690VAC Recommended Recommended Cable Section Cable Section I(A) Power (kW) CODE per Phase for Earth Wire FRAME Rated at 690VAC AWG / AWG / mm² mm² kcmil kcmil SD7FL0052 6X Y 3 –...

  • Page 38: Emc Installation Requirements

    SD700FL SERIES POWER ELECTRONICS 6.5. EMC Installation Requirements 6.5.1. Introduction The European EMC Directive defines electromagnetic compatibility as follows: the capability of an apparatus, an industrial plant, or a system to work satisfactorily in the electromagnetic environment without at the same time causing electromagnetic disturbance, which would be unacceptable to apparatus, industrial plant, or systems present in this environment.
  • Page 39 SD700FL SERIES POWER ELECTRONICS 6.5.2. SD700FL compliance SD700FL variable speed drives are designed for industrial (second environment) use. The use of radio frequency interference filters (RFI filters) and dV/dt filters as standard, and the correct installation following the recommendations within this manual, permits to achieve compliance with C3 category defined in IEC/EN 61800-3.

  • Page 40: Short Circuit

    SD700FL SERIES POWER ELECTRONICS 6.6. Protections 6.6.1. Short circuit SD700FL includes from frame 5 to 11 ultra fast fuses as standard. Frame 5 includes one fuse per phase with a rated current that depends on the drive‟s nominal current. Frames 6 on are constructed through the parallel connection of frame 5 so the fuses per phase in those frames correspond with the number of parallel drive modules (frame 5) interconnected.

  • Page 41: Ground Fault Protection

    The EMC filters and long motor cables increase the ground leakage currents so the threshold response of the protection should be adjusted according to the relevant plant conditions. For additional information, contact with Power Electronics. 6.6.3. Motor thermal protection The drive includes a motor thermal protection that based on the motor performance parameters mathematically calculates the thermal reservoir of the motor.
  • Page 42 The equipments of Frames 1 and 2 include the built-in dynamic brake as standard. The user should only connect a resistor between terminals +HVDC and B, as the following drawing shows. Figure 6.14 Power electronics for equipments of Frames 1 and 2 6.8.1. Resistor Values for Dynamic Brake (Optional)

  • Page 43: Connection Drawing

     To connect the sensor to the drive, it is recommended to use shielded cable.  The maximum cable length between the drive and the external braking resistor is 20m. For other configurations, contact with Power Electronics. CAUTION Do not touch the braking resistor during the drive operation since it could be very hot (more than 150ºC).
  • Page 44 SD700FL SERIES POWER ELECTRONICS 6.9. Power terminals for Freemaq Filter 6.9.1. Connections for Frame 1 Figure 6.16 Location of power connections for equipments of Frame 1 6.9.2. Connections for Frames 2, 3 and 4 FRAME 2 FRAME 3 FRAME 4 Figure 6.17 Location of power connections for filters Frames 2, 3 and 4 [mm]...
  • Page 45 SD700FL SERIES POWER ELECTRONICS 6.9.3. Connections for Frame 5 on Figure 6.18 Location of power connections for filters Frame 5 to 11 [mm] POWER CONNECTION...
  • Page 46 SD700FL SERIES POWER ELECTRONICS 6.10. Power terminals for SD700 drives 6.10.1. Connections for Frame 1 Figure 6.19 Location of power connections for equipments of Frame 1 [mm] POWER CONNECTION...
  • Page 47 SD700FL SERIES POWER ELECTRONICS 6.10.2. Connections for Frame 2 Figure 6.20 Location of power connections for equipments of Frame 2 [mm] POWER CONNECTION...
  • Page 48 SD700FL SERIES POWER ELECTRONICS 6.10.3. Connections for Frame 3 Figure 6.21 Location of power connections for equipments of Frame 3 [mm] POWER CONNECTION...
  • Page 49 SD700FL SERIES POWER ELECTRONICS 6.10.4. Connections for Frame 4 Figure 6.22 Location of power connections for equipments of Frame 4 [mm] POWER CONNECTION...
  • Page 50 SD700FL SERIES POWER ELECTRONICS 6.10.5. Connections for Frame 5 Figure 6.23 Location of power connections for equipments of Frame 5 [mm] POWER CONNECTION...
  • Page 51 SD700FL SERIES POWER ELECTRONICS 6.10.6. Connections for Frame 6 Figure 6.24 Location of power connections for equipments of Frame 6 [mm] POWER CONNECTION...
  • Page 52 SD700FL SERIES POWER ELECTRONICS 6.10.7. Connections for Frame 7 Figure 6.25 Location of power connections for equipments of Frame 7 [mm] POWER CONNECTION...
  • Page 53 SD700FL SERIES POWER ELECTRONICS 6.10.8. Connections for Frame 8 Figure 6.26 Location of power connections for equipments of Frame 8 [mm] POWER CONNECTION...
  • Page 54 SD700FL SERIES POWER ELECTRONICS 6.10.9. Connections for Frame 9 Figure 6.27 Location of power connections for equipments of Frame 9 [mm] POWER CONNECTION...
  • Page 55 SD700FL SERIES POWER ELECTRONICS 6.10.10. Connections for Frame 10 Figure 6.28 Location of power connections for equipments of Frame 10 [mm] POWER CONNECTION...
  • Page 56 SD700FL SERIES POWER ELECTRONICS 6.10.11. Connections for Frame 11 Figure 6.29 Location of power connections for equipments of Frame 11 [mm] POWER CONNECTION...
  • Page 57 6.11. Connection between Freemaq Filter and SD700 VFD The stand-alone SD700FL series drives which have no more than 5 modules are delivered internally wired. In these cases, the installer will not need to realize neither the connection between the filter modules nor the connection between the Freemaq filter and the SD700 drive.

