- Page 1 DIGITAL ROOM THERMOSTAT HT300 SET Wireless Room Thermostat Large LCD Backlight Display Daily and Weekly Program Touch Keys Key Lock Battery Indicator On-Off Control Product Code HT300 SET Data sheet V. No v.1.0 generallife.com.tr...
-
Page 2: Mechanical Design
USAGE OF ROOM THERMOSTAT HT300 SET is a wireless room thermostat. The HT300 SET room thermostats are used in heating systems to keep the room temperature constant at the set temperature. Large LCD Backlight Display Touch Keys Daily and Weekly Program ... -
Page 3: Operating Principles
Screen Lock Holiday Mode Room Temperature Manual Mode Hours of Day Day Indicator OPERATING PRINCIPLES HT300 SET room thermostat specifications: LCD with backlight Two-position control (ON / OFF) Temperature sensor (NTC) The thermostat measures the room temperature with its temperature sensor. The desired temperature value is set by turning the button to the right or left. -
Page 4: Room Thermostat Installation
The room thermostat can be calibrated if the measuring temperature wanted to be changed. The calibration range is -8 C to + 8 C. ORDERING When ordering, specify both the product type and the product code, for example the HT300 SET wireless room thermostat. ROOM THERMOSTAT INSTALLATION Remove the room thermostat by pulling it out of the wall bracket. -
Page 5: Modem Placement
MODEM 1-Modem Led Light 2-Sync Button: Syncs modem and room thermostat. 3-Manual Usage Button: Deactivates receiver and allows you to use boiler manually. 4-Modem Power Cable Input 5-Boiler Connection Cable Input MODEM LED LIGHT COLOR EXPLANATIONS Green Receiver synced with thermostat and Works properly. Green Flashing Pressed to receiver sync button and waiting for thermostat sync signal. -
Page 6: Application Example
APPLICATION EXAMPLE SYSTEM COMBINATION Actuator Type of Actuator Operating Voltage Positioning Type Positioning Time Thermal ST21 AC 230 V 2 Position 180 sn. SEA21.10 Motor AC 230 V 2 Position < 20 sn. APPLICATION EXAMPLE 220V 220V 6 / 12 generallife.com.tr... - Page 7 WARNING! Please do not connect the modem with another product's supply line. Risk of fire and injury due to short circuit! Please comply with local regulations when determining power cable diameters. Please supply the power line from a fuse. WARNING! The product is subject to the European Directive 2012/19 / EU as it is included in the electronic product category.
- Page 8 DAY AND HOUR SETTINGS While your thermostat is On,keep pressing “Settings” button for 3 seconds. At the first screen that appears “Hour” part will be blinking.You may set the time with “Up” and “Down” buttons After set the time, ''Settings'' button needs to be pressed once. For minute setting, minute part will be blinking. ...
-
Page 9: Weekly Program
WEEKLY PROGRAM You can adjust the weekly operating modes of your room thermostat seperately for each hours per day under favour of weekly program. Weekly program mode includes 2 active modes. They are “Comfort Mode” and “Economy Mode” In order to arrange the weekly program “Program Mode” button needs to be pressed for 3 seconds. On the screen ... -
Page 10: Technical Data
EN 300 220-2 V3.1.1:2017, EN 62479: 2010, EN 60730-2-9:2010, EN 60730-1:2011) Electromagnetic Compatibility Regulation 2014/30/EU (EMC EN 61000-6-3: 2007 + A1: 2011, EN 61000-6-1: 2007 Low Voltage Directive 2014/35/EU (LVD EN 60730-2-9:2010, EN 60730-1:2011) General Data Weight (including package) 435 g Color White Material ABS, PC... - Page 11 DIMENSIONS 85 mm 21 mm 119.5 mm 24 mm 80 mm 118 mm 6 mm 85 mm 90 mm 28.5 mm 11 / 12 generallife.com.tr...
- Page 12 ISIPARK reserves the right to change and develop the product specifications and data sheet. For all changes please visit generallife.com.tr...
