Mechanical Design - General HT 300 SET Manual

Functions
HT 300 SET room thermostat has only heating and cooling outs. Its stabilizer gets room temperature with integrated sensor and keeps
the required temperature by providing control commands . Switching difference is 0.5 C.
Operating
Key features of HT 300 SET room thermostat:
- Two-position control
- LCD Backlight screen
- NTC 10K sensor

Mechanical Design

The device consists of 2 parts:
With its digital display having electronic, drive elements and built room temperature sensor,
A plastic body
A mounting base
Plastic body is mounted on mounting base.
Day Time Indicator
ROOM
SET
Temperature Indicator
WEEKLY PROGRAMME
COMFORT MODE ECONOMY MODE
HOLIDAY MODE
Kombi Operating
o
Programming
Degree and
Data Setting
Degree and
Data Setting
Hour, Day and
SET
Mode Setting
ON/OFF and
Back
MANUAL
Mode
Heating Calibration
Thermostat and Receiver
Matching
Weekly Program
Comfort Mode
Economy Mode
Holiday Mode
HT 300 SET