  • Page 58: Control Connection

    SD700FL SERIES POWER ELECTRONICS 7. CONTROL CONNECTION 7.1. Wiring recommendations Before planning the installation, follow the next recommendations. The parallel cable routing should be minimized and the distance between the control wiring and the power wiring should be maximized. It is recommended to route control cables with different voltages in separately cable racks, trays or ducts.
  • Page 59 SD700FL SERIES POWER ELECTRONICS 7.2. Control board terminals description CAUTION Changes of control wiring or bridges should be performed at least 10 minutes after disconnecting the input power and after checking the DC Link voltage is discharged with a meter (below 30VDC).
  • Page 60 SD700FL SERIES POWER ELECTRONICS The following figure provides an overview of the standard wiring of control terminals through the X1 and X2 user connectors. Figure 7.4 Example of control terminals standard wiring Digital inputs can be configured individually or collectively. Analogue inputs can be configured as comparators.

  • Page 61: Signal Description

    SD700FL SERIES POWER ELECTRONICS SIGNAL DESCRIPTION Power supply for digital inputs. Short circuit and overload protected. (Maximum +24VDC, +24V_USER 180mA) Programmable Digital Input 1. Digital inputs are configured in the Input group. Their status can be displayed in the visualisation group. It is powered from terminal 1 or an external power 24VDC supply.
  • Page 62 SD700FL SERIES POWER ELECTRONICS 7.3. Filter Control Terminals Description Figure 7.6 Interconnection switch of the filter SIGNAL DESCRIPTION 230Vac - L Input terminals for filter power supply (230Vac / ± 10%). Other voltage ratings are 230Vac - N available on demand.
  • Page 63 SD700FL SERIES POWER ELECTRONICS 7.4. Control Connection and Configuration SD700FL drives are delivered wired and configurated to avoid working problems except in frames 1 to 4 and in equipments with more than 5 filter modules. In these cases, the installer must fulfil the following instructions in order to ensure the correct operation of the SD700 drive and Freemaq filter set.

  • Page 64: Sto - Safe Torque Off

    SD700FL SERIES POWER ELECTRONICS 7.5. STO - Safe Torque Off The STO function is defined as follows: Power, that can cause rotation, is not applied to the motor. The frequency converter will not provide energy to the motor, which can generate torque.
  • Page 65 SD700FL SERIES POWER ELECTRONICS 7.5.1. Safety Integrity Level SIL3- PLe This assembly provide a highly reliable safety function. When the sensor (E-Push Button) is activated, the STO function interrupts providing energy to the motor. Therefore, it will stop the motor by its own inertia or will avoid any possible unexpected start.
  • Page 66 SD700FL SERIES POWER ELECTRONICS Example 2: SIL3 (PLe) Safety door opening stop for maintenance tasks with manual restart. This function is used to prevent an unexpected restart when a maintenance task is being carried out in a risk area. In this case, the relay‟s safety inputs will be connected to a safety interlock switch placed in the door.
  • Page 67 SD700FL SERIES POWER ELECTRONICS 7.5.2. Safety Integrity Level SIL1- PLc This connection scheme provides an easy and cost effective solution for installations that not require the highest safety level requirements. In this case, the two NC contacts from the external push button are directly connected to the optional STO board.
  • Page 68 Power Electronics provides a solution for driving ATEX motors such as “Ex nA”, “Ex d” and “Ex p”, under the ATEX zone areas illustrated below. For different ATEX motor and zone combination, consult Power Electronics.

  • Page 69: Modbus Communication

    SD700FL SERIES POWER ELECTRONICS 8. MODBUS COMMUNICATION 8.1. Introduction To guarantee a correct operation of the drive, peripheral elements should be selected correctly and should be connected properly. A wrong installation and/or application could cause a wrong operation of the system or a reduction of the long life of the equipment, and its parts may be damaged. This manual should be read carefully and understood before proceeding.

