2.2 Hanging Installation

2.2.1 Preparation for hanging installation

cliver
Locking tabs
Note: 1000mm single hanging bar is used for hanging installation

2.2.2 Hanging installation steps

Step 1, Fix the hanging bars on the truss with wire rope, and connect the hanging bars
horizontally with block.
Step 2, Use the vertical connectors to fix the first row cabinets to the locking tabs of the
hanging bars.
Vertical connectors
- 12 - LR3.9-7.8 User Manual