  • Page 70: Hardware Technical Specifications

    SD700FL SERIES POWER ELECTRONICS 8.2. Hardware technical specifications Physical level 3 cables, optically insulated, half duplex, RS232 single ending Terminals 23  RS Common (0VDC) 24  RS232 Rx (receiving line) 25  RS232 Tx (transmitting line) Output signal level '1' logical 6.5V regarding to 0V...
  • Page 71 SD700FL SERIES POWER ELECTRONICS 8.3. RS232 Connections The following diagram shows a common wiring for a RS232 connection: Figure 8.2 RS232 Connection 8.4. RS485 Connections The following diagram shows a common wiring for a RS232 connection RS485: Figure 8.3 RS485 connection...
  • Page 72 SD700FL SERIES POWER ELECTRONICS 9. COMMISSIONING CAUTION Only qualified personnel are allowed to commission the drive. Read and follow the safety instructions on the first pages of this manual. Neglecting the safety instructions can cause injury or death. Ensure that there is no voltage present in the input power terminals and no voltage can be connected to the drive inadvertently.
  • Page 73 SD700FL SERIES POWER ELECTRONICS Connect input power supply. Verify that the display is turned on and set the drive control parameters (Follow the instruction delivered in Software and Programming manual). Check line voltages displayed. Start the drive without the motor using the display‟s keyboard pushbutton “START”.
  • Page 74 SD700FL SERIES POWER ELECTRONICS 10. DIMENSIONS 10.1. Dimensions of Frames 1 and 2 FRAME INPUT VOLTAGE EQUIPMENTS 380 – 500VAC (-20% to +10%) SD70006 5X Y, SD70009 5X Y, SD70012 5X Y, SD70018 5X Y, SD70024 5X Y 380 – 500VAC (-20% to +10%)
  • Page 75 SD700FL SERIES POWER ELECTRONICS 10.2. Dimensions of Frames 3 and 4 FRAME INPUT VOLTAGE EQUIPMENTS 380 – 500VAC (-20% to +10%) SD7FL0060 5X Y, SD7FL0075 5X Y, SDFL70090 5X Y, SD7FL0115 5X Y 690VAC (-15% to +10%) SD7FL0052 6X Y, SD7FL0062 6X Y 380 –...
  • Page 76 SD700FL SERIES POWER ELECTRONICS 10.3. Dimensions of Frame 5 FRAME INPUT VOLTAGE EQUIPMENTS 380 – 500VAC (-20% a +10%) SD7FL0210 5X Y, SD7FL0250 5X Y, SD7FL0275 5X Y 690VAC (-15% a +10%) SD7FL0130 6X Y, SD7FL0150 6X Y, SD7FL0170 6X Y...
  • Page 77 SD700FL SERIES POWER ELECTRONICS 10.4. Dimensions of Frame 6 Number of FRAME INPUT VOLTAGE filter EQUIPMENTS modules SD7FL0330 5X Y, SD7FL0370 5X Y 380 – 500VAC (-20% a +10%) SD7FL0460 5X Y SD7FL0210 6X Y 690VAC (-15% a +10%) SD70260 6X Y, SD7FL0320 6X Y...
  • Page 78 SD700FL SERIES POWER ELECTRONICS 10.5. Dimensions of Frame 7 Number of FRAME INPUT VOLTAGE filter EQUIPMENTS modules SD7FL0580 5X Y, SDFL70720 5X Y 380 – 500VAC (-20% a +10%) SD7FL0650 5X Y SD7FL0385 6X Y 690VAC (-15% a +10%) SD7FL0460 6X Y...
  • Page 79 SD700FL SERIES POWER ELECTRONICS 10.6. Dimensions of Frame 8 Number of FRAME INPUT VOLTAGE filter EQUIPMENTS modules 380 – 500VAC (-20% a +10%) SD7FL0840 5X Y, SD7FL0925 5X Y, SD7FL0990 5X Y SD7FL0550 6X Y 690VAC (-15% a +10%) SD7FL0660 6X Y...
  • Page 80 SD700FL SERIES POWER ELECTRONICS 10.7. Dimensions of Frame 9 Number of FRAME INPUT VOLTAGE filter EQUIPMENTS modules 380 – 500VAC (-20% a +10%) SD7FL1150 5X Y, SD7FL1260 5X Y, SD7FL1440 5X Y SD7FL0750 6X Y, SD7FL0840 6X Y, 690VAC (-15% a +10%)
  • Page 81 SD700FL SERIES POWER ELECTRONICS 10.8. Dimensions of Frame 10 Number of FRAME INPUT VOLTAGE filter EQUIPMENTS modules 380 – 500VAC (-20% a +10%) SD7FL1580 5X Y, SD7FL1800 5X Y SD7FL1140 6X Y 690VAC (-15% a +10%) SD7FL1270 6X Y SD7FL1420 6X Y...
  • Page 82 SD700FL SERIES POWER ELECTRONICS Figure 10.20 Dimensions of Frame 10 with seven filter modules 10.9. Dimensions of Frame 11 Number of FRAME INPUT VOLTAGE filter EQUIPMENTS modules SD7FL2200 5X Y 380 – 500VAC (-20% a +10%) SD7FL2500 5X Y SD7FL1500 6X Y...
  • Page 83 SD700FL SERIES POWER ELECTRONICS Figure 10.23 Dimensions of Frame 11 with eight filter modules Figure 10.24 Dimensions of frame 11 with nine filter modules DIMENSIONS...

  • Page 84: Maintenance

    SD700FL SERIES POWER ELECTRONICS 11. MAINTENANCE SD700FL drives consist of advanced semiconductor devices. Temperature, humidity, vibration and deteriorated components can reduce their efficiency. To avoid any possible irregularity we recommend making periodic inspections. 11.1. Warnings  Be sure to remove the input power while performing maintenance.
  • Page 85 SD700FL SERIES POWER ELECTRONICS Period Inspection Instrument of Inspection Inspection method Criterion element Measurement Have fluid leakages been observed? Is the capacitor well Visual check. No anomaly Instrument for Correct capacitor fastened? Measure the capacitance with Capacitance higher than measuring Is any dilation or a proper instrument.

  • Page 86: Optional Equipment

    GSM Module. GSM01 (For Touch-Graphic Display option). Dynamic Braking Unit. B150 (For further information, see section ‘9.4 Dynamic Braking Unit B150’). Optional Board for Slave Mode Brake. SD7DB (For Dynamic Braking Unit B150 option). Consult availability with Power Electronics. OPTIONAL EQUIPMENT...

  • Page 87: Extension Box

    SD700FL SERIES POWER ELECTRONICS 12.2. Extension Box Dimensions (mm) FRAME CODE SD7EB1 SD7EB2 SD7EB3 Figure 12.1 Dimensions for Extension Box 12.3. Plinths Dimensions (mm) Total Drive FRAME CODE Height (mm) SD7PL0417 438.5 1712 SD7PL0520 413.5 2000 SD7PL0522 613.5 2200 SD7PL0620 413.5...
  • Page 88 SD700FL SERIES POWER ELECTRONICS 12.4. Dynamic Braking Unit B150 The Dynamic brake permits to control the regenerated energy for series SD700, SD700KOMPAKT and SD700FL. B150 dynamic brake activates an IGBT to discharge the DC bus over external resistors when the DC voltage overpasses a pre-set value. This activation signal could also be delivered by the drive acquiring an optional Master- Slave mode braking board.
  • Page 89 SD700FL SERIES POWER ELECTRONICS 12.5. Touch-Graphic Display The Touch-Graphic Display provides a much more intuitive data presentation, an easy navigation through the control parameters and allows saving thousands of customized configurations defined by the user. Some of the outstanding characteristics of the graphic display are: ...
  • Page 90 Figure 12.7 Example of IP54 cabinet for Frames 1 to 4 For additional information, consult Power Electronics. 12.8. Input Protection Module for Frames 5 to 11 The filter modules could be delivered with an input protection module. In these cases, the input power will be situated in the input protection cabinet.

  • Page 91: Emc Directive

    SD700FL SERIES POWER ELECTRONICS 13. CE MARKING The CE Marking is a system to identify equipment that complies with the relevant directives (EMC directive). CE marking guarantees the free movement of the product within the EEA. CE marking shows that the product complies with technical safety, compatibility issues and conformity assessment.
  • Page 92 SD700FL SERIES POWER ELECTRONICS...

  • Page 93: Declaration Of Conformity (Ce)

    Fax: +34 96 131 82 01 Declares under its own responsibility, that the product: Variable Speed Drive for A.C. motors Brand: Power Electronics Model name: SD700FL Series Is in conformity with the following European Directives: References Title 2006/95/CE Electrical Material intended to be used with certain limits of voltage...
  • Page 94 Power Electronics India INDIA MADURAI Tel. (+91) 452 452 2125• Fax (+91) 452 452 2125 Power Electronics Italia Srl • Piazzale Cadorna, 6 • 20123 • MILANO • ITALIA ITALY Tel. (+39) 347 39 74 792 • Calle Cerrada de José Vasconcelos, No 9 • Colonia Tlalnepantla Centro •...
  • Page 95 www.power-electronics.com...
